Washer System & Wiper System: Removal & Installation Mazda RX-8 I

HEADLIGHT CLEANER NOZZLE INSTALLATION

1. Install the headlight cleaner nozzle by pushing it in until a click is heard.

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the front side marker light. (See «FRONT SIDE MARKER LIGHT REMOVAL/INSTALLATION»(ref-178404-S29368030062005061500000) .)
3. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-178300-S00403827762005061400000) .)
4. Remove the headlight cleaner nozzle. (See «HEADLIGHT CLEANER NOZZLE REMOVAL»(ref-178405-S03527937522005061500000) and «HEADLIGHT CLEANER NOZZLE INSTALLATION»(ref-178405-S02860718762005061500000) .)
5. Squeeze the clip tabs and slide the clip in the direction of the arrow.
6. Disconnect headlight cleaner hose from the headlight cleaner actuator.
7. Remove the screw, then remove the headlight cleaner actuator.
8. Install in the reverse order of removal.

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the front side marker light. (See «FRONT SIDE MARKER LIGHT REMOVAL/INSTALLATION»(ref-178404-S29368030062005061500000) .)
3. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-178300-S00403827762005061400000) .)
4. Disconnect joint pipe.
5. Disconnect headlight cleaner hose from the headlight cleaner actuator.
6. Remove the headlight cleaner hose from the front bumper.
7. Install in the reverse order of removal.

Scheme 31

1. Disconnect the negative battery cable.
2. Disconnect the connector.
3. Remove the nuts, then remove the headlight cleaner relay.
4. Install in the reverse order of removal.
