STEERING LOCK UNIT INSPECTION [ADVANCED KEYLESS SYSTEM]

  1. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) .)
  2. Measure the voltage at each terminal. If the voltage is not as specified in the «Terminal Voltage Chart (Reference)»(ref-430320-S15573769942011101700000) , inspect the parts under "Inspection item(s)". If there is any malfunction, inspect the parts under "Inspection item(s)". If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the steering lock unit.

Scheme 2

Scheme 2: Terminal Voltage Chart (Reference)
TerminalSignal nameConnected toMeasured conditionVoltage (V)Inspection item(s)
APush switch signalKeyless control moduleStart knob pressedB+Keyless control module Related wiring harnesses
Start knob released1.0 or less
BPower supplyFuseUnder any conditionB+Fuse Related wiring harnesses
CKey reminder switch signalKeyless control moduleKey insertedB+Keyless control module Related wiring harnesses
Key removed1.0 or less
DPower supplyFuseUnder any conditionB+Fuse Related wiring harnesses
EPower supplyFuseUnder any conditionB+Fuse Related wiring harnesses
FIgnition key illumination signalIgnition key illumination bulbIgnition switch off and driver-side door opened.1.0 or lessIgnition key illumination bulb Related wiring harnesses
30 s or more after driver-side door closed.B+
GSerial communicationKeyless control moduleBecause this terminal is for communication good/no good judgment by terminal voltage is not possible.Related wiring harnesses
HGNDBody groundBecause this terminal is for communication good/no good judgment by terminal voltage is not possible.Related wiring harnesses

VOLTAGE SPECIFICATION

Scheme 3

Scheme 3: TRUNK LID OPENER RELAY REMOVAL/INSTALLATION
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  3. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) .)
  4. Remove the trunk lid opener relay.
  5. Install in the reverse order of removal.

Scheme 4

Scheme 4: RELAY LOCATION
