Engine Controls - Self-Diagnostics with Codes: Overview Mercedes-Benz E-class W210/S210 facelift

Testing & Diagnostics 1 illustration

MODEL IDENTIFICATION

ModelChassis/Model NumberEngine Number
E300 Turbo Diesel210.025606.962

MODEL IDENTIFICATION (1998-99)

COMPONENT/CIRCUIT IDENTIFICATION

System components and connections are identified by the manufacturer with special designations in diagnostic information. See COMPONENT/CIRCUIT IDENTIFICATION table.

Component/CircuitManufacturer's Designation
Boost Pressure Control/Pressure Control Flap Vacuum TransducerY31/5
Crankshaft Position (CKP) SensorL5/6
Cruise Control SwitchS40
EGR Lifting SenderB28/3
EGR Valve Vacuum TransducerY31/1
Electronic Ignition Lock Control ModuleN73
Electrohydraulic Shut-Off ActuatorY1/1
Electronics Output Ground-Right FootwellW15
Engine Coolant Temperature (ECT) SensorB11
Fuel Rack Position SensorY23/1l1
Fuel Temperature SensorY1/1b1
Fuel Quantity Actuator (IFI)Y23/1
Hot Film MAF SensorB2/5
IFI Accelerator Pedal Position SensorR25/2
IFI Control ModuleN3/7
Intake Air Temperature (IAT) SensorB17
Mass Airflow Sensor (MAF)B2/5
Passenger Side Fuse & Relay Module BoxK40/4
Preglow Control UnitN14/2
Pressure SensorB28
Relay ModuleK40
Starter Lock-Out/Backup Light SwitchN15/3
Stop Light SwitchS9/1
Transmission Control ModuleN15/3

COMPONENT/CIRCUIT IDENTIFICATION

IFI CONTROL MODULE CONNECTOR IDENTIFICATION

Note. For IFI control module connector identification (Scheme 1)

Scheme 1

Scheme 1: IFI CONTROL MODULE CONNECTOR IDENTIFICATION

DIAGNOSTIC TROUBLE CODE IDENTIFICATION

Use DTC identification to identify possible cause, then proceed to indicated area under TEST STEP/REMEDY column. Before proceeding with diagnostic testing, see HOW TO READ DIAGNOSTIC INFORMATION .

DTCPossible causeTest Step/Remedy
P0100Hot film MAF sensor (B2/5)19, see IFI SYSTEM TEST STEPS 18.0-20.0
P0105Pressure sensor (B28)8, see IFI SYSTEM TEST STEPS 7.1-8.1
P0110IAT sensor (B17)7, see IFI SYSTEM TEST STEPS 6.1-7.0
P0115ECT sensor (B11)6, see IFI SYSTEM TEST STEPS 4.0-6.0
P0180Fuel temperature sensor (Y1/1b1)17, see IFI SYSTEM TEST STEPS 17.0-17.2
P0500VSSTest Electronic Traction System/Speed Sensitive Power Steering (ETS/SPS). See TRACTION CONTROL in BRAKES.
P0600CAN data bus DTC P0600 can be displayed even if no malfunction is present20, see IFI SYSTEM TEST STEPS 18.0-20.0
P0700DTC code ETCSee appropriate AUTOMATIC TRANSMISSION ELECTRONIC CONTROLS article in TRANSMISSION SERVICE & REPAIR for IMPORTED VEHICLES.
P0703Stop lamp switch (S9/1)See TRACTION CONTROL in BRAKES
P1105Atmospheric pressure sensor in control moduleReplace In-Line Fuel Injection (IFI) control module
P1220Fuel quantity actuator (IFI) (Y23/1)10, IFI SYSTEM TEST STEPS 10.0-11.1
P1221CAN communication ASR interruptedSee TRACTION CONTROL in BRAKES
P1222IFI accelerator pedal position sensor (R25/2)12, see IFI System Test Step 12.0
P1223Fuel rack position sensor (Y23/ 1/1)11, see IFI SYSTEM TEST STEPS 10.0-11.1
P1330Starter operation24, see IFI SYSTEM TEST STEPS 23.0-24.1
P1335CKP sensor (IFI) (L5/6)9, see IFI SYSTEM TEST STEPS 9.0-9.1
P1401EGR lifting sender (B28/3)18, see IFI SYSTEM TEST STEPS 18.0-20.0
P1404EGR valve vacuum transducer (Y31/1)15, see IFI SYSTEM TEST STEPS 15.0-15.2
P1470Boost pressure control/pressure control flap vacuum transducer (Y31/5)14, see IFI SYSTEM TEST STEPS 14.0-14.2
P1480Preglow control25, see IFI SYSTEM TEST STEPS 25.0-26.1
P1481Glow plug failure27, see IFI System Test Step 27.0
P1482Preglow control unit (N14/2)26, see IFI SYSTEM TEST STEPS 25.0-26.1
P1520Cruise control switch (S40)13, see IFI System Test Step 13.0
P1610Voltage supply missing or relay module (K40)5, see IFI SYSTEM TEST STEPS 4.0-6.0
P1611Internal reference voltage (2.5V)Replace In-Line Fuel Injection (IFI) control module
P1612IFI control module (N3/7) voltage, circuit 154, see IFI SYSTEM TEST STEPS 4.0-6.0
P1613IFI control module (N3/7) stabilizationReplace In-Line Fuel Injection (IFI) control module
P1614IFI control module (N3/7) microprocessor/fuel calculationReplace In-Line Fuel Injection (IFI) control module
P1615IFI control module (N3/7) supply voltage1, see IFI SYSTEM TEST STEPS 1.0-3.0
P1617N3/7 EEPROM or incorrectly codedReplace In-Line Fuel Injection (IFI) control module or perform VERSION CODING again.
P1622Electrohydraulic shut-off actuator (Y1/1)16, see IFI SYSTEM TEST STEPS 16.0-16.2
P1630Drive authorization signal23, see IFI SYSTEM TEST STEPS 23.0-24.1
P1705Starter lock-out/backup lamp switch (N15/3)21, see IFI SYSTEM TEST STEPS 21.0-22.1

DIAGNOSTIC TROUBLE CODE LIST
