Automatic transmission (AT), location of mechanical parts - GF27.10-P-0001-07G
Transmission 722.6
Identifying Automatic Transmission Hydraulic Components Position. Scheme 305
Automatic transmission (AT), location of electric/electronic components - GF27.10-P-0001-08G
Transmission 722.6
Identifying Automatic Transmission Mechanical Parts Location (Transmission 722.9). Scheme 306
Automatic transmission (AT), location of mechanical parts - GF27.10-P-0001-07N
Transmission 722.9 in model 171.4, 203, 209, 211, 215, 219, 220, 230, 463.303/340/341
Identifying Automatic Transmission Mechanical Parts Location (Transmission 722.9). Scheme 307
Automatic transmission (AT), location of electric/electronic components - GF27.10-P-0001-08N
Transmission 722.9 in model 171.4, 203, 209, 211, 215, 219, 220, 230, 463.303/340/341
Identifying Automatic Transmission Electric/Electronic Components Location (Transmission 722.9). Scheme 308
Automatic transmission (AT), location of hydraulic components - GF27.10-P-0001-09N
Transmission 722.9 in model 171.4, 203, 209, 211, 215, 219, 220, 230, 463.303/340/341
Valve housing
Identifying Valve Housing Hydraulic Components (Transmission 722.9). Scheme 309
Valve body
Identifying Valve Body Hydraulic Components (Transmission 722.9). Scheme 310
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04NR
Transmission 722.9 in model 230 except code (428a) steering wheel shift buttons
Identifying Instrument Cluster And Transmission Mode Display. Scheme 311
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04NRL
Transmission 722.9 in model 230 with code (428a) steering wheel shift buttons
Identifying Automatic Transmission Components Location. Scheme 312
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04NT
Transmission 722.9 in model 211, 219, except code (428) Steering wheel shift buttons
Model 463.303/340/341
Identifying Automatic Transmission Components Location. Scheme 313
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04NTL
Transmission 722.9 in model 211, 219 with code (428a) steering wheel shift buttons
Identifying Automatic Transmission Components Location. Scheme 314
Automatic transmission (AT), location of components, floor shift - GF27.10-P-0001-04PZ
Transmission 722.6 in models 203, 209.3 as of 01.06.03, 209.4, 211 as of 01.09.03, 219.376
Shown on model 203.061
Floor Shift Components - Shown On Model 203.061. Scheme 315
Automatic transmission (AT) location of components, floor shift - GF27.10-P-0001-04P
Transmission 722.6 in models 203, 209.3 up to 31.05.03, 211 up to 31.08.03
Shown on Model 203
Identifying Ignition Switch Lock Function Diagram - Selector Lever Position "D", "R", "N". Scheme 316
Park pawl, location/task/design/function - GF27.10-P-5100GA
TRANSMISSION 722.6 in MODEL 163, 170, 202, 208, 210 With Tapping Circuit
TRANSMISSION 722.6 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230, 240
Identifying Parking Lock Gear And Park Pawl Mechanism - Transmission 722.6. Scheme 317
| Park pawl, location | The park pawl gear (4) and park pawl mechanism (4a) are located in the rear part of the transmission housing. | ||
|---|---|---|---|
| Park pawl, task | Secures the vehicle mechanically to prevent it from rolling in addition to the parking brake. | ||
| Park pawl, design | GF27.10-P-5100-03GA | ||
| Park pawl, function | GF27.10-P-5100-02GA |
Parking lock, location / task / design / function - GF27.10-P-5100N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Parking Pawl Gear And Park Pawl Mechanism - Transmission 722.9. Scheme 318
| Park pawl, location | The park pawl gear (4) and park pawl mechanism (4a) are located in the rear area of the transmission housing. | ||
|---|---|---|---|
| Park pawl, task | Secures the vehicle mechanically to prevent it from rolling in addition to the parking brake. | ||
| Park pawl, design | GF27.10-P-5100-03N | ||
| Park pawl, function | GF27.10-P-5100-02N |
Location / task / design / function of oil pump - GF27.10-P-5103G
TRANSMISSION 722.6
Identifying Oil Pump Components Location. Scheme 319
| Oil pump, location | The oil pump (crescent-type pump) (6) is installed in the torque converter housing behind the torque converter and is driven by the drive flange of the torque converter. | ||
|---|---|---|---|
| Oil pump, task | To produce the necessary oil pressure for the hydraulic sequences. | ||
| Oil pump, design | An external gear (6a) which is mounted eccentrically in the pump housing in located on the internal gear (6b) which is connected to the drive flange (6b). The crescent (6c) drives the external gear (6a). | ||
| Oil pump, function | When the engine is running oil is delivered through the suction gallery (6e) along the top and bottom side of the crescent (6c) to the pressure chamber (6d) of the housing. The meshing of the teeth prevents oil from flowing from the pressure side to the suction side. |
Location / task / design / function of oil pump - GF27.10-P-5103N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Oil Pump Location - Transmission 722.9. Scheme 320
| Oil pump, location | The oil pump (crescent-type pump) (6) is installed in the torque converter housing behind the torque converter and is driven by the drive flange of the torque converter. | ||
|---|---|---|---|
| Oil pump, task | To produce the oil pressure required for the hydraulic sequences | ||
| Oil pump, design | An external gear (6a) which is mounted eccentrically in the pump housing in located on the internal gear (6b) which is connected to the drive flange (6b). The crescent (6c) drives the external gear (6a). | ||
| Oil pump, function | When the engine is running oil is delivered through the suction gallery (6e) along the top and bottom side of the crescent (6c) to the pressure chamber (6d) of the housing. The meshing of the teeth prevents oil from flowing from the pressure side to the suction side. |
Float, location/function - GF27.10-P-5107G
TRANSMISSION 722.6
Identifying Electric Control Unit And Float. Scheme 321
| Float, location | In the electrical control unit (Y3/6). | ||
