FRONT COMBINATION LIGHT REMOVAL/INSTALLATION

Scheme 12

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-367651-S16887864132010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-367665-S17646484842010072700000) )

Scheme 13

1. Disconnect the negative battery cable.
2. Remove the fasteners, then slightly bend back the front mudguard
3. Disconnect the connector. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
4. Remove the cover.
5. Remove the socket, then remove the headlight bulb.
6. Install in the reverse order of removal.

Headlight Leveling Actuator Removal Note

1. Loosen the adjusting bolt until the headlight leveling actuator can be rotated
2. Rotate the headlight leveling actuator to the position shown in the figure.
3. Loosen the adjusting bolt further and remove the headlight leveling actuator.

Scheme 14

Scheme 15

1. Disconnect the negative battery cable.
2. Remove the fasteners, then slightly bend back the front mudguard.
3. Disconnect the connector.
4. Remove the socket, then remove the front turn light bulb.
5. Install in the reverse order of removal.

Scheme 16

Scheme 17

1. Disconnect the negative battery cable.
2. Remove the front fog light cover.
3. Remove the screws.
4. Hold the back surface of the front fog light and lift it up as shown in the left diagram. Then arc the front fog light as pull it out from the vehicle body with care not to contact the oil cooler.
5. Disconnect the connector.
6. Install in the reverse order of removal.
7. Adjust the front fog light aiming. (See «FRONT FOG LIGHT AIMING»(ref-367665-S00336090032010072700000) .)

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Point the front fog lights to a wall and verify that the front fog lights are as shown in the figure.
2. Make a front fog light adjustment screen as shown in the figure using double-weight, white paper.
3. Adjust the tire pressure to the specification.
4. Position the unloaded vehicle on a flat, level surface.
5. Seat one person in the driver's seat.
6. Line up the front fog lights with the white screen at a distance of 3 m {9.8 ft} apart.
7. Measure the height of the center of the fog light (the center of the fog light bulb.) NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the front fog light using the actual vehicle.
8. Adjust the center of the adjustment screen to the point 681.7 mm {26.84 in} from the center of the vehicle and the measured height in the direction the headlight points, then affix the screen to the wall.
9. Start the engine so that the battery remains charged.
10. Turn the front fog lights on.
11. Place a partition screen in front of the fog light not being adjusted to block its light beam.
12. Verify that the brightness border line of the front fog light is at the position indicated on the adjustment screen. If the brightness border line is not at the position indicated on the adjustment screen, perform the following adjustment. Turn up the mudguard. Loosen the adjusting bolt and the screw. Move the front fog light in the direction of the arrow shown in the figure to adjust the brightness border line to the position indicated on the adjustment screen. Install the adjusting bolt and tighten the screw.

Scheme 24

1. Disconnect the negative battery cable.
2. Remove the front fog light. (See «FRONT FOG LIGHT REMOVAL/INSTALLATION»(ref-367665-S16173885432010072700000) .)
3. Disconnect the connector.
4. Remove the front fog light bulb by turning it in the direction of the arrow. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When handling the bulb, hold the flange, not the glass.
5. Install in the reverse order of removal.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Disconnect the negative battery cable.
2. Push the front side turn light in the direction of the arrow (1) and pull it out.
3. Turn the front side turn light in the direction of the arrow (2.)
4. Disconnect the connector.
5. Install in the reverse order of removal.

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-367662-S26442568612010072700000) .)
3. Remove the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S24296380552010072700000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-367662-S37640661352010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

LICENSE PLATE LIGHT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-367662-S26442568612010072700000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S24296380552010072700000) .) Rear combination light (See «REAR COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-367665-S07524712172010072700000) .) Request switch (Vehicles with the advanced keyless system) (See «REQUEST SWITCH REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS SYSTEM]»(ref-367649-S17078753722010072700000) .) Detach the license plate light from the rear bumper. Rear bumper (See «REAR BUMPER REMOVAL/INSTALLATION»(ref-367651-S27414068492010072700000) .)
3. Disconnect the license plate light connector and remove the license plate light.
4. Install in the reverse order of removal.

