BELT DEFLECTION
Measure belt deflection in center of longest pulley-to-pulley span. See BELT DEFLECTION SPECIFICATIONS table. If belt deflection is not as specified, adjust as necessary.
| Application | (1) Deflection - In. (mm) | ||
|---|---|---|---|
| B2200 | |||
| New Belt | 0.28-0.31 (7.0-8.0) | ||
| Used Belt | 0.31-0.35 (8.0-9.0) | ||
| B2600i | |||
| New Belt | 0.39-0.47 (10.0-12.0) | ||
| Used Belt | 0.43-0.51 (11.0-13.0) | ||
| Miata | |||
| New Belt | 0.31-0.35 (8.0-9.0) | ||
| Used Belt | 0.35-0.39 (9.0-10.0) | ||
| MPV | |||
| 4-Cylinder | |||
| New Belt | 0.39-0.47 (10.0-12.0) | ||
| Used Belt | 0.43-0.57 (11.0-13.0) | ||
| V6 | |||
| New Belt | 0.35-0.39 (9.0-10.0) | ||
| Used Belt | 0.39-0.47 (10.0-12.0) | ||
| MX-3 | |||
| 4-Cylinder | |||
| New Belt | 0.22-0.28 (5.5-7.0) | ||
| Used Belt | 0.24-0.30 (6.0-7.5) | ||
| V6 | |||
| With A/C | |||
| New Belt | 0.22-0.26 (5.5-6.5) | ||
| Used Belt | 0.26-0.30 (6.5-7.5) | ||
| Without A/C | |||
| New Belt | 0.24-0.28 (6.0-7.0) | ||
| Used Belt | 0.28-0.31 (7.0-8.0) | ||
| MX-6 & 626 | |||
| 4-Cylinder | |||
| New Belt | 0.26-0.28 (6.5-7.0) | ||
| Used Belt | 0.28-0.35 (7.0-9.0) | ||
| V6 | |||
| With A/C | |||
| New Belt | 0.22-0.26 (5.5-6.5) | ||
| Used Belt | 0.26-0.30 (6.5-7.5) | ||
| Without A/C | |||
| New Belt | 0.24-0.28 (6.0-7.0) | ||
| Used Belt | 0.28-0.31 (7.0-8.0) | ||
| Protege & 323 | |||
| New Belt | 0.31-0.35 (8.0-9.0) | ||
| Used Belt | 0.35-0.39 (9.0-10.0) | ||
| RX7 | |||
| New Belt | 0.24-0.31 (6.0-8.0) | ||
| Used Belt | 0.28-0.35 (7.0-9.0) | ||
| 929 | |||
| New Belt | 0.39-0.47 (10.0-12.0) | ||
| Used Belt | 0.43-0.51 (11.0-13.0) | ||
| (1) With 22 lbs. (10 kg) applied to belt. | |||
| (1) | With 22 lbs. (10 kg) applied to belt. |
BELT DEFLECTION SPECIFICATIONS
Miata
- Obtain code number and deactivate audio anti-theft system before disconnecting battery.
All Models
- DO NOT reverse battery cable connections. Rectifier will be damaged.
- DO NOT use high voltage type testers.
- Battery voltage is always present at terminal "B".
- DO NOT ground terminal "L" while engine is running.
- DO NOT start engine with connector disconnected from terminals "L" and "S".
- DO NOT apply battery voltage to terminal "L".
ALTERNATOR OUTPUT
- Connect an ammeter (100-amp minimum) in-line between terminal "B" connector and wire. (Scheme 12), (Scheme 13) or (Scheme 14). Turn headlights and all accessories on. Depress brake pedal. Operate engine at 2500-3000 RPM.
- If amperage is not as specified in ALTERNATOR MAXIMUM RATED OUTPUT table, repair or replace alternator as necessary. If amperage is as specified, turn off headlights and all accessories. Release brake pedal. Operate engine at 2500-3000 RPM. If amperage is not about 5 amps or more, repair or replace alternator as necessary.
- If amperage is about 5 amps or more, measure voltage between ground and terminals "S" and "L" while operating engine at 2500-3000 RPM. If 14.1-14.7 volts is not present, repair or replace alternator as necessary. If 14.1-14.7 volts is present, alternator output is okay.
| Application | Amps | |
|---|---|---|
| B2200 | 55 | |
| B2600i | 60 | |
| Miata | ||
| A/T | 65 | |
| M/T | 60 | |
| MPV | 70 | |
| MX-3 | ||
| 4-Cylinder | 70 | |
| V6 | 90 | |
| MX-6 & 626 | ||
| 4-Cylinder | 80 | |
| V6 | 90 | |
| Protege & 323 | 65 | |
| RX7 | 100 | |
| 929 | 90 | |
ALTERNATOR MAXIMUM RATED OUTPUT
Scheme 12
Scheme 13
Scheme 14
Rotor & Slip Rings
Measure resistance between rotor slip ring contacts. (Scheme 20)thru (Scheme 24). If resistance is not within specification, replace rotor. See ROTOR RESISTANCE SPECIFICATIONS table. Check continuity between individual slip rings and rotor core/shaft. If there is continuity, replace rotor.
| Application | Ohms |
|---|---|
| B2200, B2600i, Miata, Protege & 323 | 3.5-4.5 |
| MPV | 2.7-2.9 |
| MX-3 & RX7 | (1) |
| MX-6 & 626 | 2.5-3.5 |
| (1) Information is not available from manufacturer. | |
| (1) | Information is not available from manufacturer. |
ROTOR RESISTANCE SPECIFICATIONS
Stator
Check continuity between stator coil leads and stator core. (Scheme 20)thru (Scheme 24). If there is continuity, replace stator. Check continuity between leads of stator coil. If there is no continuity, replace stator.
Brushes
Replace brushes if worn to limit line. (Scheme 20)thru (Scheme 24). Replace brush springs if corroded. For brush replacement procedure, see OVERHAUL.
