Seats, Restraint Systems - Basic Knowledge - 211 Chassis: Adjustments Mercedes-Benz E-class W211/S211

Electric seat adjustment (ESA) function - GF91.29-P-0004T

MODEL 211.0 /2 /6 with CODE (275) Memory package (driver seat, steering column, mirrors) with CODE (242) Electrically adjustable front passenger seat with memory

Scheme 18

Driver seat adjustment

The left front seat adjustment switch group (S91/2) can be used to move the driver seat to the desired position.

Front passenger seat adjustment

The right front seat adjustment switch group (S92/2) can be used on vehicles with code (242) Electrically adjustable front passenger seat with memory to move the front passenger seat to the desired position.

Save seat positions

The memory button 1, 2, 3 switch (S91/2s14) and memory switch (S91/2s9) can be used to store the set seat position for the driverside seat.

The key-specific storage (up to 30.5.05) can be activated or deactivated in the instrument cluster (A1).

For vehicles with code (242) Electrically adjustable front passenger seat with memory, the position of the front passenger seat can also be stored.

The front passenger seat positions are stored using the memory button 1, 2, 3 switch (S92/2s14) and the memory switch (S92/2s9).

The memory function can also be used to store the outside mirror and steering column position

To ensure that when the front passenger seat is moved back it does not bump against a folded down rear seat backrest, vehicles with electric seat adjustment are equipped with a "collision avoidance with rear seat" function.

Seat adjustment, function - GF91.29-P-2005T

MODEL 211.0 /2 /6 with CODE (275) Memory package (driver seat, steering column, mirrors) with CODE (242) Electrically adjustable front passenger seat with memory

Shown on vehicle up to 31.5.07

Adjusting Driver Seat. Scheme 19

Function requirements

1. Circuit 15R On or corresponding front door open (up to 31.5.07)

Function

The driver seat can be manually adjusted using the left front seat adjustment switch group (S91/2), the front passenger seat using the right front seat adjustment switch group (S92/2).

Switch actuation on example of driver seat

By pressing the seat fore/aft switch (S91/2s1) the driver seat can be moved forward or backward.

By pressing the seat rear raise/lower switch (S91/2s2) the rear seat height can be adjusted; using the seat front raise/lower switch (S91/2s3) the front seat height can be adjusted.

By pressing the head restraint raise/lower switch (S91/2s4) the head restraint can be moved up or down.

By pressing the backrest switch (S91/2s5) the backrest inclination can be adjusted.

An adjustment request using the left front seat adjustment switch group (S91/2) is forwarded by the left front door control unit (N69/1) via the Controller Area Network bus Class B (interior) (CAN-B) to the driver-side front seat adjustment control unit with memory (N32/1), which then activates the left front seat adjustment motor group with memory (M27) accordingly.

Collision-avoiding seat adjustment function - GF91.29-P-2010T

MODELS 211.0 /2 with CODE (242b) Electrically adjustable front passenger seat with memory with CODE (275a) Memory package (driver seat, steering column, mirrors)

collision avoidance with rear seat

Function prerequisites

1. Normalizing performed

Function

If the rear seat backrest on the front passenger side is unlocked, the rear SAM control unit with fuse and relay module (N10/2) transmits a signal over the interior CAN to the passenger-side front seat adjustment control unit with memory (N32/2).

The seat fore/aft adjustment for the front passenger seat is moved to the 95 % position (150 mm from front stop).

If the seat fore/aft adjustment is in front of this position, then a backward adjustment can only be made up to this position.

If the rear seat backrest is locked again, the seat remains in its current position.

It is not automatically moved back to its default position.

If the rear seat backrest is locked again, the seat fore/aft adjustment is possible over the entire range of adjustment.

