Security System and Locks System: Removal & Installation Mazda MX-5 NC рестайлинг

INNER HANDLE REMOVAL/INSTALLATION

1. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-430296-S08313422672011101700000) )
2. Remove the screws, then remove the inner handle.
3. Detach the cables from the inner handle and door lock knob.
4. Install in the reverse order of removal.

Scheme 30

OPEN HOOK REMOVAL/INSTALLATION

1. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) ) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) ) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) ) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) ) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) ) Seat back bar garnish (See «SEAT BACK BAR GARNISH REMOVAL/INSTALLATION»(ref-430296-S00744916912011101700000) ) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) ) Seat back bar lower garnish (See «SEAT BACK BAR LOWER GARNISH REMOVAL/INSTALLATION»(ref-430296-S11299234462011101700000) )
2. Remove the bolts.
3. Remove the open hook.
4. Install in the reverse order of removal.

Scheme 31

DOOR LOCK SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
2. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-430296-S08313422672011101700000) )
3. Remove the screws, then remove the door lock switch.
4. install in the reverse order of removal.

Scheme 32

HOOD STRIKER REMOVAL/INSTALLATION

1. Remove the bolt, then remove the hood striker.
2. Install in the reverse order of removal.

Scheme 33

Scheme 34

Scheme 35

1. Open the hood.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Disconnect the hood latch switch connector.
4. Inspect for continuity between the hood latch switch terminals A and B. If there is no continuity, replace the hood latch.
5. Lock the hood latch using a Flathead screwdriver or equivalent as shown in the illustration.
6. Inspect for continuity between the hood latch switch terminals A and B If there is continuity, replace the hood latch. CAUTION: After the inspection, unlock the hood latch. If closing the hood with the hood latch locked, the hood latch and/or hood striker may be broken.

Scheme 36

1. Remove the following parts: Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) ) Partition board (See «PARTITION BOARD REMOVAL/INSTALLATION»(ref-430296-S16092932432011101700000) ) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-430296-S12262640872011101700000) )
2. Remove in the order indicated in the illustration.
3. Install in the reverse order of removal.
4. Adjust the fuel-filler lid. (See «FUEL-FILLER LID ADJUSTMENT»(ref-430315-S40096808532011101700000) )

Scheme 37

Scheme 38

Scheme 39

1. Position the door glass so that the distance between the top of the front door glass and top of the front beltline molding is 110 mm {4.33 in}.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Door trim (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-430296-S08313422672011101700000) ) Door speaker (See «DOOR SPEAKER REMOVAL/INSTALLATION»(ref-430309-S01013444872011101700000) ) Door module panel (See «DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-430354-S03452672642011101700000) ) Door glass See «DOOR GLASS REMOVAL/INSTALLATION»(ref-478583-S20731438372012061100000) procedure. Outer handle (See «OUTER HANDLE REMOVAL/INSTALLATION»(ref-430313-S35921038202011101700000) )
4. Detach the door key cylinder rod.
5. Turn the front door key cylinder so that the tab is aligned with the notch.
6. Remove the front door key cylinder by pulling it out from the front door.
7. Install in the reverse order of removal.

DOOR LATCH AND LOCK ACTUATOR REMOVAL/INSTALLATION

1. Position the door glass so that the distance between the top of the front door glass and top of the front beltline molding is 110 mm {4.33 in}.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the following parts: Door trim (See «DOOR TRIM REMOVAL/INSTALLATION»(ref-430296-S08313422672011101700000) ) Door speaker (See «DOOR SPEAKER REMOVAL/INSTALLATION»(ref-430309-S01013444872011101700000) ) Inner handle (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-430313-S36101593862011101700000) ) Door module panel (See «DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-430354-S03452672642011101700000) ) Door glass See «DOOR GLASS REMOVAL/INSTALLATION»(ref-478583-S20731438372012061100000) procedure.
4. Detach the rods from the key cylinder and the outer handle.
5. Remove the screws, then remove the door latch and lock actuator.
6. Install in the reverse order of removal.

