Entertainment System: Other Mazda RX-8 I рестайлинг

With Audio Unit

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Scheme 46

With Car-navigation Unit

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Scheme 47

Scheme 48

1. Disconnect the negative battery cable.
2. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Rear package side trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .) Rear package center trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 49

1. Disconnect the negative battery cable.
2. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-367662-S11282007462010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

With Bose®

1. If the resistance is not within the specification, replace the front door speaker.

Resistance

Without Bose®: 4 ohms

With Bose®: 2 ohms

Scheme 50

Scheme 51

1. Disconnect the negative battery cable.
2. Remove the speaker grille. (See «SPEAKER GRILLE REMOVAL/INSTALLATION»(ref-367662-S30339958912010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 52

1. Disconnect the negative battery cable.
2. Remove the speaker grille. (See «SPEAKER GRILLE REMOVAL/INSTALLATION»(ref-367662-S30339958912010072700000) .)
3. Remove the center speaker. (See «CENTER SPEAKER REMOVAL/INSTALLATION»(ref-367632-S14357911602010072700000) .)
4. Verify the resistance between center speaker terminals. If the resistance is not within the specification, replace the center speaker. Resistance 3.6 ohms

Scheme 53

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Rear package side trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .) Rear package center trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 54

1. Disconnect the negative battery cable.
2. Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Rear package side trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .) Rear package center trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-367662-S29446939012010072700000) .) Rear speaker (See «REAR SPEAKER REMOVAL/INSTALLATION»(ref-367632-S24535453152010072700000) .)
3. Verify the resistance between rear speaker terminals. If the resistance is not within the specification, replace the rear speaker. Resistance Without Bose®: 4 ohms With Bose®: 1.8 ohms

SIRIUS Satellite Radio Software Version Verification

1. Displays the SIRIUS satellite radio software version on the information display.

Scheme 55

Memory function

1. The memory function converts a malfunction detected by the malfunction detection function to a DTC and stores it. The error currently occurring is stored as a present malfunction. Up to three DTCs (with audio unit), or six (with car-navigation unit) can be stored as a present malfunction. The error that has previously occurred is stored as a past malfunction. Up to three DTCs (with audio unit), or six (with car-navigation unit) can be stored as a past malfunction. The DTCs, together with the number of times the ignition switch has been turned off after the occurrence of an error (maximum of 255 times), are stored as a past malfunction.

Display Function With Audio Unit

1. When the self-diagnostic function is activated, the information display displays the DTC stored in the memory.
2. The DTC consists of the following codes and numbers

1. Malfunction type
2. Number of times the ignition switch has been turned off after the occurrence of an error
3. Device code
4. Error code

1. Go to the appropriate service information for the display method.

Scheme 56

1. When the self-diagnostic function is activated, the displays the DTC stored in the memory.
2. The DTC consists of the following codes and numbers

Error history display screen

1. Error items
2. Current malfunction
3. Number of times the ignition switch has been turned off after the occurrence of an error
4. Detail Switch

Detail display screen

1. Device code
2. Error code
3. Check content
4. Number of times present/past malfunction has occurred

1. Go to the appropriate service information for the display method.

1. (7) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .)
2. (8) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .)
3. (9) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-367665-S23986903362010072700000) .)
4. (10) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-367665-S33165249612010072700000) .)
5. (11) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-367662-S27590118272010072700000) .)
6. (12) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-367662-S01058807002010072700000) .)
7. (13) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-367662-S30030225222010072700000) .)

Scheme 57

1. 3. Remove in the order indicated in the table.
2. 4. Install in the reverse order of removal.

Scheme 58

Scheme 59

1. Disconnect the negative battery cable.
2. Remove the following parts: Sunroof seaming welt (with sunroof) Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S04721282182010072700000) .) Inner scuff plate (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S03575028422010072700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S39687945372010072700000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Rear pillar trim (See «REAR PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S36729400152010072700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-367665-S23986903362010072700000) .) Interior light (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-367665-S33165249612010072700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-367662-S27590118272010072700000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-367662-S01058807002010072700000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-367662-S30030225222010072700000) .) SIRIUS satellite radio antenna (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-367632-S23934266222010072700000) .)
3. Verify that there is no continuity between the SIRIUS satellite radio antenna terminals A and C using an ohmmeter.
4. Inspect for continuity between the SIRIUS satellite radio antenna terminals using an ohmmeter. If not as indicated in the table, replace the SIRIUS satellite radio antenna.

Scheme 60

Scheme 61

1. Inspect the glass antenna for damage.
2. Verify the continuity between the glass antenna terminals. If there is any malfunction, repair the glass antenna. (See «FILAMENT REPAIR»(ref-367667-S00217135302010072700000) .)

Scheme 62

1. Disconnect the negative battery cable.
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-367662-S26442568612010072700000) .)
3. Remove the trunk side trim. (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S24296380552010072700000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