|---|---|---|---|
| Float, function | GF27.10-P-5107-04G |
Float, location/function - GF27.10-P-5107N
TRANSMISSION 722.9 in MODEL 171.4
TRANSMISSION 722.9 in MODEL 463.30
Identifying Float 1, Float 2 And Electrical Control Unit Location - Transmission 722.9. Scheme 322
| Float, location | Float 1 (31) and float 2 (32) are accommodated in the electric control unit (VGS) (Y3/8). | ||
|---|---|---|---|
| Float, function | As the oil level rises, float 1 (31) and float 2 (32) seal the openings between the oil chamber and the gear set chamber. |
Kickdown simulator, location/task - GF27.10-P-5108N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Illustrated on model 230
Identifying Kickdown Simulator (Transmission 722.9) - Illustrated On Model 230. Scheme 323
| Kick-down simulator, location | The kick-down simulator (100) is located in the footwell, installed in the electronic accelerator. | ||
|---|---|---|---|
| Kick-down simulator, task | The kick-down simulator (100) enables the driver to detect the use of the kick-down function with his foot. |
Kick-down simulator, location/task - GF27.10-P-5108T
TRANSMISSION 722.6 in model 203 as of 1.6.02, 209, 211, 215 as of 1.6.02, 219, 220, 230 as of 1.6.02, 240
Illustrated on Model 230
Identifying Kickdown Simulator (Transmission 722.6) - Illustrated On Model 230. Scheme 324
| Kick-down simulator, location | The kick-down simulator (100) is located in the footwell, installed in the electronic accelerator. | ||
|---|---|---|---|
| Kick-down simulator, task | The kick-down simulator (100) enables the driver to detect with his foot that kick-down function is used. |
Survey of system components, automatic transmission (AT), location / task / design / function - GF27.10-P-9990N
TRANSMISSION 722.9 in MODEL 215, 220
| Selection range sensor, location/task | GF27.19-P-5142N | ||
|---|---|---|---|
| Torque converter, location/task/design/function | GF27.20-P-5100N | ||
| Location/task/function of rpm sensor | GF27.19-P-5127N | ||
| Electric control unit, location/task/design/function | GF27.19-P-5104N | ||
| Transmission housing ventilation, location/task | GF27.40-P-2007N | ||
| Kick-down simulator, location/task | GF27.10-P-5108N | ||
| Multi-disk brake, location/task/design | GF27.51-P-5104N | ||
| Multi-disk clutch, location/task/design | GF27.51-P-5103N | ||
| Center shifter console, location/task/design/function | GF27.60-P-5100N | ||
| Oil pump, location/task/design/function | GF27.10-P-5103N | ||
| Park pawl, location/task/design/function | GF27.10-P-5100N | ||
| Planetary gear set, location/task/design/function | Ravigneaux gear set | GF27.50-P-5100N | |
| Simple planetary gear system | GF27.50-P-5100NN | ||
| Location/task of R/P lock | GF27.60-P-5121N | ||
| Shift detent, location/task/design/function | GF27.60-P-5101N | ||
| Float, location/function | GF27.10-P-5107N | ||
| VGS control unit, location/task | GF27.19-P-4013N | ||
| Control solenoid valve, location/task/design/function | GF27.19-P-5111N | ||
| Electronic selector lever module control unit, location/task | GF27.19-P-5140N | ||
| Transmission oil temperature sensor, location/task/design | F27.19-P-4014N | ||
| Torque converter lockup clutch, location/task/design/function | GF27.20-P-5101N | ||
| Automatic transmission (AT), contents, function description | GF27.10-P-0999N |
Upshift / downshift solenoid valve, location / task / design / function - GF27.19-P-4006G
TRANSMISSION 722.6
Identifying Upshift / Downshift Solenoid Valve Components Location. Scheme 325
| Upshift/downshift solenoid valve, location | In the shell of the electric control unit and pressed against the shift plate with a spring. | ||
|---|---|---|---|
| Upshift/downshift solenoid valve, task | The shift solenoid valves (Y3/6y3, Y3/6y4, Y3/6y5) introduce the sequence of upshifts and downshifts in the shift plate. | ||
| Upshift/downshift solenoid valve, design | GF27.19-P-4006-03G | ||
| Upshift/downshift solenoid valve, function | GF27.19-P-4006-04G |
ETC control unit, location/task - GF27.19-P-4012G
TRANSMISSION 722.6
Identifying ETC [EGS] Control Unit. Scheme 326
![Scheme 326: Identifying ETC [EGS] Control Unit](https://i.diagnostdata.com/repair/fc/fc7bec355f00ad2da63341bf76c2bb77103312a0fae747c105016b9e82523aec.webp)
| ETC control unit, location | Model 129, 170, 202, 203, 208, 209, 211, 219, 240 | GF27.19-P-4012-01GG | |
|---|---|---|---|
| Model 163 | GF27.19-P-4012-01GH | ||
| Model 171.4 | GF27.19-P-4012-01SK | ||
| Model 140,210,215,220 | GF27.19-P-4012-01G | ||
| Model 230 | GF27.19-P-4012-01R | ||
| ETC control unit, task | Model 170, 202, 208, 210 without touch shift | GF27.19-P-4012-02G | |
| Model 129, 140 | |||
| Model 170, 202, 208, 210 with touch shift | GF27.19-P-4012-02GB | ||
| Model 163 without touch shift | GF27.19-P-4012-02GH | ||
| Model 163 with touch shift | GF27.19-P-4012-02GI | ||
| Model 171.4 except code (428) steering wheel shift buttons | GF27.19-P-4012-02SK | ||
| Model 171.4 with code (428) steering wheel shift buttons | GF27.19-P-4012-02SKB | ||
| Model 203 (except 203.076/276) except code (428) steering wheel shift buttons | GF27.19-P-4012-02P | ||
| Model 203 with code (428) steering wheel shift buttons | GF27.19-P-4012-02PM | ||
| Type 203.076/276 | |||
| Model 209 up to 31.05.04 | GF27.19-P-4012-02Q | ||
| Model 209 as of 01.06.04 | GF27.19-P-4012-02QX | ||
| Model 211 up to 31.05.04 | GF27.19-P-4012-02T | ||
| Model 211 as of 01.06.04 | GF27.19-P-4012-02TX | ||
| Model 219 | GF27.19-P-4012-02TY | ||
| Model 215, 220 | GF27.19-P-4012-02GA | ||
| Model 230 except code (428) steering wheel shift buttons | GF27.19-P-4012-02R | ||
| Model 230 with code (428) steering wheel shift buttons | GF27.19-P-4012-02RX | ||
| Model 240 | GF27.19-P-4012-02X |
ETC control unit, location - GF27.19-P-4012-01GG
Transmission 722.6 in models 129, 170, 202, 203, 208, 209, 211, 219, 240
Shown on MODEL 170
Location
The ETC control unit (N15/3) is installed under the tread plate in the front passenger footwell.
