Maintenance Information: Overview Mazda MX-6 I

Procedures 4 illustrations ~898 words

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp - Brakelights, Horn
  2. 2 - 30 Amp - Power Door Locks
  3. 3 - Empty
  4. 4 - 20 Amp - Headlight Cleaners
  5. 5 - 15 Amp - Engine
  6. 6 - Empty
  7. 7 - 20 Amp - Cooling Fan
  8. 8 - 15 Amp - Air Conditioner
  9. 9 - 15 Amp - Interior Lights
  10. 10 - 10 Amp - Taillights
  11. 11 - 10 Amp - Meters
  12. 12 - 15 Amp - Sun Roof
  13. 13 - 15 Amp - Windshield Wipers
  14. 14 - 15 Amp - Car Component Stereo
  15. 15 - 30 Amp - Spare Fuse
  16. 16 - 15 Amp - Spare Fuse
  17. 17 - 10 Amp - Spare Fuse
  18. 18 - 30 Amp - Power Windows
  19. 19 - 20 Amp - Rear Window Defogger
  20. 20 - 15 Amp

Scheme 1

Scheme 1: FUSE PANEL & FUSE BLOCK IDENTIFICATION (1986-87)
Scheme 1: FUSE PANEL & FUSE BLOCK IDENTIFICATION (1986-87)
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. 1 - 30 Amp - Power Windows
  2. 2 - 20 Amp - Stoplights, Horn
  3. 3 - 15 Amp - Charging System, Fuel Injection System
  4. 4 - 15 Amp - Fuel Injection System, Turn Signals, Hazard Lights
  5. 5 - 15 Amp - Turn Signals, Hazard Lights
  6. 6 - 20 Amp - Rear Defogger
  7. 7 - 15 Amp - Taillights, Side Marker Lights, Front Side Marker Lights, Glove Box Lights, License Light, Dash Lights, Buzzers
  8. 8 - 15 Amp - Audio, Power Antenna
  9. 9 - Empty
  10. 10 - 15 Amp - Headlight Cleaner
  11. 11 - 15 Amp - Power Sun Roof
  12. 12 - 10 Amp - Footlights, Courtesy Lights, Ignition & Door Lock Lights, Luggage Light, Interior Lights, Spotlights, Audio, Antenna, Sun Roof, Warning Buzzers, Clock
  13. 13 - Empty
  14. 14 - 15 Amp - Heater, Air Conditioning
  15. 15 - 15 Amp - Sun Roof
  16. 16 - 15 Amp - Front Wiper/Washer
  17. 17 - 20 Amp - Cooling Fan System
  18. 18 - 10 Amp - Rear Wiper/Washer
  19. 19 - Empty
  20. 20 - Empty
  21. 21 - 30 Amp - EGI CON
  22. 22 - 30 Amp - Injection
  23. 23 - 80 Amp - Main Circuit Protection
  24. 24 - 40 Amp - Hazard Lights, Interior Lights, Door Lock, Stoplights, Taillights
  25. 25 - 30 Amp - Headlights

