Luggage compartment lamp, location/task/function - GF82.20-P-4003T
Model 211.0/6
Scheme 1
In Model 211.6, depending on equipment and special body, the number and position of the interior lamps may vary
| Luggage compartment lamp, location | The luggage compartment lamp (E18/1) is installed in the luggage compartment lid, and the right trunk lamp (E18/4) as well as the left luggage compartment lamp (E18/5) are installed in the respective side paneling in the luggage compartment. |
|---|---|
| Luggage compartment lamp, task | The task of the luggage compartment lamp (E18/1), right trunk lamp (E18/4) and left luggage compartment lamp (E18/5) is to illuminate the luggage compartment and the surroundings. |
| Luggage compartment lamp, function | The luggage compartment lamp (E18/1), the right trunk lamp (E18/4) and the left luggage compartment lamp (E18/5) are switched on via the trunk lid contact switch (S88/6). |
Inside door handle illumination, location/task - GF82.20-P-4012T
MODELS 211.0/2/6
Shown on model 211.0
Scheme 2
| Inside door handle illumination, location | The illumination is located in each inside door handle. |
|---|---|
| Inside door handle illumination, task | The left front door inside handle illumination (E17/11), right front door inside handle illumination (E17/12), left rear door inside handle illumination (E17/13) and right rear door inside handle illumination (E17/14) make it easier to find the inside door handles in the dark. |
Footwell lamps, location/task - GF82.20-P-4013T
MODELS 211.0/2/6
Shown on model 211.0
Scheme 3
| Footwell lamps, location | The left front footwell lamp (E17/16) and the right front footwell lamp (E17/15) are located in the lower cover of the dashboard, the left rear footwell lamp (E17/18) and the right rear footwell lamp (E17/17) are located in the lower cover of the front seats. |
|---|---|
| Footwell lamps, task | The footwell lamps are responsible for illuminating the footwell in the dark in front of the seats when getting in and out and supplement the interior lights. |
Door contact switch, location/task/design/function - GF82.20-P-4102T
MODELS 211.0/2/6
Shown on model 211.0
Scheme 4
In Model 211.6, depending on equipment and special body, the number and position of the interior lamps may vary
| Door contact switches, position | The left front door contact switch (S17/3) and right front door contact switch (S17/4) are located in the B-pillar at the level of the closing wedge. The left rear door contact switch (S17/5) and the right rear door contact switch (S17/6) are fitted in the C-pillar in the area of the closing wedge. |
|---|---|
| Door contact switches, task | Using the door contact switches the status of the vehicle doors "open" or "closed" is measured as an electrical signal. |
| Door contact switches, design | The door contacts are openers. The switching contacts are open when the doors are closed. |
| Function of door contact switches | When the door is open, the respective door contact switch sets ground on the corresponding input of the rear SAM control unit with fuse and relay module (N10/2); this then places the message about the status of the doors on the interior CAN. |
Overhead control panel control unit, location/task/design - GF82.20-P-4110T
MODELS 211.0/2/6
Shown on 211.0
Scheme 5
| Overhead control panel control unit, location | The overhead control panel control unit (N70) is located at the front in the headliner, in the area of the inside rearview mirror unit (A67). | |
|---|---|---|
| Overhead control panel control unit, purpose | GF82.20-P-4101-02T | |
| Design of overhead control panel control unit | GF82.20-P-4101-03T |
Rear interior lamp, location/task/design - GF82.20-P-4112T
MODELS 211.0/2/6
Shown on model 211.0
Scheme 6
In Model 211.6, depending on equipment and special body, the number and position of the interior lamps may vary
| Rear interior lamp, location | The rear interior lamp (E15/3) is located in the center rear area of the roof liner. | |
|---|---|---|
| Rear interior lamp, task | GF82.20-P-4111-02T | |
| Rear interior lamp, design | GF82.20-P-4112-04T |
Trunk lid lock switch, location/task/design/function - GF82.20-P-4250T
Model 211.0/6
Scheme 7
In Model 211.6, depending on equipment and special body, the number and position of the interior lamps may vary
| Trunk lid lock switch, location | The trunk lid contact switch (S88/6) is located in the trunk lid lock. |
|---|---|
| Trunk lid lock switch, task | Using the trunk lid contact switch (S88/6), the state of the trunk lid is acquired as an electrical signal. |
| Trunk lid lock switch, design | The trunk lid contact switch (S88/6) is designed as a normally closed contact. The switch has a detent position when the trunk lid is open. |
| Trunk lid lock switch, function | If the trunk lid is open, the trunk lid contact switch (S88/6) places an input from the rear SAM control unit with fuse and relay module (N10/2) to ground. |
Survey, system components, interior lighting (IBL) location/task/design/function - GF82.20-P-9998TZ
MODELS 211.0/2/6
| Overhead control panel control unit, location/task/design | GF82.20-P-4110T | |
|---|---|---|
| Door contact switch, location/task/design/function | GF82.20-P-4102T | |
| Luggage compartment lamp, location/task/function | Models 211.0/6 | GF82.20-P-4003T |
| Load compartment lamp, location/task/function | Model 211.2 | GF82.20-P-4200TA |
| Inside door handle illumination, location/task | GF82.20-P-4012T | |
| Footwell lamps, location/task | GF82.20-P-4013T | |
| Rear interior lamp, location/task/design | GF82.20-P-4112T | |
| Trunk lid lock switch, location/task/design/function | Models 211.0/6 | GF82.20-P-4250T |
| Model 211.2 | GF82.20-P-4250TA | |
| Contents, function description of interior lighting (IL) | GF82.20-P-0998TZ |
