Sunroof: Overview Mazda RX-8 I рестайлинг

Scheme 1

Scheme 2

1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, then remove the glass panel.
4. Remove the weatherstrip from the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-367683-S15928833342010072700000) .)

Scheme 3

Scheme 4

Scheme 5

1. Fully close the glass panel.
2. Measure the gap and height difference between the glass panel and the body.
3. Loosen the glass panel installation screws and move the glass panel to adjust. Standard clearance a: 0.2-2.2 mm {0.008-0.086 in} b: 0.2-2.2 mm {0.008-0.086 in} c: 0.25-2.25 mm {0.01-0.09 in} d: 0 mm {0 in}
4. Tighten the screws.
5. Insert any available thin plastic card between the weatherstrip and the body, and verify that they are sealed. (There is resistance when the plastic card is moved.) If they are not sealed, perform Steps 3-4 and adjust again.

Scheme 6

Scheme 7

Scheme 8

1. Disconnect the negative battery cable.
2. Remove the following parts: Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S04721282182010072700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S39687945372010072700000) ) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) ) Inner scuff plate (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-367665-S23986903362010072700000) .) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-367665-S33165249612010072700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-367662-S27590118272010072700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-367662-S01058807002010072700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-367662-S30030225222010072700000) .) Head impact pad (See «HEAD IMPACT PAD REMOVAL/INSTALLATION»(ref-367662-S11003152242010072700000) .) Glass panel (See «GLASS PANEL REMOVAL/INSTALLATION»(ref-367683-S20231972552010072700000) .)
3. Disconnect the front and rear drain hoses from the sunroof frame.
4. Remove the bolts from curtain air bag module points A.
5. Remove the bolt, then remove the bracket.
6. Remove the rear door striker (upper.)
7. Remove the rear set bracket.
8. Remove the nuts and screws, then remove the sunroof unit.
9. Install in the reverse order of removal.
10. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-367683-S15928833342010072700000) .)

Scheme 9

1. Remove the glass panel. (See «GLASS PANEL REMOVAL/INSTALLATION»(ref-367683-S20231972552010072700000) .)
2. Disassemble in the order indicated in the table.
3. Assemble in the reverse order of disassembly.

Scheme 10

Note. If the guide is removed, initial position setting of the sunroof motor will be required. After installing the sunroof unit, perform initial position setting using the following procedure.

1. Press the CLOSE switch to fully close the glass panel.
2. When the glass panel reaches the fully closed position, temporarily release the CLOSE switch and press it again for approx. 13 s continuously. Continue pressing the switch until the glass panel automatically stops at the fully closed position after reaching the mechanical lock position.
3. When the glass panel stops at the fully closed position, temporarily release the CLOSE switch, then press it again within 5 s and hold. NOTE: Press the CLOSE switch continuously until the glass panel opens to the fully open position, returns to the fully closed position and then stops.
4. Release the CLOSE switch when the glass panel stops at the fully closed position.
