Auxiliary battery relay, location/task - GF54.10-P-4201T
MODEL 211.0 /2 up to 31.5.06 except CODE (494) USA version except CODE (498) Japan version
MODEL 211.0 /2 up to 30.6.06 with CODE (494) USA version with CODE (498) Japan version
Location
Identifying Fuse Assignment Of Front Prefuse Box - Rear. Scheme 11
| Auxiliary battery relay, location | The auxiliary battery relay (K57/2) is mounted on the partition wall to the passenger compartment near the auxiliary battery (G1/7). | ||
|---|---|---|---|
| Auxiliary battery relay, task | The auxiliary battery relay (K57/2) separates the battery (G1) from the auxiliary battery (G1/7). The auxiliary battery relay (K57/2) connects both batteries in parallel when required and to charge the auxiliary battery (G1/7). |
Two-battery vehicle power supply, survey of system components, location/ task/design/function - GF54.10-P-9999TZ
MODEL 211.0 /2 up to 31.5.06 except CODE (494) USA version except CODE (498) Japan version
MODEL 211.0 /2 up to 30.6.06 with CODE (494) USA version with CODE (498) Japan version
| Auxiliary battery relay, location/task | GF54.10-P-4201T | ||
|---|---|---|---|
| Battery control unit location/task | GF54.21-P-4121T | ||
| Two-battery vehicle power supply, contents, function description | GF54.10-P-0999TZ |
Fuel pump relay, location/task/design/function - GF54.15-P-4105AM
MODEL 211, 219 with ENGINE 113.990
MODEL 215, 220 with ENGINE 113.991
MODEL 230 with ENGINE 113.992 /995
MODEL 463 with ENGINE 113.993
Identifying Instrument Cluster Operating Information - Shown As Of 1.6.05. Scheme 12
| Fuel pump relay, location | Model 211, 219 | GF54.15-P-4105-01TA | |
|---|---|---|---|
| Model 215, 220 | GF54.15-P-4105-01AM | ||
| Model 230 | GF54.15-P-4105-01RA | ||
| Model 463 | GF54.15-P-4105-01GM | ||
| Fuel pump relay, task | The fuel pump relay actuates the fuel pump (M3) or the fuel pump control unit (N118). | ||
| Fuel pump relay, design | The fuel pump relay is a 4-pin plug-in relay. | ||
| Fuel pump relay, function | GF54.15-P-4105-02AM |
Fuel pump relay, location - GF54.15-P-4105-01TA
Model 211, 219
MODEL 211.0, 219
Shown on model 211.0
The fuel pump relay is located in the luggage compartment, at the rear on the right wheelhouse.
Type 211.2
Identifying Fuel Pump Relay - Type 211.2. Scheme 14
The fuel pump relay is located in the luggage compartment, at the rear on the right wheelhouse.
