Washer System & Wiper System: Removal & Installation Mazda RX-8 I рестайлинг

HEADLIGHT CLEANER NOZZLE INSTALLATION

1. Install the headlight cleaner nozzle by pushing it in until a click is heard.

Scheme 28

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-367651-S16887864132010072700000) .)
3. Disconnect joint pipe.
4. Disconnect headlight cleaner hose from the headlight cleaner actuator.
5. Remove the headlight cleaner hose from the front bumper.
6. Install in the reverse order of removal.

Scheme 29

Scheme 30

1. Attach the center mark area of the head light cleaner hose to the center clip of the mesh grill.
2. Install the headlight cleaner hose as shown in the figure.

Scheme 31

1. Disconnect the negative battery cable.
2. Disconnect the connector.
3. Remove the nuts, then remove the headlight cleaner relay.
4. Install in the reverse order of removal.

Scheme 32

1. Remove the headlight cleaner relay with the connector still connected.
2. Measure the voltage at each terminal (other than terminal F.) If the voltage is not as specified in the Terminal Voltage Table (Reference), inspect the parts under "Inspection item(s)".
3. Disconnect the negative battery cable.
4. Verify that continuity at terminal F is as indicated in the Terminal Voltage Table (Reference.) If there is any malfunction, inspect the parts under "Inspection item(s)". If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the headlight cleaner relay. Terminal Voltage Table (Reference) TERMINAL VOLTAGE CONTINUITY CHART Terminal Signal name Connected to Measured condition Voltage (V)/ Continuity Inspection item(s) A Headlight cleaner motor output Headlight cleaner motor Headlight cleaner activated (auto-operation or manual operation activated) Alternates between 1.0 or less and B+ Headlight relay (See «RELAY INSPECTION»(ref-367627-S03580534092010072700000) .) Windshield wiper and washer switch (See «WINDSHIELD WIPER AND WASHER SWITCH INSPECTION»(ref-367673-S16865546552010072700000) .) Headlight cleaner motor (See «HEADLIGHT CLEANER MOTOR INSPECTION»(ref-367673-S11819163472010072700000) .) Related wiring harnesses Except above B+ D Windshield washer motor output Windshield wiper and washer switch Turn the ignition switch to the ON position. Turn the washer switch to the OFF position. 1.0 or less Headlight relay (See «RELAY INSPECTION»(ref-367627-S03580534092010072700000) .) Windshield wiper and washer switch (See «WINDSHIELD WIPER AND WASHER SWITCH INSPECTION»(ref-367673-S16865546552010072700000) .) Related wiring harnesses Turn the washer switch to the ON position. B+ E Headlight Headlight relay Light switch at ON position. B+ Headlight relay (See «RELAY INSPECTION»(ref-367627-S03580534092010072700000) .) Related wiring harnesses Except above 1.0 or less F GND Body ground Under any condition: Inspect for continuity to ground. Continuity detected GND Related wiring harnesses

RAIN SENSOR REMOVAL/INSTALLATION

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Disconnect the negative battery cable.
2. Insert the fastener remover wrapped with protective tape into the notch of the rain sensor cover. Then disconnect the tab A by turning the fastener remover in the direction of the arrow.
3. Remove the rain sensor cover in the direction of the arrow A.
4. Disconnect the rain sensor connector.
5. Slide the tab B in the direction of the arrow and disconnect it while supporting the rain sensor with your hand.
6. Un-install the rain sensor in the direction of the arrow.
7. Install in the reverse order of removal.
