Assembly Note Mazda Tribute I facelift

Assembly Note

Note. If a seat equipped with a seat-mounted side air bag system is being repaired the air bag system must be deactivated per the deactivation procedure contained in AIR BAG RESTRAINT SYSTEMS article of the appropriate car/truck service manual.

Note. Restraint system diagnostic tools must be installed under the seats in the side air bag to floor connector.

Note. Diagnostics or repairs are not to be carried out on a side air bag system or a safety belt pretensioner (if equipped) with the seat in the vehicle. Prior to attempting to diagnose/repair the side air bag system or a safety belt pretensioner (if equipped) the seat must be removed from the vehicle and the restraint system diagnostic tool must be installed in side air bag connector at the floor connector. The restraint system diagnostic tool must be removed prior to operating the vehicle.

Note. Diagnostics may be carried out on seat systems other than the side air bag system or a safety belt pretensioner (if equipped) (lumbar, climate controlled, heated, power seat track) with the seat installed in the vehicle as long as the restraint system diagnostic tool is installed under the seat in the side air bag to floor connector.

Note. After diagnosing/repairing a seat system the restraint system diagnostic tool must be removed before operating the vehicle.

Note. A repair is made by installing a new part only. If a new part is installed and the new part does not correct the condition, install the original part and carry out the diagnostic procedure again.

Note. If a side air bag deployment took place, a new seatback pad, trim cover, and side air bag module must be installed. A new seatback frame should be installed if necessary.

Vehicles with side air bag

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

1. Install the side air bag module. Install the side air bag module. Install the nuts.
2. Route the side air bag module wire harness. Install the locators to the seat backrest frame. All Vehicles
3. Install the front backrest rest pad to the front backseat rest frame.
4. Install the front seat backrest trim cover.
5. Connect the front seat backrest J-retainer.
6. If equipped, install the headrest guides and headrest.
7. Install the front seat backrest. Install the backrest. Install the pivot nut.
8. Install the front seat backrest bolts, if equipped with heated seats, connect the backrest heated grid electrical connector.
9. Install the inboard seat cushion side shield.
10. Install the outboard seat cushion side shield. Install the shield, if equipped with a power/heated seat, connect the electrical connector(s). Install the screw. Install the seat backrest lever handle.
11. If equipped, install the seat height adjustment control. CAUTION: Use care when handling the seat and track assembly. Dropping the assembly or sitting on a seat not secured in the vehicle may result in damaged components.
12. Install the driver seat. Position the driver seat, if equipped with power seats, connect the electrical connector. Install the seat track to floor bolts.
13. If equipped with power seats, connect the battery ground cable. Refer to BATTERY DISCONNECT .
14. Position the driver seat forward.
15. Install the seat track to floor nuts.
16. If equipped with power seats, disconnect the battery ground cable and wait one minute. Refer to BATTERY DISCONNECT . Vehicles with side air bag WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
17. Remove the special tool from the driver seat side air bag module body harness electrical connector.
18. Connect the driver seat side air bag module electrical connector. All vehicles WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
19. Remove the special tool from the driver seat safety belt pretensioner body harness electrical connector.
20. Connect the driver seat safety belt pretensioner electrical connector.
21. Connect the battery ground cable. Refer to BATTERY DISCONNECT .
22. With the remaining special tools still in place, prove out the air bag system. Refer to «SYSTEM OPERATION CHECK»(ref-170347-S38220482782005011000000) .
23. Disconnect the battery ground cable and wait at least one minute. Refer to BATTERY DISCONNECT . WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
24. Remove the special tool from the passenger-side safety belt pretensioner body harness electrical connector.
25. Connect the passenger seat safety belt pretensioner electrical connector. Vehicles with side air bag WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
26. Remove the special tool from the passenger seat side air bag module body harness electrical connector.
27. Connect the passenger seat side air bag module electrical connector. All vehicles WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
28. Remove the special tool to the instrument panel harness side of the passenger air bag module electrical connector.
29. Connect the passenger air bag module electrical connector.
30. Raise the glove compartment. Press the locking tabs. WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
31. Remove the special tool from the steering column harness side of the driver air bag module electrical connector.
32. Connect the driver air bag module electrical connector.
33. Install the driver air bag connector access cover.
34. Connect the battery ground cable. Refer to BATTERY DISCONNECT .
35. Prove out the air bag system. Refer to «SYSTEM OPERATION CHECK»(ref-170347-S38220482782005011000000) .
36. Check the restraint system for correct operation.

