CONSOLE - OVERHEAD

The overhead console consists of the following components

1. garage door opener compartment (without roof opening panel)
2. lamp switch
3. roof opening panel control switch (with roof opening panel)
4. sun glass compartment
5. map lamps

CONSOLE - FLOOR

The high series floor console consists of the following components

1. arm rest
2. floor console finish panel
3. rear cup holders
4. storage compartment

The low series floor console consists of the following components

1. floor console front finish panel
2. floor console rear finish panel

Scheme 40

Scheme 41

Scheme 42

1. Remove the floor console finish panel. Apply the parking brake. Remove the floor console finish panel.
2. Remove the floor console front bolts.
3. Remove the floor console. Remove the two rear bolts. Remove the floor console.
4. To install, reverse the removal procedure.

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Remove the floor console front finish panel. If equipped, remove the manual transaxle shifter knob by turning counterclockwise. Remove the floor console front finish panel.
2. Remove the floor console rear finish panel. Apply the parking brake. Remove the floor console rear finish panel.
3. Remove the floor console front bolts.
4. Remove the floor console. Remove the rear two bolts. Remove the floor console.
5. To install, reverse the removal procedure.
