Mazda MX-5
Wiring diagram

Wiring diagram: Shift interlocks — Shift interlock circuit

Mazda MX-5 NB · 1998-2001

Repair manual
All systems

Shift interlock circuit — Shift interlocks Mazda MX-5 NB

Components on the diagram

    Components on these wiring diagrams

    Click a component to highlight it on every diagram it appears on.