Note. Restraint system diagnostic tools must be installed under the seats in the side air bag to floor connector.

Note. Diagnostics or repairs are not to be carried out on a side air bag system or a safety belt preten-sioner (if equipped) with the seat in the vehicle. Prior to attempting to diagnose/repair the side air bag system or a safety belt pretensioner (if equipped) the seat must be removed from the vehicle and the restraint system diagnostic tool must be installed in side air bag connector at the floor connector. The restraint system diagnostic tool must be removed prior to operating the vehicle.

Note. Diagnostics may be carried out on seat systems other than the side air bag system or a safety belt pretensioner (if equipped) (lumbar, climate controlled, heated, power seat track) with the seat installed in the vehicle as long as the restraint system diagnostic tool is installed under the seat in the side air bag to floor connector.

Note. After diagnosing/repairing a seat system the restraint system diagnostic tool must be removed before operating the vehicle.

Note. A repair is made by installing a new part only. If a new part is installed and the new part does not correct the condition, install the original part and carry out the diagnostic procedure again.

Note. If a side air bag deployment took place, a new seatback pad, trim cover, and side air bag module must be installed. A new seatback frame should be installed if necessary.

Note. Manual seat shown, power seat similar.

All vehicles

Scheme 304

Scheme 305

Scheme 306

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

1. Position the front seats forward.
2. Disconnect the battery ground cable and wait at least one minute. Refer to BATTERY DISCONNECT . Vehicles with side air bag
3. Disconnect the driver seat side air bag module electrical connector.
4. Connect the special tool to the driver seat side air bag module body harness electrical connector. All vehicles
5. Disconnect the driver seat safety belt pretensioner electrical connector.
6. Connect the special tool to the driver seat safety belt pretensioner body harness electrical connector.
7. Disconnect the passenger seat safety belt pretensioner electrical connector.
8. Connect the special tool to the passenger seat safety belt pretensioner body harness electrical connector. Vehicles with side air bag
9. Disconnect the passenger seat side air bag module electrical connector.
10. Connect the special tool to the passenger seat side air bag module body harness electrical connector. All vehicles
11. Lower the glove compartment. Press the locking tabs.
12. Disconnect the passenger air bag module electrical connector.
13. Connect the special tool to the instrument panel harness side of the passenger air bag module electrical connector.
14. Lower the driver air bag connector access cover.
15. Disconnect the driver air bag module electrical connector.
16. Connect the special tool to the steering column harness side of the driver air bag module electrical connector.
17. Connect the battery ground cable. Refer to BATTERY DISCONNECT .
18. Prove out the air bag system. Refer to «SYSTEM OPERATION CHECK»(ref-170347-S38220482782005011000000) article.
19. Remove the seat track to floor nuts.
20. Position the driver seat rearward.
21. If equipped with power seats, disconnect the negative battery cable. Refer to BATTERY DISCONNECT . CAUTION: Use care when handling the seat and track assembly. Dropping the assembly or sitting on a seat not secured in the vehicle may result in damaged components.
22. Remove the driver seat. Remove the seat track to floor bolts. Remove the driver seat, if equipped with power seats, disconnect the electrical connector.
23. Disconnect the seat cushion trim cover J-clips.
24. Remove the front seat cushion trim and pad from the front seat cushion frame. If equipped with heated seats, disconnect the backrest heated grid and the seat cushion heated grid electrical connectors.
25. Separate the front seat cushion trim from the front seat cushion pad.