ETC Control Unit - Shown On Model 170. Scheme 327
VGS control unit, location/task - GF27.19-P-4013N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying VGS Control Unit Location - Transmission 722.9. Scheme 328
| VGS control unit, location | The fully integrated transmission control (VGS) control unit (Y3/8n4) is integrated into the electric controller unit (VGS) (Y3/8). | ||
|---|---|---|---|
| VGS [fully integrated transmission control], task | Model 171.4 (except model 171.473/44) except code (428) Steering wheel shift buttons | GF27.19-P-4013-02NK | |
| Model 171.4 with code (428) Steering wheel shift buttons Model 171.473 | GF27.19-P-4013-02NKL | ||
| Model 203 except code (428) Steering wheel shift buttons | GF27.19-P-4013-02NP | ||
| Model 203 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02NPL | ||
| Model 209 except code (428) Steering wheel shift buttons | GF27.19-P-4013-02NQ | ||
| Model 209 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02NQL | ||
| Model 211, except code (428) Steering wheel shift buttons 463.303/340/341 | GF27.19-P-4013-02NT | ||
| Model 211 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02NTL | ||
| Model 219 except code (428) Steering wheel shift buttons | GF27.19-P-4013-02TX | ||
| Model 219 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02TXL | ||
| Model 215, 220 | GF27.19-P-4013-02N | ||
| Model 230 except code (428) Steering wheel shift buttons | GF27.19-P-4013-02NR | ||
| Model 230 with code (428) Steering wheel shift buttons | GF27.19-P-4013-02NRL |
Transmission oil temperature sensor, location/task/design - GF27.19-P-4014N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Transmission Oil Temperature Sensor Location - Transmission 722.9. Scheme 329
| Transmission oil temperature sensor, location | The transmission oil temperature sensor (VGS) (Y3/8s2) is integrated in the fully integrated transmission control (VGS) control unit (Y3/8n4). | ||
|---|---|---|---|
| Transmission oil temperature sensor, task | The transmission oil temperature sensor (VGS) (Y3/8s2) detects the transmission oil temperature and passes this on as an input parameter to the fully integrated transmission control (VGS) control unit (Y3/8n4). | ||
| Transmission oil temperature sensor, design | Temperature-dependent resistor |
Electric control module, location / task / design / function - GF27.19-P-5104G
TRANSMISSION 722.6
Identifying Valve Housing Of Shift Plate And Electric Control Unit. Scheme 330
| Electric control module, location | Bolted onto the valve housing of shift plate (2a). | ||
|---|---|---|---|
| Electric control module, design | To receive various input signals and to convert the control module information into hydraulic functions. | ||
| Electric control module, design | GF27.19-P-5104-01G | ||
| Electric control module, function | GF27.19-P-5104-02G |
Electric control unit, location/task/design/function - GF27.19-P-5104N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Locations
Identifying Electric Control Unit Location - Transmission 722.9. Scheme 331
| Electric control unit, location | The electric control unit (VGS) (Y3/8), valve body (21b), intermediate panel (21c) and valve body (21d) are connected to each other by bolts and are mounted under the transmission housing. | ||
|---|---|---|---|
| Electric control unit, design | Recording various input signals and converting control unit information into hydraulic functions | ||
| Electric control unit, design | GF27.19-P-5104-01N | ||
| Electric control unit, function | GF27.19-P-5104-02N |
Starter lock-out contact, location/task/design/function - GF27.19-P-5106G
TRANSMISSION 722.6
Identifying Starter Lock-Out Contact Location. Scheme 332
| Starter lockout contact, location | The starter lockout contact (Y3/6s1) is located in the electrical control unit (Y3/6) and is permanently connected to the conductor tracks. | ||
|---|---|---|---|
| Starter lockout contact, task | To recognize selector valve and selector lever position "P" and "N". | ||
| Starter lockout contact, design | The starter lockout contact (Y3/6s1) consists of: a plunger a permanent magnet a reed contact | ||
| Starter lockout contact, function | GF27.19-P-5106-01G |
Temperature sensor, location / task / design / function - GF27.19-P-5108G
TRANSMISSION 722.6
Identifying Temperature Sensor Components Location. Scheme 333
| Temperature sensor, location | The transmission oil temperature sensor (Y3/6b1) is located in the electrical control unit (Y3/6) and is permanently connected to the conductor tracks. | ||
|---|---|---|---|
| Temperature sensor, task | To measure the temperature of the transmission oil and pass the temperature to the ETC control unit (N15/3) as an input signal. | ||
| Temperature sensor, design | Temperature-dependent resistor (PTC). | ||
| Temperature sensor, function | GF27.19-P-5108-04G |
Shift pressure regulating solenoid valve, location / task / design / function - GF27.19-P-5109G
TRANSMISSION 722.6
Identifying Shift Pressure Regulating Solenoid Valve Components Location. Scheme 334
| Shift pressure regulating solenoid valve, location | In the supporting body of the electrical control unit (Y3/6) and pressed against the valve housing of the shift plate (2a) by means of a leaf spring. | ||
|---|---|---|---|
| Shift pressure regulating solenoid valve, task | To control the shift pressure depending on the constantly changing operating conditions, such as load/gear changes. | ||
| Shift pressure regulating solenoid valve, design | GF27.19-P-5109-03G | ||
| Shift pressure regulating solenoid valve, function | The shift pressure regulating solenoid valve (Y3/6y2) assigns a proportional pressure to the current which is controlled by the ETC control module (N15/3) according to the load. |
