STARTER REMOVAL/INSTALLATION [13B-MSP]

Scheme 4

1. Remove the engine cover. (See «ENGINE COVER REMOVAL/INSTALLATION [13B-MSP]»(ref-367623-S37771794152010072700000) .)
2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [13B-MSP]»(ref-367630-S30865077932010072700000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal. AT

Scheme 5

Starter Installation Note (AT)

Note. If there is peeling on or damage to the insulator, attach a new insulator using the following procedure

Scheme 6

Scheme 7

1. Peel off the insulator from the starter completely using a scraper.
2. Degrease the insulator attachment area.
3. Attach a new insulator to the starter.

Scheme 8

On-Vehicle Inspection

1. Verify that the battery is fully charged.
2. The starter is normal if it rotates smoothly and without any noise when the engine is cranked. If the starter does not operate, inspect the following: Remove the starter, and inspect the starter unit. Inspect the related wiring harnesses, the ignition switch, and the transmission range switch (AT.)

Scheme 9

1. Verify that the battery is fully charged.
2. Connect the starter, battery, and a tester as shown in the figure.
3. Operate the starter and verify that it rotates smoothly. If the starter does not rotate smoothly, inspect the starter unit.
4. Measure the voltage and current while the starter is operating. If not within the specification, replace the starter. Starter no-load test voltage 11 V Starter no-load test current 120 A or less

Pull-Out Test

Note. Depending on the battery charge condition, the starter motor pinion may rotate while in an extended state. This is due to current flowing to the starter motor through the pull-in coil to turn the starter motor, and does not indicate an abnormality.

Scheme 10

1. Verify that the starter motor pinion is extended while battery positive voltage is connected to terminal S and the starter body is grounded. If the starter motor pinion is not extended, repair or replace the starter.

Scheme 11

1. Disconnect the motor wire from terminal M.
2. Connect battery positive voltage to terminal M and ground the starter body.
3. Pull out the drive pinion with a screwdriver. Verify that it returns to its original position when released. If it does not return, repair or replace the starter.

Scheme 12

1. Pull out the drive pinion with the battery positive voltage connected to terminal S and the starter body grounded. CAUTION: Applying power for more than 10 s can damage the starter. Do not apply power for more than 10 s.
2. Measure the pinion gap while the drive pinion is extended. If not as specified, adjust with an adjustment washer (between drive housing front cover and magnetic switch.) Starter pinion gap AT: 0 mm {0 in} MT: 0.5-2.0 mm {0.02-0.07 in}

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Verify that there is no continuity between the commutator and the core at each segment using a tester. If there is continuity, replace the armature.
2. Verify that there is no continuity between the commutator and the shaft using a tester. If there is continuity, replace the armature.
3. Place the armature on V-blocks, and measure the runout using a dial indicator. If not within the specification, replace the armature. Starter armature runout 0.1 mm {0.004 in} max.
4. Measure the commutator diameter. If not within the minimum specification, replace the armature. Starter commutator diameter Standard: 29.4 mm {1.16 in} Minimum: 28.8 mm {1.13 in}
5. Measure the segment groove depth of the commutator. If not within the minimum specification, undercut the grooves to the standard depth. Segment groove depth of starter commutator Standard: 0.5 mm {0.020 in} Minimum: 0.2 mm {0.008 in}

Scheme 18

Scheme 19

Scheme 20

1. Inspect for continuity between terminals S and M using a tester. If there is no continuity, replace the magnetic switch.
2. Inspect for continuity between terminal S and the body using a tester. If there is no continuity, replace the magnetic switch.
3. Verify that there is no continuity between terminals M and B using a tester. If there is continuity, replace the magnetic switch.

Scheme 21

Scheme 22

Scheme 23

1. Verify that there is no continuity between each insulated brush and plate using a tester. If there is continuity, replace the brush holder.
2. Measure the brush length. If any brush is worn almost to or beyond the minimum specification, replace all of the brushes. Starter brush length Standard: 17.6 mm {0.69 in} Minimum: 10.0 mm {0.39 in}
3. Measure the brush spring force using a spring balance. If not within the minimum specification, replace the brush and brush holder component. Starter brush spring force Standard: 23.4-31.6 N {2.39-3.22 kgf, 5.26-7.10 lbf} Minimum: 10.0 N {1.02 kgf, 2.25 lbf}