Note. Restraint system diagnostic tools must be installed under the seats in the side air bag to floor connector.

Note. Diagnostics or repairs are not to be carried out on a side air bag system or a safety belt pretensioner (if equipped) with the seat in the vehicle. Prior to attempting to diagnose/repair the side air bag system or a safety belt pretensioner (if equipped) the seat must be removed from the vehicle and the restraint system diagnostic tool must be installed in side air bag connector at the floor connector. The restraint system diagnostic tool must be removed prior to operating the vehicle.

Note. Diagnostics may be carried out on seat systems other than the side air bag system or a safety belt pretensioner (if equipped) (lumbar, climate controlled, heated, power seat track) with the seat installed in the vehicle as long as the restraint system diagnostic tool is installed under the seat in the side air bag to floor connector.

Note. After diagnosing/repairing a seat system the restraint system diagnostic tool must be removed before operating the vehicle.

Note. A repair is made by installing a new part only. If a new part is installed and the new part does not correct the condition, install the original part and carry out the diagnostic procedure again.

Note. If a side air bag deployment took place, a new seatback pad, trim cover, and side air bag module must be installed. A new seatback frame should be installed if necessary.

All vehicles

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

Scheme 337

1. Install the front seat cushion trim to the front seat cushion pad.
2. Install the front seat cushion trim and pad to the front seat cushion frame. If equipped with heated seats, connect the backrest heated grid and the seat cushion heated grid electrical connectors.
3. Connect the seat cushion trim cover J-clips. CAUTION: Use care when handling the seat and track assembly. Dropping the assembly or sitting on a seat not secured in the vehicle may result in damaged components.
4. Install the driver seat. Position the driver seat, if equipped with power seats, connect the electrical connector. Install the seat track to floor bolts.
5. If equipped with power seats, connect the battery ground cable. Refer to BATTERY DISCONNECT .
6. Position the driver seat forward.
7. Install the seat track to floor nuts.
8. If equipped with power seats, disconnect the battery ground cable and wait one minute. Refer BATTERY DISCONNECT . Vehicles with side air bag WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
9. Remove the special tool from the driver seat side air bag module body harness electrical connector.
10. Connect the driver seat side air bag module electrical connector. All vehicles WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
11. Remove the special tool from the driver-side safety belt pretensioner body harness electrical connector.
12. Connect the driver seat safety belt pretensioner electrical connector.
13. Connect the battery ground cable. Refer to BATTERY DISCONNECT .
14. With the remaining special tools still in place, prove out the air bag system. Refer to «SYSTEM OPERATION CHECK»(ref-170347-S38220482782005011000000) .
15. Disconnect the battery ground cable and wait at least one minute. Refer to BATTERY DISCONNECT . WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
16. Remove the special tool from the passenger seat safety belt pretensioner body harness electrical connector.
17. Connect the passenger seat safety belt pretensioner electrical connector. Vehicles with side air bag WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
18. Remove the special tool from the passenger seat side air bag module body harness electrical connector.
19. Connect the passenger seat side air bag module electrical connector. All vehicles WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
20. Remove the special tool to the instrument panel harness side of the passenger air bag module electrical connector.
21. Connect the passenger air bag module electrical connector.
22. Raise the glove compartment. Press the locking tabs. WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
23. Remove the special tool from the steering column harness side of the driver air bag module electrical connector.
24. Connect the driver air bag module electrical connector.
25. Install the driver air bag connector access cover.
26. Connect the battery ground cable. Refer to BATTERY DISCONNECT .
27. Prove out the air bag system. Refer to «SYSTEM OPERATION CHECK»(ref-170347-S38220482782005011000000) .
28. Check the restraint system for correct operation.

