DESCRIPTION & OPERATION
Heater case, mounted under center of instrument panel, contains airflow mode doors and air-mix (temperature blend) doors. (Scheme 1) Blower case, mounted under right side of instrument panel, contains blower motor, blower resistor and fresh/recirculated air door. All doors are controlled manually from control panel by cable.
Blower motor relay, located in left rear corner of engine compartment (on relay cluster), supplies power to blower motor. Blower resistors, located on bottom of blower case, determine blower speed.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in appropriate AIR BAG RESTRAINT SYSTEM article in ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle. |