Scheme 31

LICENSE PLATE LIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the lens, then remove the license plate light bulb.
3. Install in the reverse order of removal.

Scheme 32

FRONT AUTO LEVELING SENSOR REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Jack up the vehicle and remove the wheel and tire.
3. Disconnect the connector.
4. Remove the bolts and then remove the front auto leveling sensor.
5. Install in the reverse order of removal.

Scheme 33

Scheme 34

Scheme 35

1. Connect three 1.5 V dry cell batteries in a series.
2. Connect the positive pole of the battery to auto leveling sensor terminal A, and the negative pole to terminal C, then apply voltage of 4.5 V between terminals A and C.
3. Connect the tester as shown in the figure.
4. Verify that the voltage fluctuates linearly in the 0.5 to 4.1 V range while the links are moved up and down slowly. If not indicated in the graph, replace the front auto leveling sensor.

REAR AUTO LEVELING SENSOR REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Jack up the vehicle and remove the wheel and tire.
3. Disconnect the connector.
4. Remove the bolts and nut, then remove the rear auto leveling sensor.
5. Install in the reverse order of removal.

Scheme 36

Scheme 37

Scheme 38

1. Connect three 1.5 V dry cell batteries in a series.
2. Connect the positive pole of the battery to auto leveling sensor terminal A, and the negative pole to terminal D, then apply voltage of 4.5 V between terminals A and D.
3. Connect the tester as shown in the figure.
4. Verify that the voltage fluctuates linearly in the 0.5 to 4.1 V range while the links are moved up and down slowly. If not indicated in the graph, replace the rear auto leveling sensor.

AUTO LEVELING CONTROL MODULE REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Disconnect the connector.
3. Remove the screw and then remove the auto leveling control module.
4. Install in the reverse order of removal.

Scheme 39

Scheme 40

1. Disconnect the negative battery cable.
2. Remove the transmission. (See «TRANSMISSION REMOVAL/INSTALLATION [P66M-D]»(ref-367635-S07700204162010072700000) .)
3. Install in the reverse order of removal.

Scheme 41

Scheme 42

1. Disconnect the back-up light switch connector.
2. Verify that the continuity between the back-up light switch terminals is as indicated in the table. If not as indicated in the table, replace the back-up light switch.

COMBINATION SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-367666-S06928677742010072700000) .) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-367652-S39447008962010072700000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-367662-S39346719792010072700000) .) Ignition key illumination (Vehicles with keyless entry system) (See «IGNITION KEY ILLUMINATION BULB REMOVAL/INSTALLATION»(ref-367665-S11023766142010072700000) .) Clock spring (See «CLOCK SPRING REMOVAL/INSTALLATION»(ref-367666-S00889993362010072700000) .)
3. Disconnect the connector.
4. Disconnect the steering angle sensor connector. (Vehicles with DSC)
5. Remove the screws and then remove the combination switch.
6. Install in the reverse order of removal.
7. Perform the steering angle sensor initialization procedure. (Vehicles with DSC) (See «STEERING ANGLE SENSOR INITIALIZATION PROCEDURE»(ref-367629-S28414488552010072700000) )

Scheme 43

LIGHT SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-367662-S39346719792010072700000) .)
3. Remove the ignition key illumination. (Vehicles with keyless entry system) (See «IGNITION KEY ILLUMINATION BULB REMOVAL/INSTALLATION»(ref-367665-S11023766142010072700000) .)
4. Disconnect the connector.
5. Remove the screws and then remove the light switch.
6. Install in the reverse order of removal.