Upper control panel control unit, location/task/design/function - GF54.21-P-4105T
Model 211.0 /6
Identifying Upper Control Panel Control Unit Location - Model 211.0 /6. Scheme 15
| Upper control panel control unit, location | The upper control panel control unit (N72/1) is located below the audio unit in the central area of the dashboard. | ||
|---|---|---|---|
| Upper control panel control unit, task | GF54.21-P-4105-02T | ||
| Upper control panel control unit, design | GF54.21-P-4105-03T | ||
| Upper control panel control unit, function | The upper control panel control unit (N72/1) operates with its own dedicated microprocessor which scans switches, actuates appropriate semiconductor switches and exchanges data with the interior CAN. |
Upper control panel control unit, location / task / design / function - GF54.21-P-4105TS
MODEL 211.2
Shown up to 31.5.06
Indicator Lamp Test And Engine Running Detection - Communication Diagram. Scheme 16
| Upper control panel control unit Location | The upper control panel control unit (N72/1) is installed in the center section of the dashboard. | ||
|---|---|---|---|
| Upper control panel control unit, task | GF54.21-P-4105-02TS | ||
| Upper control panel control unit, design | Up to 31.5.06 without code (494) USA version without code (498) Japan version up to 30.6.06 with code (494) USA version with code (498) Japan version | GF54.21-P-4105-03TS | |
| As of 1.6.06 without code (494) USA version without code (498) Japan version as of 1.7.06 with code (494) USA version with code (498) Japan version | GF54.21-P-4105-03TM | ||
| Upper control panel control unit, function | The upper control panel control unit (N72/1) operates with its own microprocessor which reads in switches, processes signals and exchanges data with the Controller Area Network bus class B (interior) (CAN-B). |
Driver-side SAM control unit with fuse and relay module, location/task/design - GF54.21-P-4109T
MODELS 211.0 /2 /6
Identifying Driver-Side SAM Control Unit With Fuse And Relay Module Location - Models 211.0 /2 /6. Scheme 17
| Driver-side SAM control unit with fuse and relay module, location | The driver-side SAM control unit with fuse and relay module (N10/1) is located in the engine compartment near the left hood hinge (looking towards front of vehicle). | ||
|---|---|---|---|
| Driver-side SAM control unit with fuse and relay module, task | GF54.21-P-4109-01T | ||
| Driver-side SAM control unit with fuse and relay module, design | The driver-side SAM control unit with fuse and relay module (N10/1) is contained in a sturdy plastic housing. Various fuses and relays are attached to the control unit on a supporting bracket. |
Passenger-side SAM control module with fuse and relay module, location/task/design - GF54.21-P-4111T
MODELS 211.0 /2 /6
Battery Charge/Alternator Monitoring - Communication Diagram. Scheme 18
| Passenger-side SAM control module with fuse and relay module, location | The passenger-side SAM control module (N10/11) is located in the right front footwell. | ||
|---|---|---|---|
| Passenger-side SAM control module with fuse and relay module, task | GF54.21-P-4111-01T | ||
| Passenger-side SAM control module with fuse and relay module, design | The front passenger SAM control unit (N10/11) is accommodated in a plastic housing and on a stable carrier plate. |
Lower control panel control module, location / task / design - GF54.21-P-4116T
MODELS 211.0 /2 /6
location
Identifying Lower Control Panel Control Module Location. Scheme 19
| Lower control panel control module, location | The lower control panel control module (N72) is divided into groups of switches or buttons which are arranged on the center console around the gearshift lever or selector lever. | ||
|---|---|---|---|
| Lower control panel control module, task | GF54.21-P-4116-01T | ||
| Bottom control panel control unit design | GF54.21-P-4116-02T |
Battery control unit location/task - GF54.21-P-4121T
MODEL 211.0 /2 up to 31.5.06 except CODE (494) USA version except CODE (498) Japan version
MODEL 211.0 /2 up to 30.6.06 with CODE (494) USA version with CODE (498) Japan version
Identifying Battery Control Unit Location - Arrangement Illustrated. Scheme 20
Arrangement illustrated on model 211.0
