Entertainment System: Removal & Installation Mazda RX-8 I рестайлинг

CENTER PANEL UNIT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Shift lever knob (MT) (See «TRANSMISSION REMOVAL/INSTALLATION [P66M-D]»(ref-367635-S07700204162010072700000) .) Shift knob (AT) (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-367663-S27891068622010072700000) .) Upper panel (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Ashtray panel (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-367662-S00557200222010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 6

Scheme 7

Center Panel Unit Removal Note

1. Detach the clips from the dashboard while pulling the center panel unit outward, and then remove the center panel unit.

Scheme 8

Scheme 9

Front door speaker installation note

1. Installation the speaker with the wiring harness passing through the groove of the front door unit.

Scheme 10

Scheme 11

1. Disconnect the negative battery cable.
2. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-367662-S11282007462010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

FRONT TWEETER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-367662-S37909175562010072700000) .)
3. Remove the screws.
4. Remove the front tweeter.
5. Install in the reverse order of removal.

Scheme 12

Scheme 13

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-367662-S37909175562010072700000) .)
3. Remove the front tweeter. (See «FRONT TWEETER REMOVAL/INSTALLATION»(ref-367632-S11358170122010072700000) .)
4. Verify the resistance between front tweeter terminals. If the continuity is as indicated in the table, replace the front tweeter. Resistance 3.8 ohms

Scheme 14

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Rear package side trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 15

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Rear package side trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .) Rear tweeter (See «REAR TWEETER REMOVAL/INSTALLATION»(ref-367632-S32967436892010072700000) .)
3. Verify the resistance between rear tweeter terminals. If the continuity is as indicated in the table, replace the rear tweeter. Resistance 3.8 ohms

Scheme 16

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Rear package side trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .) Rear package center trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

AM/FM ANTENNA FEEDER N0.1 INSTALLATION

Note. The antenna feeder is integrated with the vehicle wiring harness. When installing a new antenna feeder, secure it to the vehicle wiring harness along the installation route of the old antenna feeder.

Scheme 17

1. Disconnect the negative battery cable.
2. Remove the following parts: Shift lever knob (MT) (See «TRANSMISSION REMOVAL/INSTALLATION [P66M-D]»(ref-367635-S07700204162010072700000) .) Shift knob (AT) (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-367663-S27891068622010072700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-367662-S24199587722010072700000) .) Inner scuff plate (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S03575028422010072700000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-367662-S32092558042010072700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-367662-S00557200222010072700000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-367662-S39346719792010072700000) .) Steering shaft installation nut (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-367652-S39447008962010072700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S39687945372010072700000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-367662-S15841994732010072700000) .)
3. Align and secure the new AM/FM antenna feeder No. 1 to the vehicle wiring harness.

Scheme 18

Scheme 19

1. Disconnect the negative battery cable.
2. Remove the following parts: Shift lever knob (MT) (See «TRANSMISSION REMOVAL/INSTALLATION [P66M-D]»(ref-367635-S07700204162010072700000) .) Shift knob (AT) (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-367663-S27891068622010072700000) .) Upper panel (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Ashtray panel (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-367662-S00557200222010072700000) .) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-367632-S21389676612010072700000) .) Inner scuff plate (LH) (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Front side trim (LH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S03575028422010072700000) .)
3. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the AM/FM antenna feeder No. 1.

AM/FM ANTENNA FEEDER NO. 2 INSTALLATION

Note. The antenna feeder is integrated with the vehicle wiring harness. When installing a new antenna feeder, secure it to the vehicle wiring harness along the installation route of the old antenna feeder.

Scheme 20

Scheme 21

1. Disconnect the negative battery cable.
2. Remove the following parts: Sunroof seaming welt (with sunroof) Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S04721282182010072700000) .) Inner scuff plate (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S03575028422010072700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S39687945372010072700000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-367665-S23986903362010072700000) .) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-367665-S33165249612010072700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-367662-S27590118272010072700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-367662-S01058807002010072700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-367662-S30030225222010072700000) .)
3. Align and secure the new AM/FM antenna feeder No. 2 to the vehicle wiring harness.

Scheme 22

Scheme 23

1. Disconnect the negative battery cable.
2. Remove the following parts: Inner scuff plate (LH) (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Front side trim (LH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S03575028422010072700000) .) Rear seat (LH) (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Tire house trim (LH) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (LH) (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .)
3. Remove the fasteners, then slightly bend back the headliner.
4. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the AM/FM antenna feeder No. 2.