Note. If a seat equipped with a seat-mounted side air bag system is being repaired the air bag system must be deactivated per the deactivation procedure contained in AIR BAG RESTRAINT SYSTEMS article of the appropriate workshop manual.

Note. Restraint system diagnostic tools must be installed under the seats in the side air bag to floor connector.

Note. Diagnostics or repairs are not to be carried out on a side air bag system or a safety belt pretensioner (if equipped) with the seat in the vehicle. Prior to attempting to diagnose/repair the side air bag system or a safety belt pretensioner (if equipped) the seat must be removed from the vehicle and the restraint system diagnostic tool must be installed in side air bag connector at the floor connector. The restraint system diagnostic tool must be removed prior to operating the vehicle.

Note. Diagnostics may be carried out on seat systems other than the side air bag system or a safety belt pretensioner (if equipped) (lumbar, climate controlled, heated, power seat track) with the seat installed in the vehicle as long as the restraint system diagnostic tool is installed under the seat in the side air bag to floor connector.

Note. After diagnosing/repairing a seat system the restraint system diagnostic tool must be removed before operating the vehicle.

Note. A repair is made by installing a new part only. If a new part is installed and the new part does not correct the condition, install the original part and carry out the diagnostic procedure again.

Note. If a side air bag deployment took place, a new seatback pad, trim cover, and side air bag module must be installed. A new seatback frame should be installed if necessary.

All vehicles

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

Scheme 352

Scheme 353

Scheme 354

1. Position the front seats forward.
2. Disconnect the battery ground cable and wait at least one minute. Refer to BATTERY DISCONNECT . Vehicles with side air bag
3. Disconnect the passenger seat side air bag module electrical connector.
4. Connect the special tool to the passenger seat side air bag module body harness electrical connector. All vehicles
5. Disconnect the passenger seat safety belt pretensioner electrical connector.
6. Connect the special tool to the passenger seat safety belt pretensioner body harness electrical connector.
7. Disconnect the driver seat safety belt pretensioner electrical connector.
8. Connect the special tool to the driver-side seat safety belt pretensioner body harness electrical connector. Vehicles with side air bag
9. Disconnect the driver seat side air bag module electrical connector.
10. Connect the special tool to the driver seat side air bag module body harness electrical connector. All vehicles
11. Lower the driver air bag connector access cover.
12. Disconnect the driver air bag module electrical connector.
13. Connect the special tool to the steering column harness side of the driver air bag module electrical connector.
14. Lower the glove compartment. Press the locking tabs.
15. Disconnect the passenger air bag module electrical connector.
16. Connect the special tool to the instrument panel harness side of the passenger air bag module electrical connector.
17. Connect the battery ground cable. Refer to BATTERY DISCONNECT .
18. Prove out the air bag system. Refer to «SYSTEM OPERATION CHECK»(ref-170347-S38220482782005011000000) .
19. Remove the seat track to floor nuts.
20. Position the passenger seat rearward. CAUTION: Use care when handling the seat and track assembly. Dropping the assembly or sitting on a seat not secured in the vehicle may result in damaged components.
21. Remove the passenger seat. Remove the seat track to floor bolts. Remove the passenger seat, if equipped with heated seats, disconnect the electrical connector.
22. Disconnect the seat cushion trim cover J-clips.
23. Remove the front seat cushion trim and pad from the front seat cushion frame. If equipped with heated seats, disconnect the backrest heated grid and the seat cushion heated grid electrical connectors.
24. Separate the front seat cushion trim from the front seat cushion pad.

Note. If a seat equipped with a seat-mounted side air bag system is being repaired the air bag system must be deactivated per the deactivation procedure contained in AIR BAG RESTRAINT SYSTEMS article of the appropriate workshop manual.

Note. Restraint system diagnostic tools must be installed under the seats in the side air bag to floor connector.

