Engine Controls - Tests W/codes: Diagnosis Mercedes-Benz E-class W210/S210

Testing & Diagnostics 27 illustrations ~387 words

SELF-DIAGNOSTIC SYSTEM

The Inline Fuel Injection (IFI) control module is equipped with a self-diagnostic capability for trouble shooting. Diagnostic Trouble Code (DTC) memory remains active if ignition is turned off or battery is disconnected. The CHECK ENGINE Malfunction Indicator Light (MIL) will illuminate to indicate severe faults.

Using Generic Scan Tool

Turn ignition off. Connect generic scan tool to diagnostic connector located under left side of dashboard. (Scheme 1) Turn ignition on. Follow tool manufacturer's instructions for reading fault codes.

Scheme 1

Scheme 1: Using Generic Scan Tool

FAULT CODE DIAGNOSIS EQUIPMENT CONNECTION

Turn ignition off. Disconnect Inline Fuel Injection (IFI) control unit connector. Install Test Cable (104 589 00 63 00) between IFI control unit and IFI control unit connector. Connect Test Cable (104 589 00 63 00) to Socket Box (129 589 00 21 00). (Scheme 2) Connect DVOM as instructed in diagnostic information.

Scheme 2

Scheme 2: FAULT CODE DIAGNOSIS EQUIPMENT CONNECTION

UNDERSTANDING DIAGNOSTIC INFORMATION

Note. IFI control unit is referred to as N37 by the manufacturer. When diagnosing IFI, test connections are made at IFI control unit (N37) using Socket Box (129 589 00 21 00).

For reading and understanding fault code diagnosis, as an example, using DIAGNOSTIC TESTS, read fault code P1615. Start at step 1.0. Under TEST SCOPE column, component being tested is IFI control module (N3/7), voltage supply. Under TEST CONNECTION column, using DVOM, measure resistance between socket box terminals No. 19 and 37. Under TEST CONDITION column, make measurement with ignition on. Voltage is 11-14 volts under NOMINAL VALUE column. If voltage is within specification, go to next step (1.1). If voltage is not within specification, follow instructions under POSSIBLE CAUSE/REMEDY column. Replace relay module (K40) or repair faulty wiring.

DIAGNOSTIC TESTS

Fault codes are not in numerical order. First code number listed is for Hand Held Tester (HHT). Second code number listed is for generic scan tool. Not all codes have a corresponding generic scan tool code number. Some fault codes are identified with the same fault code number when using a generic scan tool.

Scheme 3

Scheme 3: Fault Code Diagnosis P1612 & P1615 (Step 1.0-2.0)

Scheme 4

Scheme 4: Fault Code Diagnosis P1610 & P0115 (Step 3.0-4.0)

Scheme 5

Scheme 5: Fault Code Diagnosis P0115 & P0110/P0111 (Step 4.1-5.0)

Scheme 6

Scheme 6: Fault Code Diagnosis P0110/P0111 & P0105 (Step 5.1-6.1)

Scheme 7

Scheme 7: Fault Code Diagnosis P1335/P0725 (Step 7.0-7.1)

Scheme 8

Scheme 8

Scheme 9

Scheme 9: Fault Code Diagnosis P1220/P1614/P0200 & P1223/P1614/P0200 (Step 8.0-9.2)

Scheme 10

Scheme 10: Fault Code Diagnosis P1222/P0220 & P1705 (Step 10.0-11.0)

Scheme 11

Scheme 11: Fault Code Diagnosis P0703 (Step 12.0-12.2)

Scheme 12

Scheme 12: Fault Code Diagnosis P0703 (Step 13.0-13.2)

Scheme 13

Scheme 13: Fault Code Diagnosis P1520 & P0500 (Step 14.0-15.0)

Scheme 14

Scheme 14

Scheme 15

Scheme 15: Fault Code Diagnosis P1520 (Step 16.0)

Scheme 16

Scheme 16: Fault Code Diagnosis P1625 (Step 17.0)

Scheme 17

Scheme 17: Fault Code Diagnosis P1700 & P1781 (Step 19.0-21.1)

Scheme 18

Scheme 18: Fault Code Diagnosis P1622/P0200 (Step 22.0-22.2)

Scheme 19

Scheme 19: Fault Code Diagnosis P0180/P0181 (Step 23.0-24.0)

Scheme 20

Scheme 20: Fault Code Diagnosis P0600 & P1475/P0200 (Step 25.0-26.1)

Scheme 21

Scheme 21: Fault Code Diagnosis P1476/P0200 (Step 27.0-28.0)

Scheme 22

Scheme 22

Scheme 23

Scheme 23: Fault Code Diagnosis P1401/P0403 (Step 29.0-30.1)

Scheme 24

Scheme 24: Fault Code Diagnosis P0400 & P1470/P0120 (Step 31.0-32.0)

Scheme 25

Scheme 25: Fault Code Diagnosis P1480/P0380 & P1480/P0380 (Step 1.0-2.2)

Scheme 26

Scheme 26: Fault Code Diagnosis P1480/P0380 (Step 2.2-3.0)

Scheme 27

Scheme 27: Fault Code Diagnosis P1480/P0380 (Step 4.0-4.1)
