WHEEL HUB, STEERING KNUCKLE REMOVAL/INSTALLATION

CAUTIONPerforming the following procedures without first removing the ABS wheel-speed sensor may possibly cause an open circuit in the harness if it is pulled by mistake. Before performing the following procedures, remove the ABS wheel-speed sensor (axle side) and fit it to an appropriate place where the sensor will not be pulled by mistake while servicing the vehicle.

Scheme 5

Scheme 5
Scheme 5
  1. Remove in the order indicated in the figure.
  2. Install in the reverse order of removal.
  3. After installation, adjust the total toe-in. (See «TOTAL TOE-IN ADJUSTMENT»(ref-194433-S22932977622005092800000) .)

Scheme 6

Scheme 6: ABS Sensor Rotor Removal Note
Scheme 6: ABS Sensor Rotor Removal Note
  1. Secure the front wheel hub in a vise and remove the sensor rotor using the SSTs. NOTE: The sensor rotor does not need to be removed unless replacing it.

Wheel Hub Bolt Removal Note

Note. The hub bolts do not need to be removed unless they are being replaces.

Scheme 7

Scheme 7: Wheel Hub Bolt Removal Note
Scheme 7: Wheel Hub Bolt Removal Note
  1. Remove the hub bolts using a press.

Scheme 8

Scheme 8: Wheel Hub Bolt Installation Note
Scheme 8: Wheel Hub Bolt Installation Note
  1. Install the new hub bolts using a press.

Scheme 9

Scheme 9: ABS Sensor Rotor Installation Note
Scheme 9: ABS Sensor Rotor Installation Note
  1. Install a new sensor rotor using the SSTs and a press.

Scheme 10

Scheme 10: Locknut Installation Note
Scheme 10: Locknut Installation Note
  1. Install a new locknut and stake it as shown.
