Transfer - Tribute Except Hybrid: Removal & Installation Mazda Tribute II

Transfer Case 18 illustrations ~1166 words

Removal

All vehicles

Scheme 1

Scheme 1: Removal
Scheme 1: Removal
  1. With the vehicle in NEUTRAL, position it on a hoist. See «LIFTING»(ref-348626-S31954056142009112700000) .
  2. Disconnect the battery. See «BATTERY DISCONNECT»(ref-348661-S24834528062009112700000) .
  3. Drain the power transfer unit (PTU). See «POWER TRANSFER UNIT (PTU) DRAINING AND FILLING - AUTOMATIC TRANSAXLE»(ref-348644-S09642280372009112700000) .
  4. Remove the front RH intermediate shaft. See «INTERMEDIATE SHAFT REMOVAL/INSTALLATION»(ref-348673-S12309767802009112700000) . CAUTION: A new PTU intermediate shaft seal must be installed whenever the intermediate shaft or PTU is removed from the vehicle.
  5. Remove the driveshaft. See «DRIVESHAFT REMOVAL/INSTALLATION»(ref-348678-S15469676532009112700000) .
  6. Remove the 4 bolts and the crossmember brace. Vehicles equipped with 3.0L engines
  7. Remove the exhaust as required. See «EXHAUST SYSTEM - 3.0L»(ref-348630-S33550017012009112700000) . All vehicles
  8. Remove the 3 PTU heat shield bolts and the PTU heat shield.
  9. Remove the 6 PTU-to-engine bracket bolts and the bracket.
  10. Disconnect the PTU vent tube and position it aside.
  11. Remove the 3 PTU-to-transaxle bolts.
  12. Remove the PTU.

Scheme 2

Scheme 2: POWER TRANSFER UNIT (PTU) SEAL REMOVAL
Scheme 2: POWER TRANSFER UNIT (PTU) SEAL REMOVAL

Scheme 3

Scheme 3
Scheme 3
  1. Remove the power transfer unit (PTU) from the vehicle. See «POWER TRANSFER UNIT (PTU) - REMOVAL»(ref-348644-S20710885922009112700000) .
  2. Using the Halfshaft Oil Seal Remover and Slide Hammer, remove the intermediate shaft seal.
  3. Remove the bolt and the vent tube.
  4. Remove the 12 bolts and the PTU cover.
  5. Remove the helical driven gear, idler gear and drive gear.
  6. Using a suitable tool, remove the input shaft seal.
  7. Clean the PTU sealing surface.

Scheme 4

Scheme 4: POWER TRANSFER UNIT (PTU) - INSTALLATION
Scheme 4: POWER TRANSFER UNIT (PTU) - INSTALLATION

Installation

All vehicles

  1. Position the power transfer unit (PTU) to the transaxle. CAUTION: A new power transfer unit (PTU) intermediate shaft seal must be installed whenever the intermediate shaft or PTU is removed from the vehicle. NOTE: If necessary, install a new RH differential fluid seal.
  2. Install the 3 PTU-to-transaxle bolts. Tighten to 70 N.m {7.0 kgf.m, 52 ft.lbf}.
  3. Install the PTU-to-engine bracket and the 6 bracket bolts. Tighten to 48 N.m {4.8 kgf.m, 35 ft.lbf}.
  4. Connect the PTU vent tube.
  5. Install the PTU-to-transaxle bolt (M10). Tighten to 47 N.m {4.7 kgf.m, 35 ft.lbf}.
  6. Install the PTU heat shield and the 3 PTU heat shield bolts. Tighten to 11 N.m {1.12 kgf.m, 97 in.lbf}. Vehicles equipped with 3.0L engines
  7. Install the RH manifold catalytic converter. See «CATALYTIC CONVERTER REMOVAL/INSTALLATION - RH, 3.0L»(ref-348630-S01845308652009112700000) All vehicles
  8. Install the crossmember brace and the 4 bolts. Tighten to 40 N.m {4.1 kgf.m, 30 ft.lbf}.
  9. Install the driveshaft. See «DRIVESHAFT REMOVAL/INSTALLATION»(ref-348678-S15469676532009112700000) .
  10. Install the front RH intermediate shaft. See «INTERMEDIATE SHAFT REMOVAL/INSTALLATION»(ref-348673-S12309767802009112700000)
  11. Install the exhaust as required. See «EXHAUST SYSTEM»(ref-348629-S10264560342009112700000) or «EXHAUST SYSTEM - 3.0L»(ref-348630-S33550017012009112700000) .
  12. Fill the PTU. See «POWER TRANSFER UNIT (PTU) DRAINING AND FILLING - AUTOMATIC TRANSAXLE»(ref-348644-S09642280372009112700000) .
  13. Check the transaxle fluid level. See «TRANSAXLE - 2.5L INSTALLATION»(ref-348668-S05978645032009112700000) .

