COMPONENT TEST - STARTER
| WARNING | Always disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury. |
Note. Be sure to disconnect the battery ground cable before repairing the starter motor.
Connect the 73111 Automotive Meter at the component terminal rather than at the wiring end connector. Making a connection at the wiring end connector could result in false readings because the meter will not pick up a high resistance between the wiring connector and the component.
Scheme 1
- Make sure the battery is fully charged. Carry out a battery load test. See «PINPOINT TEST 6: THE GENERATOR IS NOISY»(ref-348627-S09300662482009112700000) .
- Connect a remote starter switch between the starter solenoid S-terminal and the battery positive (+) terminal.
- Connect the 73III Automotive Meter positive lead to the battery positive (+) post. Connect the negative lead to the M-terminal.
- Engage the remote starter switch. Read and record the voltage. The voltage reading should be 0.8 volt or less.
- If the voltage reading is 0.8 volt or less, go to the «STARTER MOTOR - GROUND CIRCUIT COMPONENT TEST»(ref-348666-S25403566912009112700000) .
- If the voltage reading is greater than 0.8 volt, this is an indication of excessive resistance in the connections, the positive battery cable or in the starter solenoid. Move the 73III Automotive Meter negative lead to the starter solenoid B-terminal and repeat the test. If the voltage reading at the B-terminal is lower than 0.8 volt, the concern is either in the connections at the starter solenoid or in the solenoid contacts.
- Remove the cables from solenoid B-, S- and M-terminals. Clean the cables and connections and reinstall the cables to the correct terminals. Repeat Steps 3 through 6 . If the voltage drop reading is still greater than 0.8 volt when checked at the M-terminal and less than 0.8 volt when checked at the B-terminal, the concern is in the solenoid contacts. Install a new starter motor.
- If the voltage reading taken at the solenoid B-terminal is still greater than 0.8 volt after cleaning the cables and the connections at the solenoid, the concern is either in the positive (+) battery cable connection or in the positive battery cable itself. Clean the positive (+) battery cable connection. If this does not solve the problem, install a new positive battery cable. See «BATTERY CABLES REMOVAL/INSTALLATION - 2.5L»(ref-348661-S26898308542009112700000) or «BATTERY CABLES REMOVAL/INSTALLATION - 3.0L»(ref-348661-S28943864182009112700000) .