The "collision avoidance with rear seat" function is only possible for the front passenger seat

Front seat adjustment switch group, location/design/function - GF91.29-P-2100TA

MODELS 211.0 /2 /6 with CODE (275a) Memory package (driver's seat, steering column, mirrors) with CODE (242b) Electrically adjustable front passenger seat with memory with CODE (433) Left dynamic seat, incl. multicontour seat with CODE (434) Right dynamic seat, incl. multicontour seat

Left front door depicted

Scheme 20

Front seat adjustment switch group, function - GF91.29-P-2100-02TA

Driver seat, function

By pressing the

1. seat fore/aft switch (S91/2s1), the driver seat can be moved forwards or backwards.
2. the rear seat raise/lower switch (S91/2s2), the rear seat height can be adjusted; by using the seat front raise/lower switch (S91/2s3) the front seat height can be adjusted.
3. the head restraint raise/lower switch (S91/2s4), the head restraint can be moved up or down.
4. the backrest switch (S91/2s5), the backrest angle can be adjusted.
5. the memory position 1, 2, 3 switch (S91/2s14, the stored adjustments can be requested again.
6. the memory position 1, 2, 3 switch (S91/2s14) and the memory switch (S91/2s9), the adjusted seat positions can be stored.
7. the memory position 1, 2, 3 switch (S91/2s14) and the memory switch (S91/2s9), the adjusted steering column position can also be stored.

With code (433)left dynamic seat, incl. multicontour seat and code (434) right dynamic seat, incl. multicontour seat the air cushion adjustments are also stored

By pressing the left front seat adjustment switch group (S91/2) the adjustment requests are sent to the front seat adjustment control unit with memory and driver-side easy entry (N32/1), which accordingly actuates the front seat adjustment motor group with memory, left (M27).

Front passenger seat, function

By pressing the

1. seat fore/aft switch (S92/2s1), the front passenger seat can be moved forwards or backwards.
2. the rear seat raise/lower switch (S92/2s2),the rear seat height can be adjusted; by using the seat front raise/lower switch (S92/2s3) the front seat height can be adjusted.
3. the head restraint raise/lower switch (S92/2s4), the head restraint can be moved up or down.
4. the backrest switch (S92/2s5), the backrest angle can be adjusted.
5. the memory position 1, 2, 3 switch (S92/2s14), the stored adjustments can be requested again.
6. the memory position 1, 2, 3 switch (S92/2s14) and the memory switch (S92/2s9), the adjusted seat positions can be stored.

With code (433)left dynamic seat, incl. multicontour seat and code (434) right dynamic seat, incl. multicontour seat the air cushion adjustments are also stored

By pressing the right front seat adjustment switch group (S92/2) the adjustment requests are sent to the passenger-side front seat adjustment control unit with memory (N32/2), which accordingly actuates the front seat adjustment motor group with memory, right (M28).

Front seat adjustment switch group, design - GF91.29-P-2100-04TA

Left front seat adjustment switch group (S91/2) comprises the

1. Seat forward/back switch (S91/2s1)
2. Rear seat raise/lower switch (S91/2s2)
3. Front seat raise/lower switch (S91/2s3)
4. Head restraint raise/lower switch (S91/2s4)
5. Backrest switch (S91/2s5)

for adjustment of the seat position and of

1. Memory switch (S91/2s9)
2. Memory position 1, 2, 3 switch (S91/2s14)

for storing the seat and steering column positions.

Right front seat adjustment switch group (S92/2) comprises the

1. Seat forward/back switch (S92/2s1)
2. Rear seat raise/lower switch (S92/2s2)
3. Front seat raise/lower switch (S92/2s3)
4. Head restraint raise/lower switch (S92/2s4)
5. Backrest switch (S92/2s5)

for adjustment of the seat position and of

1. Memory switch (S92/2s9)
2. Memory position 1, 2, 3 switch (S92/2s14)

for storage of seat position.