Scheme 2

Scheme 2: FUSE PANEL & FUSE BLOCK IDENTIFICATION (1988-92)
Scheme 2: FUSE PANEL & FUSE BLOCK IDENTIFICATION (1988-92)
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. 1 - 30 Amp - EGI
  2. 2 - Empty
  3. 3 - 30 Amp (1989-90) - 40 Amp (1991-92) - Headlights
  4. 4 - 80 Amp - 100 Amp (Some Models) - Main Circuit Protection
  5. 5 - 60 Amp - Hazard Lights, Interior Lights, Door Lock, Stoplights, Taillights
  6. 6 - 40 Amp (1989-90) - 30 Amp (1991-92) - Cooling Fan
  7. 7 - 60 Amp - ABS Pump
  8. 8 - 40 Amp - Heater, Air Conditioner
  9. 9 - 15 Amp (1989-90) - 20 Amp (1991-92) - Air Conditioner
  10. 10 - Empty (1989-90) - 10 Amp (1991-92) - Engine Control Unit
  11. 11 - 15 Amp (1989-90) - 4-Wheel Steering Empty (1991-92)
  12. 12 - Empty
  13. 13 - Empty
  14. 14 - Empty
  15. 15 - Empty
  16. 16 - 30 Amp - Seat Belt Passive System
  17. 17 - 30 Amp - Power Windows
  18. 18 - 15 Amp - Taillights, Side Marker Lights, Parking Lights, Dash Illumination, License Light
  19. 19 - 15 Amp - Interior Lights, Map Light
  20. 20 - Empty
  21. 21 - 15 Amp (1989-91) - Rear Wiper Empty (1992)
  22. 22 - 15 Amp - Radio
  23. 23 - 15 Amp (1989-90) - Foglights Empty (1991-92)
  24. 24 - 10 Amp - Meters
  25. 25 - 30 Amp - Power Door Locks
  26. 26 - 20 Amp (1989-90) - Cooling Fan Empty (1991-92)
  27. 27 - 20 Amp - Wiper
  28. 28 - 20 Amp (1989-91) - Headlight Cleaner 10 Amp (1992) - Rear Wiper/Washer
  29. 29 - 15 Amp - Hazard Lights & Warning
  30. 30 - 15 Amp - Turn Signals
  31. 31 - 15 Amp - Stoplights
  32. 32 - 15 Amp - Engine Control System
  33. 33 - 15 Amp - Sun Roof
  34. 34 - 30 Amp - Rear Window Defroster

Scheme 3

Scheme 3: MAIN FUSE BLOCK IDENTIFICATION (1993-96)
Scheme 3: MAIN FUSE BLOCK IDENTIFICATION (1993-96)
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. 1 - 100 Amp (Blue) - Main Circuit Protection
  2. 2 - 40 Amp (Green) - Headlights
  3. 3 - 40 Amp (Green) - Mirror/Rear Window Defogger
  4. 4 - 30 Amp - Fuel Injection
  5. 5 - 40 Am (Green) - Radio, Sun Roof, Turn Signal, Gauges, Engine, Power Windows, Ignition System, Windshield Wipers
  6. 6 - 60 Amp (Yellow) - Taillights, Foglights, Stoplights, Courtesy & Hazard Lights, Power Door Locks, Power Seats
  7. 7 - 60 Amp (Yellow) - ABS System
  8. 8 - 40 Amp (Green) - Cooling Fan
  9. 9 - 40 Amp (Green) - Heater, Air Conditioner
  10. 10 - 40 Amp (Green) - Air Conditioner
  11. 11 - 15 Amp (Blue) - Taillights, Parking Lights, Instrument Panel, License Light, Glove Box Light
  12. 12 - Empty
  13. 13 - 15 Amp (Blue) - Foglights
  14. 14 - Empty

Scheme 4

Scheme 4: UNDERDASH FUSE PANEL IDENTIFICATION (1993-96)
Scheme 4: UNDERDASH FUSE PANEL IDENTIFICATION (1993-96)
  1. A - 20 Amp (Yellow) - Stoplights, Horn
  2. B - 15 Amp (Blue) - Interior Lights, Trunk Light, Sound Warning System
  3. C - 15 Amp (Blue) - Spare Fuse
  4. D - 30 Amp (Green) - Power Door Locks
  5. E - 15 Amp (Blue) - Audio System, Cigarette Lighter, Outside Mirror
  6. F - 15 Amp (Blue) - Sun Roof
  7. G - 15 Amp (Blue) - Turn Signals
  8. H - 30 Amp (Green) - Power Seats
  9. I - 15 Amp (Blue) - Gauges, Back-Up Lights, Cruise Control
  10. J - 15 Amp (Blue) - Hazard Warning Lights
  11. K - 15 Amp (Blue) - Engine Control System
  12. L - 30 Amp (Green) - Power Windows
  13. M - 20 Amp (Yellow) - Headlight Cleaner
  14. N - 20 Amp (Yellow) - Windshield Wiper/Washer
  15. O - 20 Amp (Yellow) - Rear Window Wiper
