Lubricating pressure, function - GF27.60-P-3014G
TRANSMISSION 722.6
Operation
The working pressure regulating valve diverts surplus oil to the lubrication pressure regulating valve, from where it is controlled and used for lubricating and cooling the mechanical transmission and torque converter. In addition the pressure in the torque converter is limited via the lubrication pressure.
| Working pressure regulating valve, location/ task/function | GF27.60-P-5131G | ||
|---|---|---|---|
| Lubrication pressure regulating valve, location/ task/function | GF27.60-P-5122G | ||
| Torque converter lockup clutch regulating valve, location/task/function | GF27.60-P-5123G | ||
| Upshift / downshift solenoid valve, location / design / task / function | GF27.19-P-4006G | ||
| Shift pressure control solenoid valve location/task/design/function | GF27.19-P-5109G | ||
| Multiple-disc brake, location / task / design / function | GF27.51-P-5100G | ||
| Multiplate clutch, location / design / task / function | GF27.51-P-5101G | ||
| Holding pressure shift valve, location/task/ function | GF27.60-P-5135G | ||
| Shift pressure shift valve, location / task / function | GF27.60-P-5136G | ||
| Overlap regulating valve, location / task / function | GF27.60-P-5137G | ||
| Location/task/function of command valve | GF27.60-P-5138G | ||
| Selector valve, location/task | GF27.60-P-5139G | ||
| Location / task / design / function of oil pump | GF27.10-P-5103G |
Lubrication pressure, function - GF27.60-P-3014N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Excess oil is diverted to the lubrication pressure regulating valve at the working pressure regulating valve and from there used in a regulated manner for lubricating and cooling the mechanical transmission parts and torque converter. In addition the pressure in the torque converter is limited via the lubrication pressure.
| Control solenoid valve, location/task/design/ function | GF27.19-P-5111N | ||
|---|---|---|---|
| Torque converter, location/task/design/function | GF27.20-P-5100N | ||
| Oil pump, location/task/design/function | GF27.10-P-5103N |
Lubrication pressure regulating valve, location/task/function - GF27.60-P-5122G
TRANSMISSION 722.6
Scheme 303
| Lubrication pressure regulating valve, location | In the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Lubrication pressure regulating valve, task | Lubricates and cools the mechanical part of the transmission, and limits the pressure in the torque converter. | ||
| Lubrication pressure regulating valve, function | GF27.60-P-5122-01G |
Lubrication pressure regulating valve, function - GF27.60-P-5122-01G
Transmission 722.6
Operation
At the working pressure regulating valve (22) surplus oil is diverted to the lubrication pressure regulating valve (23), from where the lubrication pressure (p-Sm) is used in regulated amounts to supply the transmission lubrication system including the torque converter.