Modulating pressure regulating solenoid valve, location / task / design / function - GF27.19-P-5110G
TRANSMISSION 722.6
Identifying Modulating Pressure Regulating Solenoid Valve Components Location. Scheme 335
| Modulating pressure regulating solenoid valve, location | In the supporting body of the electrical control unit (Y3/6) and pressed against the valve housing of the shift plate (2a) by means of a leaf spring. | ||
|---|---|---|---|
| Modulating pressure regulating solenoid valve, task | To control the modulating pressure depending on the constantly changing operating conditions such as load/gear changes. | ||
| Modulating pressure regulating solenoid valve, design | GF27.19-P-5110-03G | ||
| Modulating pressure regulating solenoid valve, function | The modulating pressure regulating solenoid valve (Y3/6y1) assigns a proportional pressure to the current which is controlled by the ETC control module (N15/3) according to the load. |
Control solenoid valve, location/task/design/function - GF27.19-P-5111N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Control Solenoid Valve - Transmission 722.9. Scheme 336
| Control solenoid valve, location | The control solenoid valves are mounted on the electric control unit (VGS) (Y3/8). | ||
|---|---|---|---|
| Control solenoid valve, task | Working pressure control solenoid valve | GF27.19-P-5111-01A | |
| Clutch control solenoid valve K1 | GF27.19-P-5111-01B | ||
| Clutch control solenoid valve K2 | GF27.19-P-5111-01C | ||
| Clutch control solenoid valve K3 | GF27.19-P-5111-01D | ||
| Brake control solenoid valve B1 | GF27.19-P-5111-01E | ||
| Brake control solenoid valve B2 | GF27.19-P-5111-01F | ||
| Brake control solenoid valve B3 | GF27.19-P-5111-01G | ||
| Torque converter lockup clutch control solenoid valve | GF27.19-P-5111-01H | ||
| Control solenoid valve, design | With the control solenoid valves used the proportional solenoids convert the electric signals of the fully integrated transmission control (VGS) control unit (Y3/8n4). The float needles can also be moved into intermediate positions as a result. | ||
| Control solenoid valve, function | The control solenoid valves assign a proportional pressure to a current regulated by the fully integrated transmission control (VGS) control unit (Y3/8n4). |
Wheel speed sensor, location / task / function - GF27.19-P-5127G
TRANSMISSION 722.6
Identifying Wheel Speed Sensor Components. Scheme 337
| Wheel speed sensor location | The RPM sensors 2 and 3 (Y3/6n2 and Y3/6n3) are permanently connected with the supporting body of the electrical control unit (Y3/6) via contact tongues. | ||
|---|---|---|---|
| Wheel speed sensor - Function | The signals from the RPM sensors 2 3 (Y3/6n2, Y3/6n3) are recorded in the ETC control module (N15/3) together with the wheel and engine speeds and other information, and are the input signals for the electronic control system. | ||
| Speed sensor, function | GF27.19-P-5127-04G |
Speed sensor, location/task/function - GF27.19-P-5127N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Speed Sensor Location - Transmission 722.9. Scheme 338
| Speed sensor, location | The turbine speed sensor (VGS) (Y3/8n1), the internal speed sensor (VGS) (Y3/8n2) and output speed sensor (VGS) (Y3/8n3) are permanently connected to the electric control unit (VGS) (Y3/8) and cannot be replaced individually. | ||
|---|---|---|---|
| Speed sensor, task | Turbine speed sensor | GF27.19-P-5127-02N | |
| Internal rpm sensor | GF27.19-P-5127-02P | ||
| Output speed sensor | GF27.19-P-5127-02O | ||
| Speed sensor, function | Turbine speed sensor | GF27.19-P-5127-04N | |
| Internal rpm sensor | GF27.19-P-5127-04P | ||
| Output speed sensor | GF27.19-P-5127-04O |
Location / task / function of position indicator - GF27.19-P-5129RM
TRANSMISSION 722.6 in MODEL 209.376 up to 31.5.03, 211.076, 230.474 up to 31.8.03
Shown on model 230.474
Identifying Shift Pattern Display And Transmission Mode Switch (Shows Model 230.474). Scheme 339
| Position display, location | The position display (shift pattern display (87)) is housed in the cover of the center shifter console. In addition a gear display and transmission mode display is located in the instrument cluster (A1). | ||
|---|---|---|---|
| Position display, task | GF27.19-P-5129-02RM | ||
| Position display, function | GF27.19-P-5129-03RM |
Position sensor, location/task/function - GF27.19-P-5129RMZ
TRANSMISSION 722.6 in model 209.376 as of 1.6.03, 209.476, 211.076 as of 1.9.03, 211.276, 215.374 /379, 219.376, 220.074 /174 /179, 230.474 as of 1.9.03, 230.479
TRANSMISSION 722.6 in MODEL 209, 211, 230 with CODE (428) Steering wheel shift buttons
Illustrated on model 230.474
Identifying Shift Pattern Display And Transmission Mode Switch - Illustrated On Model 230.474. Scheme 340
| Position display, location | The position display is accommodated in the center shift console cover. In addition a gear/ driving program display is located in the instrument cluster (A1). | ||
|---|---|---|---|
| Position display, task | GF27.19-P-5129-02RMZ | ||
| Shift pattern display, function | Model 209, 211, 219, 230 | GF27.19-P-5129-03RMZ | |
| Model 215, 220 | GF27.19-P-5129-03GAZ |
Location / task / function of position indicator - GF27.19-P-5129T
TRANSMISSION 722.6 in MODEL 211 (except 211.076) up to 31.8.03
Identifying Shift Pattern Display And Transmission Mode Switch. Scheme 341
| Position display, location | The position display (shift pattern display (87)) is housed in the cover of the center shifter console. In addition a gear display and transmission mode display is located in the instrument cluster (A1). | ||
|---|---|---|---|
| Position display, task | GF27.19-P-5129-02P | ||
