COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Air Bag Control Module (1) | Behind Instrument Panel, On Steering Column |
| Anti-Lock Brake System (ABS) Module | Driver's Side Back Corner Of Engine Compartment |
| Anti-Theft/Double Locking Module (2) | (3) Behind Passenger's Side Kick Panel |
| Central Junction Box | Behind Left Side Of Instrument Panel |
| Data Link Connector | Under Left Side Of Instrument Panel, Next To Steering Column |
| Hybrid Electronic Cluster Module (HEC) (4) | Left Side Of Instrument Panel |
| In-Line Harness Connector C62 | Behind Instrument Cluster |
| In-Line Harness Connector C58 | (3) Behind Passenger's Side Kick Panel |
| Powertrain Control Module (PCM) | Right Rear Corner Of Engine Compartment |
| (1) Air bag control module may also be referred to as electronic crash sensor module. (2) Anti-theft/double locking module may also be referred to as Central Security Module (CSM). (3) (Scheme 9) (4) Hybrid Electronic Cluster (HEC) module is built into instrument cluster. | |
| (1) | Air bag control module may also be referred to as electronic crash sensor module. |
| (2) | Anti-theft/double locking module may also be referred to as Central Security Module (CSM). |
| (3) | (Scheme 9) |
| (4) | Hybrid Electronic Cluster (HEC) module is built into instrument cluster. |