| Battery control unit location | The battery control unit (N82) is located in the spare tire well of the luggage compartment. | ||
|---|---|---|---|
| Battery control unit, task | GF54.21-P-4121-02T |
Rain/light sensor location/task/function - GF54.21-P-4123Q
MODEL 209.3 /4, 211.0 /2, 215, 220 as of 1.9.02
Shown on model 209.3
Identifying Rain/Light Sensor - Shown On Model 209.3. Scheme 21
| Rain/light sensor location | The rain/light sensor (B38/2) is stuck onto the inside of the windshield below the overhead control panel control module. | ||
|---|---|---|---|
| Rain/light sensor task | The rain sensor (B38/2) measures the quantity of moisture on the windshield and controls the intermittent time of the wiper system. At the same time it also records the intensity of the daylight and through this controls the automatic functions of exterior lights and interior lights. | ||
| Rain sensor/light sensor, function | GF54.21-P-4123-04Q |
Steering column module location/task - GF54.21-P-4125T
MODEL 211.0 /2 /6
Shown on Model 211.0
Identifying Steering Column Module Location - Model 211.0. Scheme 22
| Steering column module, location | The steering column module (N80) is located on the steering column. | ||
|---|---|---|---|
| Steering column module, task | GF54.21-P-4104-02T |
Rear SAM control unit with fuse and relay module, location/task - GF54.21-P-4130T
MODEL 211.0 /6
Shown on model 211.0
Identifying Rear SAM Control Unit With Fuse And Relay Module Location - Model 211.0. Scheme 23
| Rear SAM control unit with fuse and relay module, location | The rear SAM control unit with fuse and relay module (N10/2) is installed in the trunk at the inner wheel house on the left side in the direction of travel. | ||
|---|---|---|---|
| Rear SAM control unit with fuse and relay module, task | GF54.21-P-4112-01T |
Rear SAM control unit with fuse and relay module, location/task - GF54.21-P-4130TA
MODEL 211.2
Identifying Rear SAM Control Unit With Fuse And Relay Module Location - Model 211.2. Scheme 24
| Rear SAM control unit with fuse and relay module, location | The rear SAM control unit with fuse and relay module (N10/2) is installed in the luggage compartment on the inner wheelhouse on the left viewed in the direction of travel. | ||
|---|---|---|---|
| Rear SAM control unit with fuse and relay module, task | GF54.21-P-4112-01TJ |
Data link connector, location/task/design/function - GF54.22-P-2100T
MODEL 211.0 /2 /6
Identifying "CHECK ENGINE" MIL Component Description. Scheme 25
| Data link connector, location | The data link connector (X11/4) is located in the driver-side footwell. | ||
|---|---|---|---|
| Data link connector, task | The 16-pin data link connector (X11/4) connects the STAR DIAGNOSIS and the K-lines of the control units in the vehicle. | ||
| Data link connector, design | GF54.22-P-2100-02T | ||
| Data link connector, function | The data link connector (X11/4) bundles the K-lines of the control units in the vehicle into a fixed connector. The K-lines must be active for outputting faults so that the fault codes of the control units can be read out. |
Instrument cluster (IC), location / task - GF54.30-P-3039T
MODEL 211.0 /2 up to 31.5.06 except CODE (494) USA version except CODE (498) Japan version
MODEL 211.0 /2 up to 30.6.06 with CODE (494) USA version with CODE (498) Japan version
Location
Identifying Instrument Cluster Location. Scheme 26
| Instrument cluster (IC), location | The instrument cluster (A1) is located in the instrument panel. | ||
|---|---|---|---|
| Instrument cluster (IC), task | GF54.30-P-3039-02T |
"CHECK ENGINE" MIL, location/task/function - GF54.30-P-4101AM
MODEL 211, 219 with ENGINE 113.990 with CODE (494) USA version
MODEL 215, 220 with ENGINE 113.991 with CODE (494) USA version
MODEL 230 with ENGINES 113.992 /995 with CODE (494) USA version
MODEL 463 with ENGINE 113.993 with CODE (491) USA version
Shown on MODEL 211, 219
Identifying Check Engine Malfunction Indicator Lamp - Shown On Model 211, 219. Scheme 27
| "CHECK ENGINE" malfunction indicator lamp, location | The indicator lamp is located in the instrument cluster (A1). | ||
|---|---|---|---|
| "CHECK ENGINE" malfunction indicator lamp, task | The indicator lamp signals faults relevant to exhaust emissions to the driver. | ||
