Interior Trim: Removal & Installation Mazda Tribute I

Exterior/interior Trim 39 illustrations ~692 words

Removal and Installation

Vehicles with power windows

Scheme 1

Scheme 1: Removal and Installation

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4
  1. Disconnect the battery ground cable. Vehicles with manual windows
  2. Remove the front door manual window regulator handle. Release the clip. Remove the front door manual window regulator handle. All vehicles
  3. Remove the front door latch release handle bezel. Remove the screw. Remove the front door latch release handle bezel.
  4. Remove the door handle cup screw.
  5. Remove the front door trim panel. Remove the screws. Remove the front door trim panel and disconnect the electrical connector (vehicles with power windows only).
  6. To install, reverse the removal procedure.

Vehicles with manual windows

Scheme 5

Scheme 5: Removal and Installation

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9
  1. Remove the rear door manual window regulator handle. Release the clip. Remove the rear door manual window regulator handle. All vehicles
  2. Remove the rear door latch release handle bezel. Remove the screw. Remove the rear door latch release handle bezel.
  3. Remove the door handle cup screw.
  4. Remove the rear door sail panel.
  5. Remove the rear door trim panel. Disconnect the electrical connector (vehicles with power windows only).
  6. To install, reverse the removal procedure.
WARNINGIf the side air bag sensor is subjected to shock or the sensor is disassembled, the side air bag module may operate (deploy) suddenly and cause injury, or it may fail to operate normally and cause a serious accident. Do not subject the side air bag sensor to shock or disassemble the sensor.

Disconnect the battery ground cable and wait at least one minute.

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15
  1. Remove the safety belt D-ring cover.
  2. Remove the safety belt D-ring bolt.
  3. Position the front and rear door weatherstrips aside.
  4. Remove the upper B-pillar trim panel.
  5. Remove the front door scuff plate trim panel. Remove the pin-type retainers. Remove the front door scuff plate trim panel.
  6. Remove the rear door scuff plate trim panel. Remove the pin-type retainers. Remove the rear door scuff plate trim panel.
  7. Remove the lower B-pillar trim panel.
  8. To install, reverse the removal procedure.

LH side

Scheme 16

Scheme 16: Removal and Installation

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22
  1. If equipped with a power point on the LH quarter trim panel, disconnect the battery ground cable. Both sides
  2. Remove the safety belt D-ring cover.
  3. Remove the safety belt D-ring bolt.
  4. Remove the pin-type retainers and the liftgate scuff plate trim panel.
  5. Position the liftgate weatherstrip aside.
  6. If equipped, remove the cargo net hold-down.
  7. Remove the rear quarter trim panel. Insert a tape-wrapped screwdriver between the D-pillar trim panel and rear quarter trim panel. Push the screwdriver in the direction of the arrow and remove the rear quarter trim panel.
  8. Disconnect the accessory socket connector. (Left side)
  9. Remove the C-pillar trim panel.
  10. To install, reverse the removal procedure.

Vehicles with overhead console

Scheme 23

Scheme 23: Removal and Installation

Scheme 24

Scheme 24

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39
  1. Remove the overhead console. Open the front console door. Remove the screws. Remove the overhead console. If equipped, disconnect the electrical connector.
  2. Remove the two sun visors and two clips. Remove the six screws. Remove the two sun visors and two clips.
  3. Remove the eight passenger assist handle covers.
  4. Remove the four passenger assist handles. Remove the eight bolts. Remove the four passenger assist handles.
  5. Open the four A-pillar passenger assist handle covers.
  6. Remove the two A-pillar passenger assist handles. Remove the four bolts. Remove the two A-pillar passenger assist handles.
  7. Remove the two windshield side garnish mouldings.
  8. If equipped, remove the roof opening panel moulding.
  9. Remove the safety belt D-ring covers.
  10. Remove the safety belt D-ring bolts.
  11. Position the front and rear door weather-strips aside.
  12. Remove the upper B-pillar trim panels. Attached with clips.
  13. Remove the two C-pillar trim panels. For additional information, refer to «C-PILLAR TRIM PANEL»(ref-171754-S12881167812005021100000) .
  14. Remove the two D-pillar trim panels. Attached with clips.
  15. Remove the front interior lamp lens by prying with a screwdriver.
  16. Remove the front interior lamp. Remove the screws. Remove the front interior lamp. Disconnect the electrical connector.
  17. Remove rear interior lamp by prying with a screwdriver. Disconnect the electrical connector.
  18. Remove the five pin-type retainers.
  19. If equipped, remove the three child seat tether anchor covers.
  20. If equipped, remove the three bolts and the child seat tether anchors.
  21. Remove the headliner.
  22. To install, reverse the removal procedure.
