Power Systems: Other Mazda MX-5 NC

Ignition Switch/steering Lock 13 illustrations ~297 words

FUSE SERVICE WARNINGS

WARNINGFor vehicles with DSC, if the room fuse is disconnected, the stored initial position of the steering angle sensor will be cleared and the DSC will not operate properly, making the vehicle unsafe to drive. Perform the steering angle sensor initialization procedure after connecting the room fuse. (See STEERING ANGLE SENSOR INITIALIZATION PROCEDURE .)

FUSE SERVICE CAUTION

CAUTIONDetermine and correct the cause of the burnt fuse before replacing it. If the fuse is replaced before doing this, it may burn again.

Scheme 5

Scheme 5: UPPER BLOCK REMOVAL/INSTALLATION
Scheme 5: UPPER BLOCK REMOVAL/INSTALLATION
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
  3. Remove the main fuse block cover.
  4. Remove in the order indicated in (Scheme 5).
  5. Install in the reverse order of removal.

Scheme 6

Scheme 6: Upper Block Removal Note
Scheme 6: Upper Block Removal Note
  1. Press and remove the tabs on upper block at the positions indicated by the arrows.
  2. Raise the upper block and remove it.

Scheme 7

Scheme 7: MAIN FUSE REMOVAL/INSTALLATION
Scheme 7: MAIN FUSE REMOVAL/INSTALLATION
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
  3. Remove the upper block. (See «UPPER BLOCK REMOVAL/INSTALLATION»(ref-244461-S31880700382006092400000).)
  4. Remove in the order indicated in (Scheme 7).
  5. Install in the reverse order of removal.

Scheme 8

Scheme 8: IGNITION SWITCH REMOVAL/INSTALLATION
Scheme 8: IGNITION SWITCH REMOVAL/INSTALLATION
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
  3. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-244480-S03023275402006092400000).)
  4. Remove in the order indicated in (Scheme 8).
  5. Install in the reverse order of removal.

Scheme 9

Scheme 9: IGNITION SWITCH INSPECTION
Scheme 9: IGNITION SWITCH INSPECTION

Scheme 10

Scheme 10
Scheme 10
  1. Verify that the continuity between the ignition switch terminals is as indicated in (Scheme 9). If not as indicated in (Scheme 9), replace the ignition switch.

Scheme 11

Scheme 11: KEY REMINDER SWITCH REMOVAL/INSTALLATION [EXCEPT ADVANCED KEYLESS SYSTEM]
Scheme 11: KEY REMINDER SWITCH REMOVAL/INSTALLATION [EXCEPT ADVANCED KEYLESS SYSTEM]
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
  3. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-244480-S03023275402006092400000) .)
  4. Disconnect the key reminder switch connector.
  5. Remove the key reminder switch.
  6. Install in the reverse order of removal.

Scheme 12

Scheme 12: KEY REMINDER SWITCH INSPECTION [EXCEPT ADVANCED KEYLESS SYSTEM]
Scheme 12: KEY REMINDER SWITCH INSPECTION [EXCEPT ADVANCED KEYLESS SYSTEM]

Scheme 13

Scheme 13
Scheme 13
  1. Verify that the continuity between the key reminder switch terminals is as indicated in (Scheme 12). If not as indicated in (Scheme 12), replace the key reminder switch.

Relay Type

Terminal typePart name
Type AMain relay Starter relay Drive-by-wire relay Blower relay Fuel pump relay Front fog light relay A/C relay TNS relay Rear window defroster relay Horn relay Cooling fan relay No.1 Cooling fan relay No.2 Cooling fan relay No.3 Trunk lid opener relay
Type BHeadlight relay Ignition relay

RELAY TYPE TABLE

Scheme 14

Scheme 14: Type A
Scheme 14: Type A

Scheme 15

Scheme 15
Scheme 15
  1. Verify the continuity between the relay terminals. If not as indicated in (Scheme 14), replace the relay.

Scheme 16

Scheme 16: Type B
Scheme 16: Type B

Scheme 17

Scheme 17
Scheme 17
  1. Verify the continuity between the relay terminals. If not as indicated in (Scheme 16), replace the relay.
