Brake Shoe Adjustment (With Drum On)

Note. Information is not available from manufacturer for adjustment of the brake shoe with drum on.

Brake Shoe Adjustment (With Drum Off)

1. Remove the brake drum. See «REAR BRAKE DRUM»(ref-163516-S25633163602004070100000) under REMOVAL & INSTALLATION.
2. Using Brake Adjustment Gauge (206-0002), measure the inside diameter of the brake drum. (Scheme 1)
3. Position the brake adjustment gauge on the brake shoes and linings and adjust accordingly. (Scheme 2)
4. Install the brake drum.
