Front Suspension System: Removal & Installation Mazda MX-5 NC рестайлинг

FRONT SHOCK ABSORBER AND COIL SPRING REMOVAL/INSTALLATION

1. For 6MT vehicles, perform the following procedures. Disconnect the purge solenoid valve connector wiring harness from the bracket. Remove the bracket from the air intake hose and move the purge solenoid valve component out of the way. (See «PURGE SOLENOID VALVE REMOVAL/INSTALLATION [LF]»(ref-430327-S01360201292011101700000) ). Remove the following parts as a single unit. See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [LF]»(ref-478572-S27568218632012061100000) . Air intake hose Resonance chamber No. 2 Resonance duct No. 1 Resonance duct No. 2
2. Remove the front suspension tower bar and plate. (See «FRONT SUSPENSION TOWER BAR REMOVAL/INSTALLATION»(ref-430328-S00590495132011101700000) ).
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. Inspect the front wheel alignment, and adjust it if necessary. (See «FRONT WHEEL ALIGNMENT»(ref-430306-S26371044342011101700000) ).

Scheme 5

Piston Rod Nut Removal Note

Scheme 6

Scheme 7

Scheme 8

1. Install the front shock absorber and coil spring to the SSTs according to the following procedures. NOTE: Install the SST using a piece of clean rag to prevent the coil spring from being scratched. Set the SST attachments (tabs) to the positions shown in the illustration. Install the front shock absorber and coil spring to the SST so that the coil spring is set to the position shown in the illustration.
2. Compress the coil spring using the SSTs.
3. Remove the piston rod nut.

Coil Spring Installation Note

1. Protect the coil spring from scratches using a piece of cloth and install the SSTs
2. Compress the coil spring using the SSTs.
3. Install the shock absorber so that the lower end of the coil spring is seated on the step of the lower spring seat.

Scheme 9

Scheme 10

Scheme 11

1. Align the mark on the upper spring seat with the dust boot projection.
2. Install the upper spring seat so that the upper spring seat stud is at a 27°-33° angle to the shock absorber installation shaft (lower side).

FRONT UPPER ARM REMOVAL/INSTALLATION

1. For 6MT vehicles, perform the following procedures. Disconnect the purge solenoid valve connector wiring harness from the bracket. Remove the bracket from the air intake hose and move the purge solenoid valve component out of the way. (See «PURGE SOLENOID VALVE REMOVAL/INSTALLATION [LF]»(ref-430327-S01360201292011101700000) ). Remove the following parts as a single unit. See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [LF]»(ref-478572-S27568218632012061100000) Air intake hose Resonance chamber No. 2 Resonance duct No. 1 Resonance duct No. 2
2. Remove the front suspension tower bar. (See «FRONT SUSPENSION TOWER BAR REMOVAL/INSTALLATION»(ref-430328-S00590495132011101700000) ).
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. Inspect the front wheel alignment and adjust it if necessary. (See «FRONT WHEEL ALIGNMENT»(ref-430306-S26371044342011101700000) ).

Scheme 12

Front Upper Arm Ball Joint Removal Note

1. Remove the front upper arm ball joint from the steering knuckle using the SST.

Scheme 13

Front Shock Absorber, Coil Spring And Front Upper Arm Removal Note

1. Loosen the shock absorber upper nuts.
2. Remove the front shock absorber lower bolt and nut.

Front Upper Arm Removal Note

1. Remove the front upper arm bolts.
2. Push down the front lower arm, and then remove the front upper arm from the gap between the shock absorber lower end and the front lower arm.

FRONT LOWER ARM REMOVAL/INSTALLATION

1. Remove in the order indicated in the table.
2. Install in the reverse order of removal.

Scheme 14

Caliper and Mounting Support Removal Note

1. Remove the caliper and mounting support from the steering knuckle and suspend it with a cable in a location out of the way.

Front Lower Arm Ball Joint Removal Note

1. Disconnect the front lower arm ball joint from the steering knuckle using the SST. NOTE: When removing the front lower arm ball joint, the steering knuckle bushing may also come off. If it comes off, replace the steering knuckle.

Scheme 15

1. Loosen the bolts on the vehicle side.
2. Disconnect the upper arm ball joint using the SST.

Scheme 16

Bushing (Rear Side) Removal Note

Scheme 17

Scheme 18

1. Mark the front upper arm as shown in the illustration.
2. Remove the bushing using the SSTs.

Bushing (Front Side) Removal Note

Scheme 19

Scheme 20

Scheme 21

1. Cut off the stopper plate rubber using a razor.
2. Cut off 5-6 mm {0.20-0.23 in} from each side of the knob end of the bushing using a hacksaw.
3. Remove the bushing using the SSTs.

