EVAPORATOR TEMPERATURE SENSOR INSPECTION
Note. Inspect the evaporator temperature sensor when it is installed to the A/C unit.
Scheme 30
- Set the fan speed MAX-HI.
- Set the temperature control to MAX COLD.
- Set the air intake mode to RECIRCULATE.
- Turn the A/C switch off.
- Close all of the doors and roll up all the windows.
- Wait for 5 min.
- Disconnect the evaporator temperature sensor connector.
- Measure the temperature at the air intake.
- Measure the resistance between evaporator temperature sensor terminals. If the characteristics of the evaporator temperature sensor are not (Scheme 30), replace the evaporator temperature sensor.
Scheme 31
- Remove the battery cover.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
- Discharge the refrigerant from the system. (See «REFRIGERANT CHARGING»(ref-244471-S09026287512006092400000).)
- Remove in the order indicated in (Scheme 31).
- Install in the reverse order of removal.
CLIMATE CONTROL UNIT INSPECTION
- Turn the ignition switch to the ON position.
- Connect the negative (-) lead of the tester to body ground.
- By inserting the positive (+) lead of the tester into each climate control unit terminal, measure the voltage according to «TERMINAL VOLTAGE REFERENCE TABLE»(ref-244473-S00179116702006092400000) . If there is any malfunction, inspect the parts under "Inspection item (s)". If the parts under "Inspection item (s)" are found to be normal, replace the climate control unit.
Scheme 32
| Terminal | Signal name | Connected to | Measurement condition | Voltage (V) | Inspection item (s) |
|---|---|---|---|---|---|
| A | IG2 | A/C 7.5 A fuse | IG SW ON | B+ | Wiring harness: continuity, short circuit (Climate control unit-fuse: A-A/C 7.5 A) A/C 7.5 A fuse |
| IG SW LOCK | 1.0 or less | Wiring harness: continuity, short circuit (Climate control unit-fuse: A-A/C 7.5 A) | |||
| B | B+ | ROOM 15 A fuse | Under any condition | B+ | Wiring harness: continuity, short circuit (Climate control unit-fuse: B-ROOM 15 A) ROOM 15 A fuse |
| C | Blower fan speed control | Power MOS FET | Fan stopped | 1.0 or less | Wiring harness: continuity, short circuit (Climate control unit-power MOS FET: C-C) Power MOS FET |
| Fan: manual LO | 2.8 | ||||
| Fan: manual HI | 9.9 | ||||
| D | TNS signal | TNS relay | Headlight switch OFF | 1.0 or less | Wiring harness: short circuit (Climate control unit-TNS relay: D-D) TNS relay Headlight switch |
| Headlight switch ON | B+ | Wiring harness: continuity, short circuit (Climate control unit-TNS relay: D-D) TNS relay Headlight switch | |||
| E | Blower motor feedback | Power MOS FET | Fan stopped | B+ | Wiring harness: continuity, short circuit (Climate control unit-power MOS FET: E-B) Power MOS FET Blower motor Blower relay HEATER 40 A fuse Power MOS FET replacement |
| Fan: manual LO | 8.17 | ||||
| Fan: manual HI | 0.6 | ||||
| F | Panel control signal | Instrument cluster | Headlight switch OFF | 0 | Wiring harness: continuity (Climate control unit-instrument cluster: F-1F) Instrument cluster Climate control unit: terminal voltage (D) |
| Headlight switch ON | 2.7 | Wiring harness: short circuit (Climate control unit-instrument cluster: F-1F) | |||
| G | Actuator power | Air intake actuator Air mix actuator Airflow mode actuator | IG SW ON | B+ | Wiring harness: continuity, short circuit (Climate control unit-air intake actuator, air mix actuator, air flow mode actuator: G-A, A, A) Air intake actuator Air mix actuator Airflow mode actuator |
| IG SW LOCK | 1.0 or less | ||||
| H | GND | Body ground | Under any condition | 1.0 or less | Wiring harness: continuity (Climate control unit-GND: H-GND) |
| I | Plus Signal | ||||
| J | |||||
| K | A/C | Refrigerant pressure switch | A/C switch ON, fan switch at 1st | 1.0 or less | Wiring harness: short circuit (Climate control unit-refrigerant pressure switch: K-A) |
| A/C switch OFF | B+ | Wiring harness: continuity, short circuit (Climate control unit-refrigerant pressure switch: K-A) (Refrigerant pressure switch-PCM: C-1J ) Refrigerant pressure switch PCM: terminal voltage (1J) | |||
| L | |||||
| M | Evaporator temperature sensor input | Evaporator temperature sensor | Compared with temperature detected by evaporator temperature sensor | (Scheme 33) | Wiring harness: continuity (Climate control unit-evaporator temperature sensor: M-B, S-A) Wiring harness: short circuit (Climate control unit-evaporator temperature sensor: M-B) Evaporator temperature sensor |
| N | Rear window defroster operation | Rear window defroster relay | Rear window defroster switch OFF | B+ | Wiring harness: continuity, short circuit (Climate control unit-rear window defroster relay: N-E) Rear window defroster relay |
| Rear window defroster switch ON | 1.0 or less | ||||
| O | |||||
| P | |||||
| Q | |||||
| R | |||||
| S | Sensor GND | Evaporator temperature sensor | Under any condition | 1.0 or less | Wiring harness: continuity (Climate control unit-GND: S-GND) |
| T |
