Sunroof: Overview Mazda MPV II рестайлинг

Scheme 1

1. Remove the screws.
2. Slide the deflector to disengage it from the tabs.
3. Remove the deflector.
4. Install in the reverse order of removal.

Scheme 2

Scheme 3

1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, and then remove the glass panel.
4. Peel the weatherstrip off the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-178061-S32982565442005061000000) .)

Scheme 4

Scheme 5

1. Measure the gap and height between the glass panel and body. If not as specified, loosen the glass panel installation screws and reposition the glass panel. Clearance a: 0.2-2.2 mm {0.086 in} b: 0 MM {0 in}
2. Tighten the installation screws.
3. Insert a plastic card (thickness approx. 0.3 mm between the weatherstrip and the body of the vehicle. Verify that the sunroof is shut tightly (there is resistance when the plastic card is moved). If the sunroof is not shut tightly, readjust by performing steps 2 and 3 .

Scheme 6

1. Remove the headliner. (See HEADLINER REMOVAL/INSTALLATION .)
2. Disconnect the front drain hose from the sunroof frame.
3. Remove the front drain hose front he clips.
4. Pull the front drain hose into the room side.
5. Remove the front drain hose.
