Lighting Systems: Diagnosis Mazda RX-8 I

LIGHT SWITCH INSPECTION

1. Remove the column cover. (See COLUMN COVER REMOVAL/INSTALLATION .)
2. Remove the ignition key illumination. (See «IGNITION KEY ILLUMINATION BULB REMOVAL/INSTALLATION»(ref-178404-S09354952382005061500000) .)
3. Remove the light switch. (See «LIGHT SWITCH REMOVAL/INSTALLATION»(ref-178404-S08197472842005061500000) .)
4. Verify that the continuity between the light switch terminals is as indicated.

Scheme 5

Scheme 6

1. If not as indicated, replace the light switch.

Scheme 7

Scheme 8

Scheme 9

1. Disconnect the negative battery cable.
2. Disconnect the connector.
3. Remove the screw and then remove the flasher control module.
4. Install in the reverse order of removal.

FLASHER CONTROL MODULE INSPECTION

1. Remove the flasher control module with the connector still connected.
2. Measure the voltage at each terminal (other than terminal F). If the voltage is not as specified in the «TERMINAL VOLTAGE TABLE (REFERENCE)»(ref-178404-S27388190292005061500000) .
3. Disconnect the flasher control module connector.
4. Verify that continuity at terminal F is as indicated in the «TERMINAL VOLTAGE TABLE (REFERENCE)»(ref-178404-S27388190292005061500000) . If there is any malfunction, inspect the parts under "Inspection item(s)". If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the flasher control module.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Disconnect the negative battery cable.
2. Disconnect the connectors.
3. Remove the screw and then remove the DRL control module.
4. Install in the reverse order of removal.

Scheme 14

DRL CONTROL MODULE INSPECTION

1. Connect the connector to the DRL control module.
2. Connect the negative battery cable.
3. Measure the voltage at the DRL control module using voltmeter. When inspecting terminal 1B, 1D or 2D for continuity, disconnect the DRL control module connector.
4. If the value are not as specified in the Terminal Voltage List (Reference), inspect the parts under "Inspection item(s)" and related wiring harnesses.
5. If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the DRL control module.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative battery cable.
2. Remove the screws.
3. Remove the map light. (See «MAP LIGHT REMOVAL NOTE»(ref-178404-S21740507422005061500000) .)
4. Disconnect the connector.
5. Remove the socket, then remove the map light bulb.
6. Install in the reverse order of removal.

Scheme 19

1. Insert a tape-wrapped Flathead screwdriver into the gap between the headliner and the map light.
2. Press the tab, and remove the map light.

Scheme 20

Scheme 21

1. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-178404-S16618549752005061500000).)
2. Verify that the continuity between the map light terminals is as indicated in the figure. (Scheme 20) If not as indicated, replace the map light.

Scheme 22

1. Disconnect the negative battery cable.
2. Remove the socket, then remove the glove compartment light bulb.
3. Install in the reverse order of removal.

Scheme 23

1. Disconnect the negative battery cable.
2. Remove the lens, then remove the courtesy light bulb.
3. Install in the reverse order of removal.

Scheme 24

1. Disconnect the negative battery cable.
2. Remove the lens. (See «LENS REMOVAL NOTE»(ref-178404-S35104290752005061500000) .)
3. Remove the interior light bulb.
4. Remove the interior light. (See «INTERIOR LIGHT REMOVAL NOTE»(ref-178404-S30006933752005061500000) .)
5. Disconnect the connector.
6. Install in the reverse order of removal.

Scheme 25

1. Insert a tape-wrapped Flathead screwdriver into the gap between the headliner and the interior light.
2. Press the tab, and remove the interior light.

Scheme 26

1. Insert a tape-wrapped Flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 27

Scheme 28

1. Remove the interior light. (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-178404-S41164716852005061500000).)
2. Verify that the continuity between the interior light terminals. (Scheme 27) If not as indicated, replace the interior light.

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the lens, then remove the trunk compartment light bulb.
3. Install in the reverse order of removal.

TRUNK COMPARTMENT LIGHT SWITCH INSPECTION

Note. The trunk compartment light switch is built into the trunk lock.

Scheme 30

Scheme 31

1. Remove the trunk lid trim. (See TRUNK LID TRIM REMOVAL/INSTALLATION.
2. Disconnect the trunk compartment light switch connector.
3. Verify that the continuity between the trunk compartment light switch terminals is as indicated. (Scheme 30) If not as indicated, replace the trunk lock.

Scheme 32

1. Disconnect the negative battery cable.
2. Remove the ashtray panel. (See CONSOLE REMOVAL/INSTALLATION .)
3. Remove the socket, then remove the ashtray illumination bulb.
4. Install in the reverse order of removal.

Scheme 33

1. Disconnect the negative battery cable.
2. Remove the column cover. (See COLUMN COVER REMOVAL/INSTALLATION .)
3. Remove the ignition key illumination bulb.
4. Install in the reverse order of removal.

Scheme 34

1. Disconnect the negative battery cable.
2. Remove the lens. (See «LENS REMOVAL NOTE»(ref-178404-S35990212782005061500000) .)
3. Remove the vanity mirror illumination bulb.
4. Install in the reverse order of removal.

Scheme 35

1. Insert a tape-wrapped Flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 36

1. Disconnect the negative battery cable.
2. Remove the panel light control switch. (See «PANEL LIGHT CONTROL SWITCH REMOVAL NOTE»(ref-178404-S35766140182005061500000) .)
3. Disconnect the connector.
4. Install in the reverse order of removal.

PANEL LIGHT CONTROL SWITCH INSPECTION

1. Connect the panel light control switch connector.
2. Connect the negative battery cable.
3. Measure the voltage at each terminal (other than terminal D). If the voltage is not as specified in the «TERMINAL VOLTAGE TABLE (REFERENCE)»(ref-178404-S14842478172005061500000) , inspect the parts under "Inspection item(s)".
4. Disconnect the panel light control switch connector.
5. Verify that continuity at terminal D is as indicated in the «TERMINAL VOLTAGE TABLE (REFERENCE)»(ref-178404-S14842478172005061500000) . If there is any malfunction, inspect the parts under "Inspection item(s)". If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the panel light control switch.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

1. Measure the wave pattern of panel light control switch terminals A and F using an oscilloscope. Oscilloscope setting: 5 V/DIV (Y), 5 MS/div (X), DC range
2. Turn the light switch to the TENS or ON position.
3. Turn the panel light control switch to the brightest setting.
4. Verify that the wave pattern is as shown in the figure.
5. Turn the panel light control switch to the darkest position and verify that the wave pattern is as shown in the figure.

Scheme 42

1. Disconnect the negative battery cable.
2. Remove the screw.
3. Disconnect the connector and remove the door switch.
4. Install in the reverse order of removal.

Scheme 43

Scheme 44

1. Remove the door switch. (See «DOOR SWITCH REMOVAL/INSTALLATION»(ref-178404-S10750079582005061500000).)
2. Verify that the continuity between door switch terminal and the body ground is as indicated. (Scheme 43) If not as indicated, replace the door switch.

Scheme 45

Scheme 46

1. Disconnect the negative battery cable.
2. Remove in the order indicated. (Scheme 45)
3. Install in the reverse order of removal.

Scheme 47

1. Loosen the adjusting bolt until the headlight leveling actuator can be rotated.
2. Rotate the headlight leveling actuator to the position shown in the figure.
3. Loosen the adjusting bolt further and remove the headlight leveling actuator.
