Interior Trim: Removal & Installation Mazda Tribute I рестайлинг

Removal and Installation

Note. Inspect the safety belt D-ring cover for damage. If the safety belt D-ring cover does not remain in place, install a new cover.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Remove the safety belt D-ring cover.
2. Remove the safety belt D-ring bolt.
3. Position the front and rear door weatherstrips aside.
4. Remove the upper B-pillar trim panel.
5. Remove the front door scuff plate trim panel. Remove the pin-type retainers. Remove the front door scuff plate trim panel.
6. Remove the rear door scuff plate trim panel. Remove the pin-type retainers. Remove the rear door scuff plate trim panel.
7. Remove the lower B-pillar trim panel.
8. To install, reverse the removal procedure.

Note. Inspect the safety belt D-ring cover for damage. If the safety belt D-ring cover does not remain in place, install a new cover.

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Remove the safety belt D-ring cover.
2. Remove the safety belt D-ring bolt.
3. Remove the pin-type retainers and the liftgate scuff plate trim panel.
4. Position the liftgate weatherstrip aside.
5. If equipped, remove the cargo net hold-down.
6. Remove the rear quarter trim panel. Insert a tape-wrapped screwdriver between the D-pillar trim panel and rear quarter trim panel. Push the screwdriver in the direction of the arrow and remove the rear quarter trim panel.
7. Remove the C-pillar trim panel.
8. To install, reverse the removal procedure.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. Disconnect the battery. For additional information, See «BATTERY DISCONNECT»(ref-221834-S42533501902006022600000) .
2. Remove the overhead console. Open the front console door. Remove the screws. Remove the overhead console. If equipped, disconnect the electrical connector.
3. Remove the two sun visors and two clips. Remove the six screws. Remove the two sun visors and two clips. If equipped, disconnect the electrical connector.
4. Remove the eight passenger assist handle covers.
5. Remove the four passenger assist handles. Remove the eight bolts. Remove the four passenger assist handles.
6. Open the four A-pillar passenger assist handle covers.
7. Remove the two A-pillar passenger assist handles. Remove the four bolts. Remove the two A-pillar passenger assist handles.
8. Remove the two windshield side garnish moldings.
9. If equipped, remove the roof opening panel moulding. NOTE: Inspect the safety belt D-ring cover for damage. If the safety belt D-ring cover does not remain in place, install a new cover.
10. Remove the safety belt D-ring covers.
11. Remove the safety belt D-ring bolts.
12. Position the front and rear door weatherstrips aside.
13. Remove the upper B-pillar trim panels. Attached with clips.
14. Remove the two C-pillar trim panels. See «C-PILLAR TRIM PANEL»(ref-221990-S33147367742006022600000) .
15. Remove the two D-pillar trim panels. Attached with clips.
16. Remove the front interior lamp lens by prying with a screwdriver.
17. Remove the front interior lamp. Remove the screws. Disconnect the electrical connector, and remove the front interior lamp.
18. Remove the rear interior lamp by prying with a screwdriver. Disconnect the electrical connector.
19. Remove the five pin-type retainers.
20. If equipped, remove the three child seat tether anchor covers.
21. If equipped, remove the three bolts and the child seat tether anchors.
22. Remove the headliner. CAUTION: If equipped, do not disconnect the delete resistor during headliner removal.
23. If equipped, cut and remove the lanyard between the delete resistor and the headliner. NOTE: The headliner retainer should meet at the rear of the roof opening and have no gaps or overlaps.
24. To install, reverse the removal procedure.