| "CHECK ENGINE" malfunction indicator lamp, function | The indicator lamp is actuated by the ME-SFI [ME] control unit (N3/10) at the ground end when the engine is started. If there is no fault, the motor electronics control unit interrupts the actuation and the indicator lamp goes out. To check the bulb function it lights up for approx. 1 second when the ignition is switched "ON". |
Survey of system components, instrument cluster (IC), location / task / design / function - GF54.30-P-9997TZ
MODEL 211.0 /2 up to 31.5.06 except CODE (494) USA version except CODE (498) Japan version
MODEL 211.0 /2 up to 30.6.06 with CODE (494) USA version with CODE (498) Japan version
| Instrument cluster (IC), location / task | GF54.30-P-3039T | ||
|---|---|---|---|
| Table of contents for function description of instrument cluster (IC) | GF54.30-P-0997TZ |
PTS control unit, location / task - GF54.65-P-4100T
MODEL 211.0 /2 with CODE (220a) Parktronic system (PTS)
Shown on model 211.0
N62 PTS control unit
Identifying PTS Control Unit, Location - Shown On Model 211.0. Scheme 28
| PTS control unit, location | The Parktronic control unit(N62) is mounted in the trunk behind the left paneling. | ||
|---|---|---|---|
| PTS control unit, task | Actuation of the sensors Evaluation of echo journey times Bidirectional data transfer from and to the PTS warning displays System checks Data exchange with CAN class B |
Sensors, location/task/function - GF54.65-P-4102T
MODEL 209.3 /4, 211.0 /2 with CODE (220a) Parktronic system (PTS)
Scheme 29
Shown on model 211.0
| Sensors, location | The front bumper PTS sensor unit (A42) and rear bumper PTS sensor unit (A43) are located in the respective bumper. | ||
|---|---|---|---|
| Sensors, task | The sensors transmit ultrasonic waves and detect echoes from existing obstacles. | ||
| Sensors, function | The ultrasonic sensors function based on the echo sounding principle and operate as transmitters and receivers. |
Warning display, location / task / design / function - GF54.65-P-4104T
MODEL 209.3 /4, 211.0 /2 with CODE (220a) Parktronic System (PTS)
center instrument panel PTS warning indicator
Shown on model 211.0
Scheme 30
| Warning display, location | The center instrument panel PTS warning indicator (A44/4) is located in the center of the instrument panel. | ||
|---|---|---|---|
| Warning display, task | Displays of the distance to an obstacle in the front monitoring range. When the minimum distance is not reached, output of an acoustic signal. | ||
| Warning display, design | The center instrument panel PTS warning indicator (A44/4) consists of the LCD bar display (model 209) or the LEDs (model 211), the frame, the sound source and microprocessor which evaluates and converts the data telegrams of the Parktronic control unit. | ||
| Warning display, function | Models 211.0/2 | GF54.65-P-4104-01T | |
| Models 209.3/4 | GF54.65-P-4104-01Q |
Warning display, location / task / design / function - GF54.65-P-4104TA
MODEL 209.3 /4, 211.0 /2 with CODE (220a) Parktronic System (PTS)
Rear PTS warning indicator
Shown on model 211.0
Scheme 31
| Warning display, location | The PTS warning display, rear (A44/3) is located in the rear area of the headliner. | ||
|---|---|---|---|
| Warning display, task | To display the distance to an obstacle in the rear monitoring range. When the minimum distance is not reached, output of an acoustic signal. | ||
| Warning display, design | The rear PTS warning indicator (A44/3) consists of the LCD bar display (model 209) or the LEDs (model 211), the sound source and microprocessor which evaluates and converts the data telegrams of the Parktronic control unit. | ||
| Warning display, function | Models 211.0/2 | GF54.65-P-4104-01T | |
| Models 209.3/4 | GF54.65-P-4104-01Q |
Survey of system components, Parktronic system (PTS), location / task / design / function - GF54.65-P-9999T
MODEL 211.0 /2 with CODE (220a) Parktronic system (PTS)
| PTS control unit, location / task | GF54.65-P-4100T | ||
|---|---|---|---|
| Sensors, location/task/function | GF54.65-P-4102T | ||
| Warning display, location / task / design / function | PTS warning display, rear | GF54.65-P-4104TA | |
| PTS warning display, center of instrument panel | GF54.65-P-4104T | ||
| Contents, function description, Parktronic system (PTS) | GF54.65-P-0999T |
