Security System and Locks System: Overview Mazda MX-5 NB рестайлинг

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Close the door glass completely.
2. Disconnect the negative battery cable.
3. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(/mazda/mx-5/nb-2001-2005/remont/exteriorinterior-trim/#interior-trim) .)
4. To remove the door lock, remove the rear glass guide. (See «DOOR DISASSEMBLY/ASSEMBLY»(/mazda/mx-5/nb-2001-2005/remont/exterior-body-panels/#doors-and-liftgate) .)
5. Remove in the order indicated in the illustration.
6. Install in the reverse order of removal.

Scheme 37

Scheme 38

1. Remove the door trim. (See «DOOR TRIM REMOVAL/INSTALLATION»(/mazda/mx-5/nb-2001-2005/remont/exteriorinterior-trim/#interior-trim) .)
2. Remove the door screen.
3. Disconnect the door lock actuator connector.
4. Apply battery positive voltage to the door lock actuator terminals and inspect the operation of the door lock actuator. If not as specified, replace the passenger's side door lock.

Scheme 39

1. Remove the screws.
2. Remove the door lock striker.
3. Install in the reverse order of removal.
4. Adjust the door. (See «DOOR ADJUSTMENT»(/mazda/mx-5/nb-2001-2005/remont/exterior-body-panels/#doors-and-liftgate) .)

Scheme 40

1. Close the door glass completely.
2. Disconnect the negative battery cable.
3. Remove the door trim.
4. Remove the door screen.
5. Release the outer handle and the door key cylinder installation rods.
6. Disconnect the door key cylinder switch connector.
7. Remove the door key cylinder switch.
8. Install in the reverse order of removal.

Scheme 41

Scheme 42

1. Raise the door glass completely.
2. Disconnect the negative battery cable.
3. Remove door trim.
4. Remove the door screen.
5. Disconnect the door key cylinder switch connector.
6. Inspect for continuity between the door key cylinder switch terminals using an ohmmeter. If not as specified, replace the door key cylinder switch.

Scheme 43

1. Disconnect the negative battery cable.
2. Remove the door lock switch using a Flathead screwdriver wrapped with protective tape.
3. Install in the reverse order of removal.

Scheme 44

Scheme 45

1. Remove the door lock switch. (See «DOOR LOCK SWITCH REMOVAL/INSTALLATION».)
2. Inspect for continuity between the door lock switch terminals using an ohmmeter. If not as specified, replace the door lock switch.

Scheme 46

1. Disconnect the negative battery cable.
2. Remove the lower panel.
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.
