Wiring diagram: Instrument cluster — Instrument cluster circuit Mazda MX-5 NB
All systems — 25 systems
- Air conditioning 2
- Anti-lock brakes
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Engine performance 1.8l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights
- Power antenna
- Power distribution
- Power door locks
- Power mirrors
- Power windows
- Radio 2
- Shift interlocks
- Starting/charging 2
- Supplemental restraints
- Transmission
- Warning systems
- Wiper/washer
Components on these wiring diagrams 30
Click a component to highlight it on every diagram it appears on.