| Position display, function | GF27.19-P-5129-03Q |
Location / task / function of position indicator - GF27.19-P-5129TZ
TRANSMISSION 722.6 in MODEL 211 (except 211.076 /05 /25 /276) as of 1.9.03 except CODE (428a) Steering wheel shift buttons
Identifying Shift Pattern Display And Transmission Mode Switch. Scheme 342
| Position display, location | The position display is accommodated in the center shift console cover. In addition a gear/ driving program display is located in the instrument cluster (A1). | ||
|---|---|---|---|
| Position display, task | GF27.19-P-5129-02PZ | ||
| Shift pattern display, function | GF27.19-P-5129-03QZ |
Steering wheel gear shifter, location/task/function - GF27.19-P-5137NT
TRANSMISSION 722.9 in MODEL 211, 219 up to 31.5.06 with CODE (428) Steering wheel shift buttons
Shown on model 211
Identifying Steering Wheel Gear Shifter (Shown On Model 211). Scheme 343
| Steering wheel gear shifter, location | The left steering wheel gear shifter (S110/2) is located on the left, the right steering wheel gear shifter (S111/2) is located on the right on the rear of the multifunction steering wheel (MFL). | ||
|---|---|---|---|
| Steering wheel gear shifter, task | Shifting range preselection Shifting into a gear from which the vehicle can be favorably accelerated or decelerated. Direct shifting of all forward gears | ||
| Steering wheel gear shifter, function | GF27.19-P-5137-04NT |
Steering wheel gear shifter, location/task/function - GF27.19-P-5137PMA
TRANSMISSION 722.6 in MODEL 203, 209, 211 up to 31.5.06 with CODE (428) Steering wheel shift buttons
Illustrated on model 203
Identifying Steering Wheel Gear Shifter (Transmission 722.6) - Illustrated On Model 203. Scheme 344
| Steering wheel gear shifter, location | The left steering wheel gear shifter (S110/2) is located on the left, the right steering wheel gear shifter (S111/2) is located on the right on the rear of the multifunction steering wheel (MFL). | ||
|---|---|---|---|
| Steering wheel gear shifter, task | Shifting range preselection Shifting into a gear from which the vehicle can be favorably accelerated or decelerated. Direct shifting of all forward gears | ||
| Steering wheel gear shifter, function | GF27.19-P-5137-04PMA |
Steering wheel gear shifter, location/task/function - GF27.19-P-5137PMB
TRANSMISSION 722.6 in model 203.076 /276, 209.376 /476, 211.076 /276 as of 1.6.04, 219.376
Shown on model 203
Identifying Steering Wheel Gear Shifter (Transmission 722.6) - Shown On Model 203. Scheme 345
| Steering wheel gear shifter, location | The steering wheel gear shifter MINUS (S110/1) is located on the left, the steering wheel gear shifter PLUS (S111/1) is located on the right on the back of the multifunction steering wheel (MFL). | ||
|---|---|---|---|
| Steering wheel gear shifter, task | Preselection of shift range. Shifting into a gear from which the vehicle can be favorably accelerated or decelerated. Direct shifting of all forward gears. | ||
| Steering wheel gear shifter, function | GF27.19-P-5137-04PMB |
Steering wheel gear shifter, location/task/function - GF27.19-P-5137RM
TRANSMISSION 722.6 in MODEL 209.376 /476, 211.076 /276 up to 31.5.04, 215.374 /379, 220.074 /174 /179, 230.474 /479
Illustrated on Model 230.474
Identifying Steering Wheel Gear Shifter MINUS And Steering Wheel Gear Shifter PLUS (Illustrated On Model 230.474). Scheme 346
| Steering wheel gear shifter, location | The steering wheel gear shifter MINUS (S110/1) is located on the left, the steering wheel gear shifter PLUS (S111/1) is located on the right on the back of the multifunction steering wheel (MFL). | ||
|---|---|---|---|
| Steering wheel gear shifter, task | For program selection "M" (manual program) the individual gears of the transmission can be shifted directly via the steering wheel gear shifter MINUS (S110/1) or the steering wheel gear shifter PLUS (S111/1). | ||
| Steering wheel gear shifter, function | GF27.19-P-5137-04RM |
Electronic selector lever module control unit, location/task/design - GF27.19-P-5138P
TRANSMISSION 722.6 in model 203 up to 23.4.04, 209, 211, 219
Illustrated on model 203.0
Identifying Electronic Selector Lever Module Control Unit (Transmission 722.6) - Illustrated On Model 203.0. Scheme 347
| Control unit for electronic selector lever module, location | The control unit for the electronic selector lever module (N15/5) is located in the center console of the vehicle. | ||
|---|---|---|---|
| Control unit for electronic selector lever module, task | Model 203 | GF27.19-P-5138-02P | |
| Model 209 up to 31.05.04 | GF27.19-P-5138-02Q | ||
| Model 209 as of 01.06.04 | GF27.19-P-5138-02QX | ||
| Model 211 up to 31.05.04 | GF27.19-P-5138-02T | ||
| Model 211 as of 01.06.04 Model 219 | GF27.19-P-5138-02TX | ||
| Electronic selector lever module control unit, design | GF27.19-P-5138-03P |
Electronic selector lever module control unit, location/task - GF27.19-P-5140NT
TRANSMISSION 722.9 in MODELS 211, 219
Identifying Electronic Selector Lever Module Control Unit (Shown On Model 211.0). Scheme 348
Shown on model 211.0
| Control unit for electronic selector lever module, location | The control unit for the electronic selector lever module (N15/5) is located in the center console of the vehicle. | ||
|---|---|---|---|
| Control unit for electronic selector lever module, task | Except code (428a) steering wheel shift buttons | GF27.19-P-5138-02NT | |
| With code (428a) steering wheel shift buttons | GF27.19-P-5138-02NTL |
Selection range sensor, location/task - GF27.19-P-5142N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Selection Range Sensor - Transmission 722.9. Scheme 349
