FUSE SERVICE WARNINGS
| WARNING | For vehicles with DSC, if the room fuse is disconnected, the stored initial position of the steering angle sensor will be cleared and the DSC will not operate properly, making the vehicle unsafe to drive. Perform the steering angle sensor initialization procedure after connecting the room fuse. (See STEERING ANGLE SENSOR INITIALIZATION PROCEDURE .) |
FUSE SERVICE CAUTIONS
| CAUTION | Determine and correct the cause of the burnt fuse before replacing it. If the fuse is replaced before doing this, it may burn again. |
Scheme 5
- Remove the battery cover.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
- Remove the main fuse block cover.
- Remove in the order indicated in the illustration.
- Install in the reverse order of removal.
Scheme 6
- Press and remove the tabs on upper block at the positions indicated by the arrows.
- Raise the upper block and remove it.
Scheme 7
- Remove the battery cover.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
- Remove the upper block. (See «UPPER BLOCK REMOVAL/INSTALLATION»(ref-430320-S14265175962011101700000) .)
- Remove in the order indicated in the illustration.
- Install in the reverse order of removal.
Scheme 8
Scheme 9
- Verify that the continuity between the ignition switch terminals is as indicated in the illustration. If not as indicated in the illustration, replace the ignition switch.
Scheme 10
- Remove the battery cover.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) .)
- Remove in the order indicated in the illustration.
- Install in the reverse order of removal.
Scheme 11
![Scheme 11: KEY REMINDER SWITCH REMOVAL/INSTALLATION [EXCEPT ADVANCED KEYLESS SYSTEM]](https://i.diagnostdata.com/repair/c2/c224692b7d0a034ad7a8fcfcbe5660d2fe883b4476aa9198f16846f428caa9ae.webp)
- Remove the battery cover.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) .)
- Disconnect the key reminder switch connector.
- Remove the key reminder switch.
- Install in the reverse order of removal.
Scheme 12
![Scheme 12: KEY REMINDER SWITCH INSPECTION [EXCEPT ADVANCED KEYLESS SYSTEM]](https://i.diagnostdata.com/repair/23/23a2bfa82bf4bd555d806cd2ecb01c66e1e79579bf39383c36d5ad78055b6f3b.webp)
Scheme 13
- Verify that the continuity between the key reminder switch terminals is as indicated in the illustration. If not as indicated in the illustration, replace the key reminder switch.
Relay type
| Terminal type | Part name |
|---|---|
| Type A | Main relay Starter relay Drive-by-wire relay Blower relay Fuel pump relay Front fog light relay A/C relay TNS relay Rear window defroster relay Horn relay Cooling fan relay No. 1 Cooling fan relay No. 2 Cooling fan relay No. 3 Trunk lid opener relay |
| Type B | Headlight relay Ignition relay |
PART SPECIFICATION
Scheme 14
Scheme 15
- Verify the continuity between the relay terminals. If not as indicated in the illustration, replace the relay.
Scheme 16
Scheme 17
- Verify the continuity between the relay terminals. If not as indicated in the illustration, replace the relay.