Scheme 40

DOOR LOCK STRIKER REMOVAL/INSTALLATION

1. Remove the screws, and then remove the door lock striker.
2. Install in the reverse order of removal.
3. Adjust the door. (See «DOOR ADJUSTMENT»(ref-430354-S40079508782011101700000) )

Scheme 41

TRUNK LID OPENER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) )
3. Detach the rod.
4. Disconnect the trunk lid opener connector and the trunk compartment light connector.
5. Remove the bolts, then remove the trunk lid opener.
6. Install in the reverse order of removal.

Scheme 42

TRUNK LID STRIKER REMOVAL/INSTALLATION

1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) )
2. Remove the bolts, then remove the trunk lid striker.
3. Install in the reverse order of removal.

Scheme 43

TRUNK LID OPENER SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
2. Using a small Flathead screwdriver, detach the tabs of the trunk lid opener switch from the dashboard.
3. Push the trunk lid opener switch into the dashboard and remove.
4. Disconnect the trunk lid opener switch connector.
5. Install in the reverse order of removal.

Scheme 44

TRUNK KEY CYLINDER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) )
3. Detach the rod.
4. Remove the nuts, then remove the trunk key cylinder.
5. Install in the reverse order of removal.

Scheme 45

TRUNK LID OPEN CANCEL SWITCH REMOVAL/INSTALLATION

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-430296-S09188712472011101700000) )
3. Squeeze the tabs of the trunk lid open cancel switch and pull it forward to remove it.
4. Disconnect the trunk lid open cancel switch connector.
5. Remove the trunk lid open cancel switch.
6. Install in the reverse order of removal.

Scheme 46

KEYLESS CONTROL MODULE REMOVAL/INSTALLATION

Note. If the keyless control module is replaced, always perform the following procedure. Without immobilizer system Advanced key programming (See ADVANCED KEY ID CODE REGISTRATION ) Steering lock unit programming (See STEERING LOCK UNIT ID CODE REGISTRATION ) With immobilizer system Advanced key programming (See ADVANCED KEY ID CODE REGISTRATION ) Steering lock unit programming (See STEERING LOCK UNIT ID CODE REGISTRATION ) Immobilizer system resetting (with immobilizer system) (See IMMOBILIZER SYSTEM-RELATED PARTS PROGRAMMING [ADVANCED KEYLESS ENTRY AND START SYSTEM] )

Scheme 47

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
2. Remove the side panel. (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-430296-S24557577942011101700000) )
3. Remove the bolt and nut.
4. While inclining the keyless control module along the body panel in the direction indicated by the arrow shown in the illustration, disengage the bracket tab from the hole in the body panel.
5. Disconnect the keyless control module connector.
6. Remove the keyless control module.
7. Remove the screw, then remove the bracket. NOTE: The screw which fixes the keyless control module and bracket is for a body ground connection. Be sure to secure the screw when installing.
8. Install in the reverse order of removal.

Scheme 48

No. 5 Programming Procedure Due to Keyless Control Module Replacement

Note. Since two or more keys need to be programmed to start the engine, program two or more keys after the replacement.

No. 6 Programming Procedure Due to Simultaneous Replacement of Immobilizer System-related Parts (PCM and Keyless Control Module)

Note. Since two or more keys need to be programmed to start the engine, program two or more keys after the replacement.

No. 4 Programming Procedure Due to PCM Replacement

No. 5 Programming Procedure Due to Steering Lock Unit Replacement

Note. Since two or more keys need to be programmed to start the engine, program two or more keys after the replacement.

No. 6 Programming Procedure Due to Keyless Control Module Replacement

Note. Before beginning the procedure, verify that the customer has turned in all of the advanced keys and key for the vehicle. The engine cannot be started unless an advanced key and two or more keys are programmed after the replacement.