| Selection range sensor, location | The selection range sensor (VGS) (Y3/8s1) is integrated in the electric control unit (VGS) (Y3/8). | ||
|---|---|---|---|
| Selection range sensor, task | The task of the selection range sensor (VGS) (Y3/8s1) is to detect the selection ranges "P", "R", "N", "D" and the intermediate position. |
Transmission housing breather, location/task - GF27.40-P-2007G
TRANSMISSION 722.6
Identifying Transmission Housing Breather. Scheme 350
| Transmission housing breather, location | The inside of the transmission and the breather (72) are connected by a channel which is cast into the torque converter casing. | ||
|---|---|---|---|
| Transmission housing breather, task | The transmission housing vent compensates the pressure in the transmission housing if temperature-related volume changes in the transmission oil and air occur. |
Transmission housing vent, location/task - GF27.40-P-2007N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Manual Program Selection Function Chart. Scheme 351
| Transmission housing breather, location | The inside of the transmission and the breather (72) are connected by a channel which is cast into the torque converter housing. | ||
|---|---|---|---|
| Transmission housing breather, task | The transmission housing breather ensures that a pressure equilibrium is maintained in the event of temperature-related volume changes in the transmission fluid and air in the transmission housing. |
Planetary gear set, location / task / design / function - GF27.50-P-5100G
TRANSMISSION 722.6
Identifying Planetary Gear Set Components Location. Scheme 352
| Planetary gear set, location | Three planetary gear sets are used to produce the different gear ratios. These are located in the mechanical part of the transmission as the front, center and rear planetary gear set (V, M, H) | ||
|---|---|---|---|
| Planetary gear set, task | Power transmission and production of different gear ratios. | ||
| Planetary gear set, design | A planetary gear set consists of the ring gear (1), the planet gears (2) carried in the planet carrier (4) and the sun gear (3). | ||
| Planetary gear set, function | GF27.50-P-5100-01G |
Planetary gear set, location/task/design/function - GF27.50-P-5100N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230 Ravigneaux gear set
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Planetary Gear Set - Transmission 722.9. Scheme 353
| Planetary gear set, location | The Ravigneaux gear set (9) is located in the mechanical part of the transmission. | ||
|---|---|---|---|
| Planetary gear set, task | Power transmission and production of different gear ratios. | ||
| Planetary gear set, design | The Ravigneaux gear set (9) used consists of 2 ring gears, a planet carrier, a sun gear as well as short and long planetary gears. | ||
| Planetary gear set, function | GF27.50-P-5100-01N |
Planetary gear set, location/task/design/function - GF27.50-P-5100NN
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230 Single planetary gear set
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Single Planetary Gear Set - Transmission 722.9. Scheme 354
| Planetary gear set, location | The front single planetary gear set (12a) and the rear single planetary gear set (12b) are located in the mechanical part of the transmission. | ||
|---|---|---|---|
| Planetary gear set, task | Power transmission and production of different gear ratios. | ||
| Planetary gear set, design | A single planetary gear system consists of a ring gear, the planetary gears mounted in the planet carrier and a sun gear | ||
| Planetary gear set, function | GF27.50-P-5100-01NN |
Multiple-disc brake, location / task / design / function - GF27.51-P-5100G
TRANSMISSION 722.6
Identifying Multiple-Disc Brake Components. Scheme 355
| Multiple-disc brake, location | Three multiple-disc brakes arranged as the front, center and rear multiple-disc brake (B1, B3, B2) are located in the planetary gear sets in the transmission housing. | ||
|---|---|---|---|
| Multiple-disc brake, task | Brace the ring gear, sun gear or planet carrier of a planetary gear set against the transmission housing in order to transmit the drive torque. | ||
| Multiple-disc brake, design | A multiple-disc brake consists of a number of internally toothed discs (10) on an internally toothed disc carrier and externally toothed discs (9) on an externally toothed disc carrier, which is rigidly connected to the transmission housing. | ||
| Multiple-disc brake, function | GF27.51-P-5100-04G |
Multi-plate clutch, location / task / design / function - GF27.51-P-5101G
TRANSMISSION 722.6
Identifying Multi-Plate Clutch Components Function. Scheme 356
| Multi-disk clutch, location | Three multi-plate clutches, the front, middle and rear multi-plate clutches K1, K2 and K3, are located in the planetary gear sets in the transmission housing. | ||
|---|---|---|---|
| Multi-disk clutch, task | Produces a non-positive locking connection between two elements of a planetary gear set or between one element from each of two planetary gear sets in order to transmit the drive torque. | ||
| Multiple-disc clutch, design | A multi-plate clutch consists of a number of internally toothed discs (10) on an internally toothed disc carrier and externally toothed discs (9) on an externally toothed disc carrier. | ||
| Multi-disk clutch, function | GF27.51-P-4000-01G |
Location / task / design / function of freewheel - GF27.51-P-5102G
TRANSMISSION 722.6
Identifying Freewheel Components Function. Scheme 357
| Freewheel, location | In the front planetary gear set a freewheel (F1, F2) is installed between the front sun gear (V1) and the stator shaft (8) and in the rear planetary gear set between the rear sun gear (H1) and the intermediate shaft (3). | ||
|---|---|---|---|
