FUEL FILTER LOCATION
| Application | Location |
|---|---|
| B2300, B2500, B3000 & B4000 | Inside Frame Rail, Below Cab |
| Miata | Forward Of Differential, Right Side, Under Vehicle |
| Millenia | Front Of Trunk, Under Carpet And Access Panel |
| MPV | Forward of Fuel Tank Below Drivers Seat Under Vehicle. |
| Protege | High And Low Pressure Filters Inside Fuel Tank. |
| Tribute | Forward of Left Rear Wheel Under Vehicle |
| 626 | Under Hood, Front of Left Strut Tower on Frame |
FUEL FILTER LOCATION
Scheme 20
- Relieve the system pressure. Refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-12159-S27442981722000121300000).
- Disconnect the negative battery cable.
- Remove the cruise actuator with the harness and cable connected.
- Remove the air cleaner and air hose.
- Remove in the order indicated in (Scheme 20).
- Install in the reverse order of removal.
- Check for fuel leaks.
Scheme 21
- Relieve the system pressure. Refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-12159-S27442981722000121300000)
- Fuel filter is located inside left frame rail, below cab. Disconnect the push-connect and hairpin clip ("R" clip) fittings.
- Remove the filter from the bracket.
- Install in reverse order of removal.