Motor group for front seat adjustment with memory, location/body - GF91.29-P-2105T

MODELS 211.0 /2 /6 with CODE (275a) Memory package (driver's seat, steering column, mirrors) with CODE (242b) Electrically adjustable front passenger seat with memory

Shown on driver seat

Identifying Front Seat Adjustment Motor Group And Backrest Forward/Back Motor. Scheme 21

Front seat adjustment motor group with memory, design - GF91.29-P-2105-01T

Structure

The left front seat adjustment with memory motor group (M27) consists of

1. Forward/back motor (M27m1)
2. Rear raise/lower motor (M27m2)
3. Front raise/lower motor (M27m3)
4. Head restraint raise/lower motor (M27m4)
5. Backrest forward/back motor (M27m5)

The right front seat adjustment with memory motor group (M28) consists of

1. Forward/back motor (M28m1)
2. Rear raise/lower motor (M28m2)
3. Front raise/lower motor (M28m3)
4. Head restraint raise/lower motor (M28m4)
5. Backrest forward/back motor (M28m5)

Left front seat adjustment control unit, with memory location/task - GF91.29-P-2106T

MODELS 211.0 /2 /6 with CODE (275a) Memory package (driver's seat, steering column, mirrors)

Supplemental Restraint System Block Diagram. Scheme 22

Left front seat adjustment control unit, with memory, purpose - GF91.29-P-2106-02T

The driver-side front seat adjustment control unit with memory (N32/1) is connected to the CAN interior. It registers signals (memory block number, state of the circuit) and states of the switch (front door contacts, seat adjustment switch).

The driver-side front seat adjustment control unit with memory (N32/1) controls the motor group front seat adjustment with memory, left (M27).

The driver-side front seat adjustment control unit with memory (N32/1) also controls the steering column adjustment motor group (M20).

Scope of function

1. 5 seat adjustment functions.
2. 2 steering column adjustment functions.
3. Driver-side easy entry through automatic seat and steering column adjustment to a position specified by the driver.
4. Recording and storage of actual position.
5. Moving to stored positions of adjustment functions
6. Moving to the fixed and defined position "presafe" as an active accident protection.

Function groups

1. Manual adjustment
2. Storing positions
3. Calling-up of stored positions
4. Head restraint presetting
5. Easy entry/exit
6. Protective functions
7. Pre-block cutout
8. Antilock device/ emergency running mode
9. Display of seat longitudinal position
10. Display of easy entry position
11. Normalization
12. Denormalization
13. Seat adjustment handicapped vehicle
14. "Presafe" function

Right front seat adjustment control unit, with memory location/task - GF91.29-P-2107T

MODELS 211.0 /2 /6 with CODE (242b) Electrically adjustable front passenger seat with memory with CODE (275a) Memory package (driver's seat, steering column, mirrors)

Identifying Passenger Front Seat Adjustment Control Unit. Scheme 23

Right front seat adjustment control unit, with memory, task - GF91.29-P-2107-02T

The passenger-side front seat adjustment control unit with memory (N32/2) is connected to the CAN interior. It registers sensor signals (memory block number, state of the circuit) and states of the switch (front door contacts, seat adjustment switch).

The passenger-side front seat adjustment control unit with memory (N32/2) controls the motor group front seat adjustment with memory, right (M28).

Scope of function

1. 5 seat adjustment functions.
2. Recording and storage of actual position.
3. Moving to stored positions of adjustment functions.
4. Moving to the fixed and defined position "presafe" as an active accident protection.

Function groups

1. Manual adjustment
2. Storing positions
3. Calling-up of stored positions
4. Head restraint presetting
5. Protective functions
6. Pre-block cutout
7. Anti-lock device/emergency running mode
8. Display of seat longitudinal position
9. Display of easy entry position
10. Normalization
11. Denormalization
12. Seat adjustment handicapped vehicle
13. "Presafe" function

Summary, electrical seat adjustment (ESV) system component, location/task/design/function - GF91.29-P-9998T

MODELS 211.0 /2 /6 with CODE (275a) Memory package (driver's seat, steering column, mirrors) with CODE (242b) Electrically adjustable front passenger seat with memory