SIRIUS SATELLITE RADIO ANTENNA FEEDER INSTALLATION

Note. The antenna feeder is integrated with the vehicle wiring harness. When installing a new antenna feeder, secure it to the vehicle wiring harness along the installation route of the old antenna feeder.

1. Disconnect the negative battery cable.
2. Remove the following parts: Sunroof seaming welt (with sunroof) Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S04721282182010072700000) .) Inner scuff plate (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S03575028422010072700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S39687945372010072700000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-367665-S23986903362010072700000) .) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-367665-S33165249612010072700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-367662-S27590118272010072700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-367662-S01058807002010072700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-367662-S30030225222010072700000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-367662-S26442568612010072700000) .) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S24296380552010072700000) .)
3. Align and secure the new SIRIUS satellite radio antenna feeder to the vehicle wiring harness.

Scheme 24

Scheme 25

Scheme 26

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Inner scuff plate (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-367662-S26442568612010072700000) .) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S24296380552010072700000) .)
3. Remove the fasteners, then slightly bend back the headliner.
4. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the SIRIUS satellite radio antenna feeder.

GPS ANTENNA REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-367662-S24199587722010072700000) .) Inner scuff plate (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S03575028422010072700000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-367662-S32092558042010072700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-367662-S00557200222010072700000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-367662-S39346719792010072700000) .) Steering shaft installation nut (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-367652-S39447008962010072700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S39687945372010072700000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-367662-S15841994732010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 27

AUDIO CONTROL SWITCH REMOVAL/INSTALLATION

Note. For vehicles with the cruise control system, the audio control switch harness and the cruise control switch harness are united, therefore they cannot be separated.

1. Disconnect the negative battery cable and wait for 1 min or more.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-367666-S06928677742010072700000) .)
3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-367652-S39447008962010072700000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Disconnect the negative battery cable and wait for 1 min or more.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-367666-S06928677742010072700000) .)
3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-367652-S39447008962010072700000) .)
4. Verify the resistance and continuity between the audio control switch terminals. If the resistance and continuity are not as indicated in the tables, replace the audio control switch.
5. Apply battery positive voltage to audio control switch terminal E, and connect terminal D to ground.
6. Verify that the LED illuminates. If the LED does not illuminate, replace the audio control switch.

Scheme 32

1. Disconnect the negative battery cable.
2. Remove the speaker grille. (See «SPEAKER GRILLE REMOVAL/INSTALLATION»(ref-367662-S30339958912010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 33

1. Disconnect the negative battery cable.
2. Remove the rear console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 34

1. Disconnect the negative battery cable.
2. Remove the hole cover. (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Accessory Socket Removal Note

1. Remove the accessory socket in the direction of the arrow (2) shown in the figure while opening the caps in the direction of the arrow (1) using a tape-wrapped fastener remover.

Scheme 35

Cap Removal Note

1. Remove the cap in the direction of the arrow (2) shown in the figure while pressing the cap tabs in the direction of the arrow (1.)

Scheme 36

Scheme 37

1. Disconnect the negative battery cable.
2. Remove the hole cover. (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .)
3. Connect a tester as shown in the figure and verify that there is continuity. If the continuity cannot be verified, replace the accessory socket.

AUXILIARY JACK REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the hole cover. (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .)
3. Remove the auxiliary jack in the direction of the arrow (2) shown in the figure while pressing the auxiliary jack tabs in the direction of the arrow (1.)
4. Install in the reverse order of removal.

Scheme 38

Scheme 39

Scheme 40

1. Disconnect the negative battery cable.
2. Remove the hole cover. (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .)
3. Connect a commercially-available nonresistant plug to the auxiliary jack.
4. Verify that the continuity between the auxiliary jack terminals is as indicated in the table. If not as indicated in the table, replace the auxiliary jack.

Scheme 41

1. Disconnect the negative battery cable.
2. Remove the ashtray. (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Socket Removal Note

1. Remove the socket in the direction of the arrow (2) shown in the figure while opening the rings in the direction of the arrow (1) using a tape-wrapped fastener remover.

Scheme 42

Ring Removal Note

1. Remove the ring in the direction of the arrow (2) shown in the figure while pressing the ring tabs in the direction of the arrow (1.)

Scheme 43

Scheme 44

1. Turn the ignition switch to the ACC position.
2. Press the cigarette lighter into the socket and verify that it returns to its original position in 10-20 s. If the cigarette lighter does not operate normally, replace the cigarette lighter and the socket.
