MAIN SWITCH
Disconnect main switch connector. Check for continuity between specified terminals of main switch with main switch button held in specified position. See MAIN SWITCH CONTINUITY TEST. (Scheme 2) If continuity is not as specified, replace main switch.
| Switch Position (1) | Terminals | |
|---|---|---|
| Driver | ||
| UP | A & H; C & F | |
| DOWN | A & F; C & H | |
| Auto Down | A & F; C & H | |
| Off (Neutral) | A, C & F | |
| Passenger | ||
| UP | F & K; H & M | |
| DOWN | F & M; H & K | |
| Off (Neutral) | F, K & M | |
| Left Rear | ||
| UP | B & F; D & H | |
| DOWN | D & F; B & H | |
| Off (Neutral) | B, D & F | |
| Right Rear | ||
| UP | H & L; F & N | |
| DOWN | F & L; H & N | |
| Off (Neutral) | F, L & N | |
| (1) Ensure power cut switch is in ON position. | ||
| (1) | Ensure power cut switch is in ON position. |
MAIN SWITCH CONTINUITY TEST
Scheme 2
SUB-SWITCH
Disconnect sub-switch connector. Check for continuity between specified terminals of sub-switch with sub-switch button held in specified position. Refer to the SUB-SWITCH CONTINUITY TEST. (Scheme 3) If continuity is not as specified, replace sub-switch.
| Switch Position | Terminals |
|---|---|
| UP | A & E; B & D |
| DOWN | B & E; D & F |
| Off (Neutral) | A & E; D & F |
SUB-SWITCH CONTINUITY TEST
Scheme 3
WINDOW MOTOR
Disconnect window motor connector. Apply battery voltage and ground between terminals of window motor. Reverse polarity to move motor in opposite direction. If window motor does not operate properly, replace window motor.
| WARNING | Window regulator is spring-loaded to assist window motor during upward movement. Before separating window motor from regulator, securely position regulator arms in full-up position (if possible). This will relieve spring pressure as much as possible, preventing injury when window motor is separated from regulator. |
