Parking Aid System: Removal & Installation Mercury Mariner II

Collision/avoidance 2 illustrations ~125 words

REMOVAL AND INSTALLATION

  1. Remove the lower instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-292175) article.
  2. Press the retaining tabs and remove the parking aid switch.
  3. To install, reverse the removal procedure.

Scheme 22

Scheme 22: Parking Aid Module
Scheme 22: Parking Aid Module
ItemPart NumberDescription
1Electrical connector (part of 14405)
2Parking aid module (PAM) screws (2 required)
315T850PAM
415A866Parking aid speaker
  1. Remove the RH rear quarter trim panel.
  2. Disconnect the electrical connectors.
  3. Remove the 2 screws and the parking aid module (PAM).
  4. To install, reverse the removal procedure.

Scheme 23

Scheme 23: Parking Aid Sensor
Scheme 23: Parking Aid Sensor
ItemPart NumberDescription
1Electrical connector (part of 15K868)
2131302Parking aid sensor
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-292146) article.
  2. Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-292171) article.
  3. Press the retaining tabs and remove the parking aid sensor. Disconnect the electrical connector.
  4. To install, reverse the removal procedure.
