Maintenance Information: Overview Mazda Millenia I

Fuse Identification

1. 1 - 120 Amp (White) Main Protection Of All Circuits
2. 2 - 30 Amp (Pink) Additional Cooling Fan For Air Conditioner
3. 3 - 30 Amp (Pink) Fuel Injection System
4. 4 - 40 Amp (Green) Headlights
5. 5 - 60 Amp (Yellow) RADIO, TURN, METER, ENGINE, and S/ROOF Fuses, Ignition System
6. 6 - 30 Amp (Pink) Cooling Fan
7. 7 - 60 Amp (Yellow) Antilock Brake System
8. 8 - 40 Amp (Green) Heater, Air Conditioner
9. 9 - 40 Amp (Green) Rear Window Defroster
10. 10 - 60 Amp (Yellow) STOP, ROOM, D/LOCK and P/WIND Fuses
11. 11 - 20 Amp (Yellow) Audio System
12. 12 - 10 Amp (Red) Horn
13. 13 - 30 Amp (Green) Power Seat
14. 14 - Not Used
15. 15 - 10 Amp (Red) Engine Control System
16. 16 - 10 Amp (Red) Engine Control Unit
17. 17 - 15 Amp (Blue) Fog Lights
18. 18 - 20 Amp (Yellow) Seat Warmer
19. 19 - 15 Amp (Blue) Taillights, Parking Lights, License Plate Lights, Instrument Panel Illumination, Glove Box Light, Clock
20. 20 - Not Used
21. 21 - Not Used
22. 22 - Not Used

Scheme 1

1. 1 - 15 Amp (Blue) Hazard
2. 2 - 15 Amp (Blue) Clock, Interior Light
3. 3 - 15 Amp (Blue) Sunroof
4. 4 - 15 Amp (Blue) Gauges, Back-up Lights, Turn Signals, Cruise Control
5. 5 - 20 Amp (Yellow) Brake Lights
6. 6 - Not Used
7. 7 - 15 Amp IIA
8. 8 - 15 Amp (Blue) Rear Window Defroster
9. 9 - 10 Amp (Red) Air Conditioner
10. 10 - 20 Amp (Yellow) Windshield Wipers and Washer
11. 11 - 10 Amp Mirror Defroster
12. 12 - 15 Amp Starter
13. 13 - 10 Amp (Red) Turn Signal Lights
14. 14 - 15 Amp (Blue) Air Conditioner
15. 15 - 30 Amp (Green) Power Windows
16. 16 - Not Used
17. 17 - Not Used
18. 18 - 10 Amp (Red) Radio (Cassette Tape Player)
19. 19 - 15 Amp (Blue) Engine Control System
20. 20 - 10 Amp (Red) Dashboard Illumination
21. 21 - 15 Amp (Blue) Trunk Light, Fuel-Lid Opener
22. 22 - Not Used
23. 23 - 15 Amp (Blue) Cigar Lighter
24. 24 - Not Used
25. 25 - Not Used
26. 26 - 30 Amp (Green) Spare
27. 27 - Not Used
28. 28 - Not Used
29. 29 - 30 Amp (Pink) Power Door Locks
