Brush Installation
- Install brush and spring into holder. Allow brush to extend out of holder until wear limit line extends.08-.16" (2-4 mm) beyond end of brush holder. (Scheme 2) Solder pigtail onto brush holder.
- Insert spring and brush into brush holder. Using a spring scale, pull brush into holder until end of brush protrudes.08" (2.0 mm) from holder. see scheme 15-20. Note reading on spring scale. Replace spring if tension is not 5.6-15.5 ozs. (160-440 g).
