WHEEL HUB COMPONENT REMOVAL/INSTALLATION
| CAUTION | Performing the following procedures without first removing the ABS wheel-speed sensor may possibly cause an open circuit in the wiring harness if it is pulled by mistake. Before performing the following procedures, remove the ABS wheel-speed sensor (axle side) and fix it to an appropriate place where the sensor will not be pulled by mistake while servicing the vehicle. |
- Remove in the order indicated in (Scheme 50).
- Install in the reverse order of removal.
- After installation, inspect rear wheel alignment. (See «REAR WHEEL ALIGNMENT»(ref-244483-S31637353352006092400000).)
Scheme 50
Locknut Removal Note
- Lock the disc plate by applying the brakes.
- Knock the crimped portion of the locknut outward using a chisel and a hammer.
- Remove the locknut.
Scheme 51
Brake Caliper Component Removal Note
- Suspend the brake caliper component using a cable or equivalent.
Scheme 52
- Temporarily install a spare nut onto the end of the rear drive shaft.
- Tap the nut with a copper hammer to loosen the drive shaft from the wheel hub.
- Separate the rear drive shaft from the wheel hub.
Scheme 53
Scheme 54
Scheme 55
- Wind the SST and backing plate contact area with packing tape two times.
- Remove the wheel hub component using the SSTs.
- If the bearing inner race remains on the wheel hub component, use a chisel to secure a sufficient space for installing the SST between wheel hub component and bearing inner race.
- Remove the bearing inner race using the SST.
- After removing the bearing, repair any backing plate deformation.
Wheel Bearing Removal Note
- Wind the SST and backing plate contact area with packing tape two times.
- Remove the wheel bearing from the rear knuckle using the SSTs.
- After removing the bearing, repair any backing plate deformation.
Dust Cover Removal Note
Note. Remove the dust cover only if there is an abnormality.
Scheme 56
Scheme 57
- Place an alignment mark on the dust cover and rear knuckle for proper installation.
- Remove the dust cover using a chisel.
Scheme 58
- Remove the bushing from the rear knuckle using the SSTs.
Wheel Hub Bolt Removal Note
Note. Remove the wheel hub bolt only if there is an abnormality.
Scheme 59
- Remove the wheel hub bolts from the wheel hub using a press.
Scheme 60
- Press in new wheel hub bolts into the wheel hub using a press.
Scheme 61
- Press the new bushing into the rear knuckle using the SSTs.
Scheme 62
Scheme 63
- Align the new and old dust covers and place alignment marks on the new dust cover.
- Align the marks on the new dust cover and rear knuckle.
- Press the new dust cover onto the rear knuckle using the SSTs.
Scheme 64
- Install a new wheel bearing using the SSTs.
Scheme 65
- Install the wheel hub component using the SSTs.
Scheme 66
- Tighten a new locknut.
- Install a new locknut and indent as shown to crimp the locknut, using a chisel and hammer.