No. 7 Programming Procedure Due to Simultaneous Replacement of Immobilizer System-related Parts (PCM, Keyless Control Module, and Steering Lock Unit)

PARTS PROCEDURE CHART

Scheme 49

KEY PROGRAMMING PROCEDURE CHART Step Procedure Action after procedure 1 REPLACE UNITS OR PARTS Replace the unit or parts. Go to the next step. 2 PERFORM PARAMETER RESET Connect the M-MDS to the DLC-2. (See M-MDS CONNECTING PROCEDURE ) Turn the ignition switch to the ON position using key 1. NOTE: Although the security light flashes or illuminates and DTC 15 or 23 is displayed after approx. 1 min , continue to perform the procedure. After vehicle identification, select the following from the M-MDS initial screen. Using an IDS (laptop PC): Select "Body". Select "Security". Select "PATS functions". Using a PDS (pocket PC): Select "Programming". Select "PATS Functions". Then, select an item from the screen menu. Parameter Reset Perform the security access according to the directions on the M-MDS screen. Select the replaced parts according to the directions on the M-MDS screen. If the PCM is replaced: Select "PCM". If the keyless control module is replaced: Select "RKE". CAUTION: At this time, do not select the other parts from the M-MDS menu. Go to the next step. 3 CLEAR IGNITION KEY ID NUMBERS Select "Ignition Key Code Erase and Program" from the M-MDS screen menu. Clear the ignition key ID number according to the directions on the M-MDS. Go to the next step. 4 PERFORM IGNITION KEY ID NUMBER PROGRAMMING Program two keys according to the directions on the M-MDS. Verify that the PATS function menu is displayed again on the M-MDS screen. Go to the next step. 5 PERFORM ADVANCED KEY PROGRAMMING Select "Program Additional card key" from the M-MDS screen menu. Program the advanced key according to the directions on the M-MDS. Verify that the PATS function menu is displayed again on the M-MDS screen. Go to the next step. 6 PERFORM STEERING LOCK UNIT PROGRAMMING Select "Steering Lock Unit Programming" from the M-MDS screen menu. Complete the Steering Lock Unit Programming according to the directions on the M-MDS. (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION ) After verifying that the PATS function menu is displayed again on the M-MDS screen, select "Finish (this menu)". Turn the ignition switch to the LOCK position. Disconnect the M-MDS from the DLC-2. Remove the programmed advanced key from the vehicle. Go to the next step. 7 VERIFY KEY 1 PROGRAMMING PERFORMED CORRECTLY Start the engine using key 1. Verify that the security light and keyless warning light operate as shown in the following illustration. Turn the ignition switch to the LOCK position and remove key 1. Go to the next step. 8 VERIFY KEY 2 PROGRAMMING PERFORMED CORRECTLY Start the engine using key 2. Verify that the security light and keyless warning light operate as shown in the following illustration. Turn the ignition switch to the LOCK position and remove key 2. Are there other keys to be programmed? Yes Repeat Step 8 using each programmed key. No Go to the next step. 9 VERIFY ADVANCED KEY PROGRAMMING PERFORMED CORRECTLY Bring the programmed advanced key into the vehicle. Close all doors. Remove the key from the key cylinder and place it on the front passenger's seat. Start the engine using the advanced key. Verify that the security light and keyless warning light operate as shown in the following illustration. Turn the ignition switch to the LOCK position. Procedure is completed

Scheme 50

Scheme 51

Scheme 52

COIL ANTENNA REMOVAL/INSTALLATION

Note. Do not remove the coil antenna unless you are replacing it.

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) )
3. Disconnect the coil antenna connector.
4. Detach the steering lock tabs from the holes on the coil antenna.
5. Install in the reverse order of removal.

Scheme 53

Scheme 54

1. Fully lower the driver-side door glass.
2. Connect the M-MDS to the DLC-2.
3. Pull out the M-MDS cable from the door glass opening and set the M-MDS outside the vehicle. CAUTION: Protect the cable and body contact area with a clean rag, otherwise they could b damaged.
4. After vehicle identification, select the following from the M-MDS initial screen. Using an IDS (laptop PC) Select "Body". Select "Security". Select "PATS Functions". Using a PDS (pocket PC): Select "Programming". Select "PATS Functions".
5. Then, select an item from the screen menu. Card Key Code Erase and Program
6. Perform the security access according to the directions on the M-MDS screen.
