Differential: Overview Mazda MX-5 NC рестайлинг

Scheme 1

Scheme 2

Scheme 3

1. Park the vehicle on level ground for approx. 5 min. to stabilize the differential oil
2. Remove the oil-fill plug and the washer.
3. Inspect if the oil level is close to the rim of the oil-fill hole. NOTE: Each vehicle is filled with a specified amount of oil (0.7±0.1 L) when it is delivered, therefore, the oil level is lower than the lower end of the plug hole as shown in illustration. However, this has no affect on the differential function.
4. If the oil level is lower than approx. 12 mm {0.47 in} from the lower end of the oil-fill plug hole, inspect for oil leakage and add the specified oil. Differential oil Grade: API service GL-5 Viscosity: SAE 90, SAE 80W-90, SAE 75W-90 (Not available from Mazda)
5. Install the oil-fill plug with a new washer and tighten. Tightening Torque: 39.2-53.9 N.m {4.00-5.49 kgf.m, 29.0-39.7 ft.lbf}

Scheme 4

Scheme 5

1. Park the vehicle on level ground.
2. Remove the oil-fill plug.
3. Remove the drain plug and drain the oil.
4. Install the drain plug with a new washer and tighten. Tightening Torque: 39.2-53.9 N.m {4.00-5.49 kgf.m, 29.0-39.7 ft.lbf}
5. Add the specified oil from the oil-fill plug hole until the oil level reaches the lower end of the plug hole. Differential oil Grade: API service GL-5 Viscosity: SAE 90, SAE 80W-90, SAE 75W-90 (Not available from Mazda) Capacity (approx. quantity): 0.6-0.8 L {0.63-0.85 US qt, 0.53-0.70 lmp qt}
6. Install the oil-fill plug with a new washer and tighten. Tightening Torque: 39.2-53.9 N.m {4.00-5.49 kgf.m, 29.0-39.7 ft.lbf}

Scheme 6

Scheme 7

1. Remove the drain plug and drain the oil.
2. Install the drain plug with a new washer and tighten. Tightening Torque: 39.2-53.9 N.m {4.00-5.49 kgf.m, 29.0-39.7 ft.lbf}
3. Disconnect the rear drive shaft on the differential side. (See «REAR DIFFERENTIAL REMOVAL/INSTALLATION» )
4. Remove the clip from the rear drive shaft. CAUTION: To prevent damaging the inside of the differential casing, wrap cloth on the end of the flathead screwdriver.
5. Remove the oil seal from the differential carrier using a flathead screwdriver.
6. Apply differential oil to the lip of a new oil seal.
7. Tap in the new oil seat until it reaches the differential carrier using the SSTs. NOTE: Install the oil seal at a straight angle.
8. After installing a new clip to the rear drive shaft, insert it into the rear differential. (See «REAR DIFFERENTIAL REMOVAL/INSTALLATION» )
9. Verify that the rear drive shaft is held securely by the clip by pulling the outer ring on the differential side towards the axle.
10. Add differential oil.
11. After adding the oil, perform the oil level inspection. (See «DIFFERENTIAL OIL INSPECTION»
12. Install the oil-fill plug with a new washer and tighten. Tightening Torque: 39.2-53.9 N.m {4.00-5.49 kgf.m, 29.0-39.7 ft.lbf}
