COMBINATION SWITCH DISASSEMBLY/ASSEMBLY
| CAUTION | For vehicles with DSC: If the disc on the combination switch is deformed or has foreign material adhering to it, performance of the steering angle sensor may be reduced, causing abnormal operation. When handling the combination switch, be careful not to deform the disc and make sure there is no foreign material on it. |
Scheme 60
Scheme 61
- Disassemble in the order indicated. (Scheme 60)
- Assemble in the reverse order of disassembly.
Scheme 62
Scheme 62: FRONT FOG LIGHT SWITCH INSPECTION
Scheme 63
- Remove the column cover. (See COLUMN COVER REMOVAL/INSTALLATION.)
- Remove the ignition key illumination. (See «IGNITION KEY ILLUMINATION BULB REMOVAL/INSTALLATION»(ref-178404-S09354952382005061500000).)
- Remove the light switch. (See «LIGHT SWITCH REMOVAL/INSTALLATION»(ref-178404-S08197472842005061500000).)
- Verify that the continuity between the light switch terminals is as indicated. (Scheme 62) If not as indicated. replace the light switch.
Scheme 64
Scheme 64: HAZARD WARNING SWITCH INSPECTION
Scheme 65
- Remove the console. (See CONSOLE REMOVAL/INSTALLATION .)
- Remove the lower panel. (See LOWER PANEL REMOVAL/INSTALLATION .)
- Remove the center panel module. (See CENTER PANEL MODULE REMOVAL/INSTALLATION .)
- Verify continuity between the hazard switch terminals.
- If not as indicated, replace the center panel.
Scheme 66
Scheme 66: HEADLIGHT LEVELING SWITCH REMOVAL/INSTALLATION
- Disconnect the negative battery cable.
- Remove the headlight leveling switch. (See «HEADLIGHT LEVELING SWITCH REMOVAL NOTE»(ref-178404-S19864074722005061500000) .)
- Disconnect the connector.
- Install in the reverse order of removal.
