STEERING LOCK UNIT INSPECTION [ADVANCED KEYLESS SYSTEM]
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-244480-S03023275402006092400000) .)
- Measure the voltage at each terminal (other than terminals G and H). If the voltage is not as specified in the «Terminal Voltage Table (Reference)»(ref-244461-S39986085832006092400000) , inspect the parts under "Inspection item(s)".
- Disconnect the steering lock unit connector
- Verify that continuity at terminals G and H is as indicated in the «Terminal Voltage Table (Reference)»(ref-244461-S39986085832006092400000) . If there is any malfunction, inspect the parts under "Inspection item(s)". If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the panel light control switch.
Scheme 2
| Terminal | Signal name | Connected to | Measured condition | Voltage (V)/Continuity | Inspection item(s) |
|---|---|---|---|---|---|
| A | Push switch signal | Keyless control module | Start knob pressed | B+ | Keyless control module Related wiring harnesses |
| Start knob released | 1.0 or less | ||||
| B | Power supply | Fuse | Under any condition | B+ | Fuse Related wiring harnesses |
| C | Key reminder switch signal | Keyless control module | Key inserted | B+ | Keyless control module Related wiring harnesses |
| Key removed | 1.0 or less | ||||
| D | Power supply | Fuse | Under any condition | B+ | Fuse Related wiring harnesses |
| E | Power supply | Fuse | Under any condition | B+ | Fuse Related wiring harnesses |
| F | Ignition key illumination signal | Ignition key illumination bulb | Ignition switch off and driver-side door opened. | 1.0 or less | Ignition key illumination bulb Related wiring harnesses |
| 30s or more after driver-side door closed. | B+ | ||||
| G | Serial communication | Keyless control module | Under any condition: Inspect for continuity to keyless control module. | Continuity detected | Related wiring harnesses |
| H | GND | Body ground | Under any condition: Inspect for continuity to GND. | Continuity detected | Related wiring harnesses |
TERMINAL VOLTAGE TABLE
Scheme 3
Scheme 4
- Remove the battery cover.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000) .)
- Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244480-S41692017792006092400000) .)
- Remove the trunk lid opener relay.
- Install in the reverse order of removal.