Scheme 5

Scheme 5: POWER TRANSFER UNIT (PTU) SEAL INSTALLATION
Scheme 5: POWER TRANSFER UNIT (PTU) SEAL INSTALLATION

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Using the Driven Gear Oil Seal Installer, install the inner input seal.
  2. Install the helical gears. Install the drive gear. Use a slight rotation to prevent damaging the inner input seal. Install the idler gear. Install the driven gear. CAUTION: Make sure not to roll the inner input seal sealing lip when installing the drive gear.
  3. Apply a 3 mm (0.11 in) bead of silicone sealant to the sealing surface of the PTU cover. Install the PTU cover and tighten the 11 PTU cover bolts in a star pattern. Tighten to 32 N.m {3.2 kgf.m, 24 ft.lbf}. CAUTION: The PTU cover and case sealing surfaces must be free of oil before applying new sealant.
  4. Install the PTU vent tube and the 2 PTU vent tube bolts. Tighten to 14 N.m {1.4 kgf.m, 124 in.lbf}.
  5. Using the Halfshaft Oil Seal Installer and Handle, install the intermediate shaft seal.
  6. Install the PTU in the vehicle. See «POWER TRANSFER UNIT (PTU) - INSTALLATION»(ref-348644-S11385904092009112700000)

Scheme 10

Scheme 10: 4X4 CONTROL MODULE REMOVAL/INSTALLATION
Scheme 10: 4X4 CONTROL MODULE REMOVAL/INSTALLATION
  1. Remove the floor console. See «FLOOR CONSOLE REMOVAL/INSTALLATION»(ref-348677-S26690194032009112700000) .
  2. Disconnect the electrical connector.
  3. Lift upward on the module to release the fasteners from the shifter base. Remove the 4X4 control module.
  4. To install, reverse the removal procedure.

Note. This procedure applies to vehicles equipped with automatic transaxles.

  1. Remove the power transfer unit (PTU) rear output shaft flange. See «OUTPUT FLANGE REMOVAL/INSTALLATION»(ref-348644-S22442659242009112700000) .
  2. Remove the deflector.
  3. Using a suitable tool, remove the PTU output shaft oil seal.

Scheme 11

Scheme 11: Installation
Scheme 11: Installation
  1. Using the PTO Drive Gear Outer Oil Seal Installer, install the PTU rear output shaft oil (pinion) seal.
  2. Install the deflector.
  3. Install the PTU rear output shaft flange. See «OUTPUT FLANGE REMOVAL/INSTALLATION»(ref-348644-S22442659242009112700000) .

Note. This procedure applies to vehicles equipped with automatic transaxles.

Scheme 12

Scheme 12: Removal
Scheme 12: Removal

Scheme 13

Scheme 13
Scheme 13
  1. Remove the driveshaft. See «DRIVESHAFT REMOVAL/INSTALLATION»(ref-348678-S15469676532009112700000) .
  2. Using the Drive Pinion Flange Holding Fixture to hold the flange, remove the pinion nut. CAUTION: Rotational torque of the power transfer unit (PTU) rear output shaft flange must be measured and recorded using a N.m {kgf.m, in.lbf} torque wrench for correct pinion bearing preload when reassembled.
  3. Using the Steering Wheel Remover, remove the PTU rear output shaft flange. NOTE: Index-mark the PTU rear output shaft flange relative to the pinion spline.
  1. Install the PTU rear output shaft flange to engage the spline as previously marked. Install the PTU rear output shaft flange.
  2. Using the Drive Pinion Flange Holding Fixture, install the pinion nut. CAUTION: Do not overtighten the pinion nut. Refer to the rotational torque previously recorded with a N.m {kgf.m, in.lbf} torque wrench. Overtightening the pinion nut will damage the collapsible spacer. CAUTION: If the rotational torque is less than specification, tighten the drive pinion nut in small increments until it is within specification. Do not tighten the drive pinion nut more than 3 N.m {0.3 kgf.m, 27 in.lbf} at a time or the collapsible spacer will be damaged. If the rotation torque is higher than specification, the collapsible spacer has been compressed too far and a new collapsible spacer must be installed.
  3. Install the driveshaft. See «DRIVESHAFT REMOVAL/INSTALLATION»(ref-348678-S15469676532009112700000) .

Note. This procedure applies to vehicles equipped with manual transaxles.

  1. Remove the power transfer unit (PTU). See «POWER TRANSFER UNIT (PTU) - INSTALLATION»(ref-348644-S11385904092009112700000) .
  2. Using a Slide Hammer with a 3-Jaw Puller Attachment, remove the PTU tube.

Scheme 14

Scheme 14: Installation
Scheme 14: Installation
  1. Inspect the condition of the PTU vent hole. By hand, insert the new PTU vent into the PTU cover and measure the distance between the PTU cover and the vent as indicated. If the measurement is less than specification, install a new PTU.

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Apply a bead of silicone gasket and sealant to the PTU vent where indicated. CAUTION: Do not apply silicone sealant to the PTU vent hole as it may cause damage to the PTU internal components.
  2. Using the special tool, install the PTU vent. NOTE: Drive the PTU vent in until the special tool bottoms out against the PTU rear cover boss.
  3. Measure the depth of the PTU vent. If the vent is too high, repeat Step 3 .
  4. Install the PTU vent boot. CAUTION: Make sure the PTU vent boot is correctly aligned or damage to the components may occur. NOTE: Use a soapy water solution to lubricate the PTU breather boot.
  5. Install the PTU. See «POWER TRANSFER UNIT (PTU) - INSTALLATION»(ref-348644-S11385904092009112700000) .

More articles — Transfer - Tribute Except Hybrid
