Screw Installation Note
- After installation of the screws, verify that the MAF/IAT sensor is installed securely.
ECCENTRIC SHAFT POSITION SENSOR REMOVAL/INSTALLATION
| CAUTION | When replacing the eccentric shaft position sensor, make sure there is no foreign material on it such as metal shavings. If it is installed with foreign material, the sensor output signal will malfunction resulting from fluctuation in magnetic flux and cause a deterioration in engine control. |
Scheme 520
- Disconnect the eccentric shaft position sensor connector.
- Remove the eccentric shaft position sensor installation bolt and remove the eccentric shaft position sensor.
- Install in the reverse order of removal. Eccentric shaft position sensor tightening torque 7.9-10.7 N.m {80-110 kgf.cm, 69-95 in.lbf}
Scheme 521
Scheme 521: ECCENTRIC SHAFT POSITION PLATE INSPECTION
- Verify that there are no cracks, damage, or corrosion on the projecting parts of the eccentric shaft position plate. If there are cracks, damage, or corrosion on the projecting parts, replace the eccentric shaft position plate. (See «ECCENTRIC SHAFT POSITION PLATE REMOVAL/INSTALLATION»(ref-221640-S00873382702006022500000) .)
ECCENTRIC SHAFT POSITION PLATE REMOVAL/INSTALLATION
| CAUTION | To allow the PCM to identify that the eccentric shaft position plate has been replaced, pump the brake pedal 20 times within 8 s after the ignition switch is turn to the ON position (engine off). |
Scheme 522
- Remove the drive belt referring to the drive belt replacement. (See «DRIVE BELT REPLACEMENT»(ref-221532-S36770145582006022500000) .)
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
