Lighting Systems: Removal & Installation Mazda Tribute I рестайлинг

Removal and Installation

Note. Make sure that the headlamp switch and the ignition switch are in the OFF position.

Scheme 7

1. Remove the front bumper cover. See «FRONT BUMPER COVER»(ref-221971-S10314968712006022600000) . NOTE: Pull headlamp assembly forward to access electrical connectors.
2. Remove the headlamp assembly. Remove the three bolts. Loosen the nut. Disconnect the electrical connectors.
3. To install, reverse the removal procedure. If necessary, adjust the headlamps. See «HEADLAMP ADJUSTMENT - PHOTOMETRIC AIMING»(ref-221992-S35654040342006022600000) or «HEADLAMP ADJUSTMENT - SCREEN METHOD AIMING»(ref-221992-S23475561642006022600000) .

Note. Make sure that the headlamp switch and the ignition switch are in the OFF position.

Scheme 8

1. Remove the rear cover.
2. Disconnect the electrical connector.
3. Remove the bulb.
4. To install, reverse the removal procedure.

1. Remove the Headlamp Assembly. See «HEADLAMP ASSEMBLY»(ref-221992-S14096991692006022600000) .
2. Remove the lamp socket from the lamp assembly.
3. Remove the bulb.
4. To install, reverse the removal procedure.

Scheme 9

Scheme 10

1. Remove the wheel and tire. See «WHEEL AND TIRE»(ref-221854-S28618994392006022600000) .
2. Position the inner fender well aside. Remove the bolts. Remove the pin-type retainers. Remove the screw. Position the inner fender well aside.
3. Remove the lamp socket from the lamp assembly.
4. Disconnect the bulb from the electrical connector.
5. To install, reverse the removal procedure.

Scheme 11

Scheme 12

Scheme 13

1. Remove the license plate lamp assembly. Push the license lamp to the right and pull out.
2. Disconnect the socket from the lens and remove the bulb.
3. To install, reverse the removal procedure.

Scheme 14

1. Remove the rear lamp assembly. Remove the bolts. Using a flat tipped screwdriver covered with a rag, gently pry the lamp from the edge of the quarter panel at the bottom portion, and then the top portion. Disconnect the electrical connectors.
2. To install, reverse the removal procedure.

Scheme 15

Scheme 16

Scheme 17

1. Remove the high-mounted stoplamp assembly and discard the screws and washers.
2. Remove the high-mounted stoplamp bulb holder from the lamp assembly by disengaging the snaps.
3. Remove the bulb(s).
4. To install, reverse the removal procedure.

Scheme 18

Scheme 19

1. Remove the brake pedal position (BPP) switch. Disconnect the electrical connector. Rotate clockwise and remove the BPP switch.

Installation

Note. Initial installation of brake pedal position (BPP) switch allows for one adjustment. If additional adjustments are necessary, install a new switch.

Scheme 20

Scheme 21

1. To unlock, rotate the lock knob counterclockwise to the stop.
2. With the engine running, fully depress and hold the brake pedal.
3. Install the brake pedal position (BPP) switch. Position the BPP switch in the bracket and rotate counterclockwise. Connect the electrical connector.
4. Slowly release the brake pedal.

Scheme 22

Scheme 23

Scheme 24

1. Disconnect the battery ground cable. See «BATTERY DISCONNECT»(ref-221834-S42533501902006022600000) . CAUTION: Do not use a screwdriver to remove fog lamp switch or damage to the finish panel may occur. Adding tape to the end of a thin tool will reduce marring to the finish panel.
2. Use a thin tool to remove the fog lamp switch.
3. Disconnect the electrical connector.
4. To install, reverse the removal procedure.

1. Disconnect the battery ground cable. See «BATTERY DISCONNECT»(ref-221834-S42533501902006022600000) .
2. Position the instrument panel center finish panel aside.
3. Disconnect the electrical connector.
4. Release the spring clips and remove the hazard flasher switch.
5. To install, reverse the removal procedure.