Scheme 44

HAZARD WARNING SWITCH REMOVAL/INSTALLATION

Scheme 45

1. Disconnect the negative battery cable.
2. Remove the following parts: Shift lever knob (MT) (See «TRANSMISSION REMOVAL/INSTALLATION [P66M-D]»(ref-367635-S07700204162010072700000) .) Shift knob (AT) (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-367663-S27891068622010072700000) .) Console panel (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Ashtray panel (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-367662-S00557200222010072700000) .) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-367632-S21389676612010072700000) .) Speaker grille (See «SPEAKER GRILLE REMOVAL/INSTALLATION»(ref-367662-S30339958912010072700000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-367662-S08814802452010072700000) .)
3. Remove the screw.
4. Remove the hazard switch knob.
5. Remove the hazard switch.
6. Install in the reverse order of removal.

FLASHER CONTROL MODULE REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Disconnect the connector.
3. Remove the screw and then remove the flasher control module.
4. Install in the reverse order of removal.

Scheme 46

MAP LIGHT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the screws.
3. Remove the map light. (See «MAP LIGHT REMOVAL NOTE»(ref-367665-S04063401242010072700000) .)
4. Disconnect the connector.
5. Remove the socket, then remove the map light bulb.
6. Install in the reverse order of removal.

Scheme 47

Map Light Removal Note

1. Insert a tape-wrapped flathead screwdriver into the gap between the headliner and the map light.
2. Press the tab, and remove the map light.

Scheme 48

Scheme 49

Scheme 50

1. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-367665-S23986903362010072700000) .)
2. Verify that the continuity between the map light terminals is as indicated in the table. If not as indicated in the table, replace the map light.

INTERIOR LIGHT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the lens. (See «LENS REMOVAL NOTE»(ref-367665-S19563647832010072700000) .)
3. Remove the interior light bulb.
4. Remove the interior light. (See «INTERIOR LIGHT REMOVAL NOTE»(ref-367665-S25735847892010072700000) .)
5. Disconnect the connector.
6. Install in the reverse order of removal.

Scheme 51

Scheme 52

1. Insert a tape-wrapped flathead screwdriver into the gap between the headliner and the interior light.
2. Press the tab, and remove the interior light.

Scheme 53

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 54

Scheme 55

1. Remove the interior light. (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-367665-S33165249612010072700000) .)
2. Verify that the continuity between the interior light terminals is as indicated in the table. If not as indicated in the table, replace the interior light.

Scheme 56

1. Disconnect the negative battery cable.
2. Remove the lens, then remove the trunk compartment light bulb.
3. Install in the reverse order of removal.

COURTESY LIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the lens, then remove the courtesy light bulb.
3. Install in the reverse order of removal.

Scheme 57

ASHTRAY ILLUMINATION BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the ashtray panel. (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .)
3. Remove the socket, then remove the ashtray illumination bulb.
4. Install in the reverse order of removal.

Scheme 58

GLOVE COMPARTMENT LIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the socket, then remove the glove compartment light bulb.
3. Install in the reverse order of removal.

Scheme 59

Scheme 60

Scheme 61

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Remove the vanity mirror illumination bulb.
4. Install in the reverse order of removal.

PANEL LIGHT CONTROL SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the panel light control switch. (See «PANEL LIGHT CONTROL SWITCH REMOVAL NOTE»(ref-367665-S33239375672010072700000) .)
3. Disconnect the connector.
4. Install in the reverse order of removal.

Scheme 62

Panel Light Control Switch Removal Note

1. Reach into the dashboard through the underside of the lower panel and, while pushing on the tabs of the panel light control switch, pull it outward.

DOOR SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the screw.
3. Disconnect the connector and remove the door switch.
4. Install in the reverse order of removal.

Scheme 63

Scheme 64

Scheme 65

1. Remove the door switch. (See «DOOR SWITCH REMOVAL/INSTALLATION»(ref-367665-S17966395492010072700000) .)
2. Verify that the continuity between door switch terminal and the body ground is as indicated in the table. If not as indicated in the table, replace the door switch.