Note. Diagnostics or repairs are not to be carried out on a side air bag system or a safety belt pretensioner (if equipped) with the seat in the vehicle. Prior to attempting to diagnose/repair the side air bag system or a safety belt pretensioner (if equipped) the seat must be removed from the vehicle and the restraint system diagnostic tool must be installed in side air bag connector at the floor connector. The restraint system diagnostic tool must be removed prior to operating the vehicle.

Note. Diagnostics may be carried out on seat systems other than the side air bag system or a safety belt pretensioner (if equipped) (lumbar, climate controlled, heated, power seat track) with the seat installed in the vehicle as long as the restraint system diagnostic tool is installed under the seat in the side air bag to floor connector.

Note. After diagnosing/repairing a seat system the restraint system diagnostic tool must be removed before operating the vehicle.

Note. A repair is made by installing a new part only. If a new part is installed and the new part does not correct the condition, install the original part and carry out the diagnostic procedure again.

Note. If a side air bag deployment took place, a new seatback pad, trim cover, and side air bag module must be installed. A new seatback frame should be installed if necessary.

All vehicles

Scheme 355

Scheme 356

Scheme 357

Scheme 358

Scheme 359

Scheme 360

Scheme 361

Scheme 362

Scheme 363

Scheme 364

Scheme 365

Scheme 366

Scheme 367

Scheme 368

Scheme 369

Scheme 370

Scheme 371

1. Install the front seat cushion trim to the front seat cushion pad.
2. Install the front seat cushion trim and pad to the front seat cushion frame. If equipped with heated seats, connect the backrest heated grid and the seat cushion heated grid electrical connectors.
3. Connect the seat cushion trim cover J-clips. CAUTION: Use care when handling the seat and track assembly. Dropping the assembly or sitting on a seat not secured in the vehicle may result in damaged components.
4. Install the passenger seat. Position the passenger seat, if equipped with power seats, connect the electrical connector. Install the seat track to floor bolts.
5. Position the passenger seat forward.
6. Install the seat track to floor nuts.
7. Disconnect the battery ground cable and wait at least one minute. Refer to BATTERY DISCONNECT . Vehicles with side air bag WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
8. Remove the special tool from the passenger seat side air bag module body harness electrical connector.
9. Connect the passenger seat air bag module electrical connector. All vehicles WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
10. Remove the special tool from the passenger seat safety belt pretensioner body harness electrical connector.
11. Connect the passenger seat safety belt pretensioner electrical connector.
12. Connect the battery ground cable. Refer to BATTERY DISCONNECT .
13. With the remaining special tools still in place, prove out the air bag system. Refer to «SYSTEM OPERATION CHECK»(ref-170347-S38220482782005011000000) .
14. Disconnect the battery ground cable and wait at least one minute. Refer to BATTERY DISCONNECT . WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
15. Remove the special tool from the driver seat safety belt pretensioner body harness electrical connector.
16. Connect the driver seat safety belt pretensioner electrical connector. Vehicles with side air bag WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
17. Remove the special tool from the driver seat side air bag module body harness electrical connector.
18. Connect the driver seat side air bag module electrical connector. All vehicles WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
19. Remove the special tool from the steering column harness side of the driver air bag module electrical connector.
20. Connect the driver air bag module electrical connector.
21. Install the driver air bag connector access cover. WARNING: The restraint system diagnostic tool is for restraint system repair only. Remove from vehicle prior to road use. Failure to remove could result in injury and possible violation of vehicle safety standards.
22. Remove the special tool to the instrument panel harness side of the passenger air bag module electrical connector.
23. Connect the passenger air bag module electrical connector.
24. Raise the glove compartment. Press the locking tabs.
25. Connect the battery ground cable. Refer to BATTERY DISCONNECT .
26. Prove out the air bag system. Refer to «SYSTEM OPERATION CHECK»(ref-170347-S38220482782005011000000) .
27. Check the restraint system for correct operation.
