Wheel Alignment Specifications & Procedures Mazda RX-7 FC

Wheel Alignment 2 illustrations
ApplicationSpecification
Front
Camber in Degrees
Fraction21/64 +/- 1/2
Decimal.33 +/- .50
Caster in Degrees
Fraction43/64
Decimal.67
Toe-In in Inches
Fraction1/8 +/-+/- 1/8
Decimal.13 +/- .13
Toe-In in Degrees
Fraction1/4 +/- 1/4
Decimal.25 +/- .25
Toe-Out on Turns
Inner37°
Outer33°
Steering Axis Inclination (SAI)13 3/4°
Rear
Camber in Degrees
Fraction47/64 +/- 1/2
Decimal.73 +/- .50
Toe-In in Inches
Fraction0 +/- 1/8
Decimal0 +/- .13
Toe-In in Degrees
Fraction0 +/- 1/4
Decimal0 +/- .25

WHEEL ALIGNMENT SPECIFICATIONS

ALIGNMENT PROCEDURES

Note. Alignment procedures not available.

Front Camber & Caster Adjustment To adjust caster and camber, remove 4 mounting bolts, then push down and rotate block to desired position. Scheme 1

Scheme 1: Front Camber & Caster Adjustment To adjust caster and camber, remove 4 mounting bolts, then push down and rotate block to desired position.
Scheme 1: Front Camber & Caster Adjustment To adjust caster and camber, remove 4 mounting bolts, then push down and rotate block to desired position.

Rear Toe Adjustment To increase toe-in, increase eccentric width at contact point. Scheme 2

Scheme 2: Rear Toe Adjustment To increase toe-in, increase eccentric width at contact point.
Scheme 2: Rear Toe Adjustment To increase toe-in, increase eccentric width at contact point.