Bushing (Shock Absorber Lower Side Connecting Part) Removal Note

1. Remove the bushing using the SSTs.

Scheme 22

Bushing (Shock Absorber Lower Side Connecting Part) Installation Note

1. Compress the bushing using the SSTs.

Scheme 23

Scheme 24

Scheme 25

1. Press the bushing in using the SSTs.
2. Insert the stopper plate rubber into the inner pipe of the bushing (front side).

Scheme 26

Scheme 27

1. Align the marks placed during removal and install the bushing.
2. Press the bushing in using the SSTs.

Clip Installation Note

1. Wipe the grease off the ball joint stud.
2. Fill the inside of the new dust boot with grease.
3. Install the dust boot to the ball joint.
4. Install the clip using the SST.
5. Verify that the clip is installed securely to the groove.
6. Wipe off any excess grease.

Scheme 28

Front Lower Arm Installation Note

1. Install the front lower arm rear side bushing part horizontally.
2. Install the front lower arm front side bushing part.

FRONT STABILIZER REMOVAL/INSTALLATION

1. Remove the splash shield A. (See «SPLASH SHIELD REMOVAL/INSTALLATION»(ref-430307-S42583601182011101700000) ).
2. Remove the front under cover. (See «FRONT UNDER COVER REMOVAL/INSTALLATION»(ref-430307-S42285086172011101700000) ).
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 29

Stabilizer Bracket Installation Note

1. Apply rubber grease to the inner side of the stabilizer bushing.
2. Align the outer side of the stabilizer slide stopper with the stabilizer bushing.
3. Install the stabilizer bracket.

Scheme 30

FRONT CROSSMEMBER REMOVAL/INSTALLATION

1. For 6MT vehicles, perform the following procedures. Disconnect the purge solenoid valve connector wiring harness from the bracket. Remove the bracket from the air intake hose and move the purge solenoid valve component out of the way. (See «PURGE SOLENOID VALVE REMOVAL/INSTALLATION [LF]»(ref-430327-S01360201292011101700000) ). Remove the following parts as a single unit. See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [LF]»(ref-478572-S27568218632012061100000) Air intake hose Resonance chamber No. 2 Resonance duct No. 1 Resonance duct No. 2
2. Remove the front suspension tower bar. (See «FRONT SUSPENSION TOWER BAR REMOVAL/INSTALLATION»(ref-430328-S00590495132011101700000) ).
3. Remove the splash shield A. (See «SPLASH SHIELD REMOVAL/INSTALLATION»(ref-430307-S42583601182011101700000) ).
4. Remove the front under cover. (See «FRONT UNDER COVER REMOVAL/INSTALLATION»(ref-430307-S42285086172011101700000) ).
5. Remove the front stabilizer (See «FRONT STABILIZER REMOVAL/INSTALLATION»(ref-430328-S24049272012011101700000) ).
6. Remove the transverse members (See «TRANSVERSE MEMBER REMOVAL/INSTALLATION»(ref-430328-S39020638982011101700000) ).
7. Remove the steering gear and linkage, and suspend it using a cable.
8. Remove in the order indicated in the table.
9. Install in the reverse order of removal.
10. Inspect the front wheel alignment. (See «FRONT WHEEL ALIGNMENT»(ref-430306-S26371044342011101700000) ).

Scheme 31

Axle and Hub Component Removal Note

1. Loosen the front upper arm inner bolts.
2. Remove the axle and hub component.

Scheme 32

Scheme 33

Scheme 34

1. Secure the chain to install the SST to the position shown in the illustration using the bolts ( M10 x 1.5 , length 30 mm {1.18 in}).
2. Suspend the engine.
3. Support the front crossmember using a jack. WARNING: Verify that the crossmember component is securely supported by a jack. If the crossmember component falls, it could cause serious injury or death, or damage to the vehicle.
4. Lower the front crossmember component slightly.
5. Remove the engine mounting rubber, pipes and hoses installed to the front crossmember.
6. Remove the front crossmember component.

FRONT SUSPENSION TOWER BAR REMOVAL/INSTALLATION

1. For 6MT vehicles, perform the following procedures. Disconnect the purge solenoid valve connector wiring harness from the bracket. Remove the bracket from the air intake hose and move the purge solenoid valve component out of the way (See «PURGE SOLENOID VALVE REMOVAL/INSTALLATION [LF]»(ref-430327-S01360201292011101700000) ). Remove the following parts as a single unit. See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [LF]»(ref-478572-S27568218632012061100000) Air intake hose Resonance chamber No. 2 Resonance duct No. 1 Resonance duct No. 2
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 35

Plate Installation Note

1. Install the plates with the identification marks facing upward.

Scheme 36

TRANSVERSE MEMBER REMOVAL/INSTALLATION

1. Remove in the order indicated in the table.
2. Install in the reverse order of removal.

Scheme 37

Transverse Member Removal Note

1. Support the crossmember using a jack.
2. Remove the transverse member.

Scheme 38

Scheme 39

1. Align projection A with the transverse member opening to temporarily support the under cover.
2. Tighten the bolts in the order of A, B and C.
