MAIN SWITCH
Check continuity across specified terminals of main switch connector with main switch button held in specified position. See MAIN SWITCH CONTINUITY TEST. (Scheme 2) Replace main switch if continuity is not as specified.
| Switch Position | Terminals | |
|---|---|---|
| Driver | ||
| UP | F & N; H & L | |
| Off (Neutral) | F, L & N | |
| DOWN | F & L; H & N | |
| AUTO DOWN | F & L; H & N | |
| Passenger | ||
| UP | D & H; B & F | |
| Off (Neutral) | B, D & F | |
| DOWN | B & H; D & F | |
| Left Rear | ||
| UP | F & K; J & M | |
| Off (Neutral) | A, K & M | |
| DOWN | F & M; J & K | |
| Right Rear | ||
| UP | A & J; C & F | |
| Off (Neutral) | A, C & F | |
| DOWN | A & F; C & J | |
MAIN SWITCH CONTINUITY TEST
Scheme 2
SUB-SWITCH
Check continuity across specified terminals of sub-switch connector with main switch button held in specified position. See SUB-SWITCH CONTINUITY TEST. (Scheme 3) Replace sub-switch if continuity is not as specified.
| Switch Position | Terminals |
|---|---|
| UP | A & E; B & D |
| Off (Neutral) | A & E; D & F |
| DOWN | B & E; D & F |
SUB-SWITCH CONTINUITY TEST
Scheme 3
WINDOW MOTOR
Disconnect window motor connector. Apply battery voltage and ground across window motor connector terminals. Reverse polarity to move window in opposite direction. Replace window motor if it does not operate.
| WARNING | Window regulator is spring-loaded to assist window motor during upward movement. Before separating window motor from regulator, securely position regulator arms in full-up position (if possible). This will relieve spring pressure as much as possible, preventing injury when window motor is separated from regulator. |