| Freewheel, task | Optimizes individual gearshifts. Support of the individual elements of a planetary gear set against each other or against the transmission housing in one direction of rotation in order to permit torque transmission. | ||
| Freewheel, design | The freewheels (F1, F2) consist of an outer race (12), an inner race (13), a number of clamping bodies (14) and a clamping body cage (15). | ||
| Freewheel, function | GF27.51-P-5102-04G |
Multi-disk clutch, location/task/design - GF27.51-P-5103N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Multi-Disk Clutch - Transmission 722. Scheme 358
| Multi-disk clutch, location | 3 multi-disk clutches made up of multi-disk clutch K1 (8), multi-disk clutch K2 (11) and multi-disk clutch K3 (14) are arranged in planetary gear systems in the transmission housing. | ||
|---|---|---|---|
| Multi-disk clutch, task | To produce a friction connection between 2 elements of a planetary gear set or one element each from 2 planetary gear sets, for transferring the drive torque. | ||
| Multi-disk clutch, design | GF27.51-P-5103-03N |
Multi-disk brake, location/task/design - GF27.51-P-5104N
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 215, 219, 220, 230
TRANSMISSION 722.9 in MODEL 463.303 /340 /341
Identifying Multi-Disk Brake - Transmission 722.9. Scheme 359
| Multi-disk brake, location | 4 multi-disk brakes made up of multi-disk brake B1 (7), multi-disk brake B3 (10), multi-disk brake BR (13) and multi-disk brake B2 (15) are arranged in the planetary gear systems in the transmission housing. | ||
|---|---|---|---|
| Multi-disk brake, task | To support the ring gear, sun gear or planet carrier of a planetary gear set relative to the transmission housing, to transmit the drive torque. | ||
| Multi-disk brake, design | GF27.51-P-5104-03N |
Location / task / design / function of floor shift - GF27.60-P-5100NT
TRANSMISSION 722.9 in MODEL 211, 219
Identifying Floor Shift Location. Scheme 360
| Floor shift, location | The floor shift is located in the center console of the vehicle. | ||
|---|---|---|---|
| Floor shift, task | The floor shift is the central control for the driver to influence the shift program of the automatic transmission. | ||
| Floor shift, design | GF27.60-P-5100-03NT | ||
| Floor shift, function | GF27.60-P-5100-04NT |
Center shifter console, location/task/design/function - GF27.60-P-5100NTL
TRANSMISSION 722.9 in MODEL 211, 219 with CODE (428) Steering wheel shift buttons
Identifying Center Shifter Console Location. Scheme 361
| Center shifter console, location | The floor shift is located in the center console of the vehicle. | ||
|---|---|---|---|
| Center shifter console, task | The floor shift is the central control for the driver to influence the shift program of the automatic transmission. | ||
| Center shifter console, design | GF27.60-P-5100-03NTL | ||
| Center shifter console, function | GF27.60-P-5100-04NT |
Center shifter console, location/task/design/function - GF27.60-P-5100P
TRANSMISSION 722.6 in MODEL 203, 209, 211, 219
Identifying Center Shifter Console Location - Shown On Model 203.061. Scheme 362
Shown on model 203.061
| Center shifter console, location | The floor shift is located in the center console of the vehicle. | ||
|---|---|---|---|
| Center shifter console, task | The floor shift is the central control for the driver to influence the shift program of the automatic transmission. | ||
| Center shifter console, design | Models 203, 209 up to 31.05.03, 211 to 31.08.03 | GF27.60-P-5100-03P | |
| Model 203, 209 as of 01.06.03, 211 after 01.09.03 | GF27.60-P-5100-03PZ | ||
| Model 219 | |||
| Center shifter console, function | GF27.60-P-5100-04P |
Shift detent, location/task/design/function - GF27.60-P-5101NT
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 219
Identifying Shift Detent Location - Transmission 722.9 In Model 171.4, 203, 209, 211, 219. Scheme 363
| Shift detent, location | The shift detent is integrated in the electronic selector lever module control unit (N15/5). | ||
|---|---|---|---|
| Shift detent, task | Locating the selector lever positions "R", "N" and "D" | ||
| Shift detent, design | The shift detent consists of the locking lever (69) permanently connected with the selector lever (80), a leaf spring (85) clamped in the basic housing and a roller (84) inserted in the leaf spring (85). | ||
| Shift detent, function | GF27.60-P-5101-04NT |
Location / task / design / function of shift detent - GF27.60-P-5101P
TRANSMISSION 722.6 in MODEL 171.4, 203, 209, 211, 219
Identifying Shift Detent Location - Transmission 722.6 In Model 171.4, 203, 209, 211, 219. Scheme 364
| Shift detent, location | The shift detent is integrated in the electronic selector lever module control unit (N15/5). | ||
|---|---|---|---|
| Shift detent, task | Fixing the selector lever positions "R", "N" and "D". | ||
| Shift detent, design | The shift detent consists of: the locking lever (69) rigidly connected to the selector lever (80). a leaf spring clamped in the base body (85). a roller (84) inserted in the leaf spring (85) (84). | ||
| Shift detent, function | GF27.60-P-5101-04P |
R/P lock, location/task/design/function - GF27.60-P-5103NT
TRANSMISSION 722.9 in MODEL 171.4, 203, 209, 211, 219
Identifying Command Valve Function Diagram - Shift Phase (B1 Disengaging, K1 Engaging). Scheme 365
| R/P lock, location | The R/P lock is integrated in the electronic selector lever module control unit (N15/5). | ||
|---|---|---|---|
| R/P lock, task | Depending on the condition the R/P lock prevents shifting out of selector lever position "P" or changing into selector lever position "R" from "N". | ||
| R/P lock, design | The R/P lock consists of: Locking lever (69) R/P locking solenoid (89) Rocker (100) Leaf spring of rocker (101) Rocker arm (102) Leaf spring of rocker arm (103) | ||
| R/P lock, function | GF27.60-P-5103-04NT |
R/P lock, location/task/design/function - GF27.60-P-5103P
TRANSMISSION 722.6 in MODEL 171.4, 203, 209, 211, 219
Identifying R/P Lock Location - Transmission 722.6 In Model 171.4, 203, 209, 211, 219. Scheme 366
| R/P lock, location | The R/P lock is integrated in the electronic selector lever module control unit (N15/5). | ||
|---|---|---|---|
| R/P lock, task | Depending on the prerequisite, the R/P-lockout prevents a shift out of selector lever position "P" or a changeover to selector lever position "R" from "N". | ||
| R/P lock, design | The R/P lock consists of: Locking lever (69) R/P locking solenoid (89) Rocker (100) Leaf spring of rocker (101) Rocker arm (102) Leaf spring of rocker arm (103) | ||
| R/P lock, function | GF27.60-P-5103-04P |
Working pressure regulating valve, location/task/function - GF27.60-P-5131G
TRANSMISSION 722.6
Identifying Valve Housing Of Shift Plate, Working Pressure Regulating Valve. Scheme 367
| Working pressure regulating valve, location | 2In the valve housing of the shift plate. | ||
|---|---|---|---|
| Working pressure regulating valve, task | Regulates the primary pressure of the hydraulic system. | ||
| Working pressure regulating valve, function | GF27.60-P-5131-01G |
Shift pressure regulating valve, location / task / function - GF27.60-P-5132G
TRANSMISSION 722.6
Identifying Valve Housing Of Shift Plate, Working Pressure Regulating Valve. Scheme 368
| Shift pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Shift pressure regulating valve, task | Control of shift pressure. | ||
| Shift pressure regulating valve, function | GF27.60-P-5132-04G |
Regulating valve pressure regulating valve, location / task / function - GF27.60-P-5133G
TRANSMISSION 722.6
Identifying Valve Housing Of Shift Plate, Working Pressure Regulating Valve. Scheme 369
| Regulating valve pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Regulating valve pressure regulating valve, task | Controls the regulating valve pressure. | ||
| Regulating valve pressure regulating valve, function | GF27.60-P-5133-04G |
Shift valve pressure regulating valve, location/task/function - GF27.60-P-5134G
TRANSMISSION 722.6
Identifying Valve Housing Of Shift Plate, Working Pressure Regulating Valve. Scheme 370
| Shift valve pressure regulating valve, location | In the valve housing of shift plate (2b). | ||
|---|---|---|---|
| Shift valve pressure regulating valve, task | Control of shift valve pressure. | ||
| Shift valve pressure regulating valve, function | GF27.60-P-5134-04G |
Holding pressure shift valve, location/task/function - GF27.60-P-5135G
TRANSMISSION 722.6
Identifying Holding Pressure Shift Valve Components. Scheme 371
| Holding pressure shift valve, location | Each shift group is assigned a holding pressure shift valve (28a, 28b, 28c). The holding pressure shift valves 1-2/4-5 (28a) and 2-3 (28b) are installed in the valve housing (2b), the 3-4 holding pressure shift valve (28c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Holding pressure shift valve, task | Allocates the working pressure to one actuator of a shift group. | ||
| Holding pressure shift valve, function | GF27.60-P-5135-04G |
Shift pressure shift valve, location / task / function - GF27.60-P-5136G
TRANSMISSION 722.6
Identifying Pressure Shift Valve Components. Scheme 372
| Shift pressure shift valve, location | Each shift group possesses one shift pressure shift valve. The 1-2/4-5 shift pressure shift valves (29a) and 2-3 shift pressure shift valve (29b) are installed in the valve housing of the shift plate (2b), the 3-4 shift pressure shift valve (29c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Shift pressure shift valve, task | To assign shift pressure to the engaging shift actuator and to assign the overlap pressure, controlled by the overlap regulating valve, to the disengaging shift actuator. | ||
| Shift pressure shift valve, function | GF27.60-P-5136-04G |
Overlap regulating valve, location / task / function - GF27.60-P-5137G
TRANSMISSION 722.6
Identifying Overlap Regulating Valve Components. Scheme 373
| Overlap regulating valve, location | Each shift group is assigned one overlap regulating valve. The 1-2/4-5 overlap regulating valve (30a) is installed in the valve housing of the shift plate (2b), the 2-3 overlap regulating valve (30b) and 4-5 (30c) are installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Overlap regulating valve, location | The overlap regulating valve regulates the pressure reduction during a shift phase. | ||
| Overlap regulating valve, function | GF27.60-P-5137-04G |
Location/task/function of command valve - GF27.60-P-5138G
TRANSMISSION 722.6
Identifying Command Valve Components. Scheme 374
| Command valve, location | Each shift group possesses one command valve. The 1-2/4-5 command valves (31a) and 2-3 (31b) are installed in the valve housing of the shift plate (2b), the 3-4 command valve (31c) is installed in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Command valve, task | The command valves switch the shift groups from the stationary phase into the shift phase and back again | ||
| Command valve, function | GF27.60-P-5138-04G |
Selector valve, location/task - GF27.60-P-5139G
TRANSMISSION 722.6
Identifying Valve Housing Of Shift Plate, Selector Valve. Scheme 375
| Selector valve, location | The selector valve (52) is located in the valve housing of the shift plate (2a). | ||
|---|---|---|---|
| Selector valve, task | Distributes pressure to the appropriate hydraulic components according to the selector lever position selected by the driver. |
